Getting Started - Tektronix VITS 200 Instruction Manual

Table 1–1: Inserter Board (A1) Operating Mode Selection Jumpers (Green)
Function
Sound-in-sync mode
Line Select Mode
Bypass Lockout
Table 1–2: Controller Board (A3) Operating Mode Selection Jumpers (Green)
Function
Front Panel Lockout
External 1 Clamp Mode
External 2 Clamp Mode
External 3 Clamp Mode
External 4 Clamp Mode
Never Used
VITS 200
Jumper #
J9 Pins 1–2: No sound-in-sync on PROGRAM IN.
< 5 >
Pins 2–3: Sound-in-sync on PROGRAM IN (blocks
sound-in-sync pulses from the Genlock circuit).
J22 Pins 1–2: Front panel selection of lines 10 through 21 or
< 3 > lines 17 through 30.
Pins 2–3: Lines 10 through 21 available for VITS.
No Plug: Lines 17 through 30 available for VITS.
J28 Pins 1–2: Front panel BYPASS button enabled.
< 3 >
Pins 2–3: Front panel BYPASS button disabled.
Jumper # Description
J8 Pins 1–2: Front panel enabled.
< 3 >
Pins 2–3: Front Panel disabled.
J19 Pins 1–2: Clamp timing derived from External 1 Input.
< 1 >
Pins 2–3: Clamp timing derived from VITS 200 Genlock
(locked to Program Video or free-running).
J20 Pins 1–2: Clamp timing derived from External 2 Input.
< 1 >
Pins 2–3: Clamp timing derived from VITS 200 Genlock
(locked to Program Video or free-running).
J21 Pins 1–2: Clamp timing derived from External 3 Input.
< 2 >
Pins 2–3: Clamp timing derived from VITS 200 Genlock
(locked to Program Video or free-running).
J22 Pins 1–2: Clamp timing derived from External 4 Input.
< 2 >
Pins 2–3: Clamp timing derived from VITS 200 Genlock
(locked to Program Video or free-running).
J49 Never used. Removed at B020249.
< 5 >
Description

Getting Started

Factory Setting
Pins 1–2
Pins 1–2
Pins 1–2
Factory Setting
Pins 1–2
Pins 1–2
Pins 1–2
Pins 1–2
Pins 1–2
Pins 1–2
1–5
