UG-110
EVALUATION SETUP
PC
EXTERNAL DC
EXTERNAL POWER
SUPPLY
SWITCH
EXTERNAL DC
GND
USB POWER SWITCH
USB CRYSTAL
AND PROCESSOR
USB
POWER
LED
REFERENCE IN/OUT
Figure 3. Evaluation Setup
PLL
POWER
LED
HEADERS
LOCK DETECT LED
ADF4350
LOOP FILTER
TCXO
Rev. 0 | Page 4 of 12
Evaluation Board User Guide
OSCILLOSCOPE
(OPTIONAL)
SPECTRUM ANALYZER
50Ω
TERMINATION
(OPTIONAL)
