Performance Verification
Frequency Response and
Crosstalk
5–32
NOTE. Crosstalk specifications are guaranteed to be within specification by
successfully completing the Frequency Response checks.
42. Program Channel Frequency Response
REQUIREMENT — "1% to 5.5 MHz. "3% to 10 MHz.
a. Set the 1410 TSG 6, Multiburst module:
Control
Frequency Range
Markers . . . . . . . . . . . . . . . . . .
Composite . . . . . . . . . . . . . . . .
Amplitude . . . . . . . . . . . . . . . .
Sweep . . . . . . . . . . . . . . . . . . .
others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
b. Connect Sweep out from the 1410 to the P-P Detector Head Input with a
75 Ω coax and barrel connector.
c. Connect 75 Ω coax from Detector Head Output to P-P Detector + Input.
d. Enable P-P Detector + Input.
e. Set + Input Level to light green LED (full clockwise).
Connect 75 Ω coax from P-P detector Output to Test Scope plug in
f.
11A34 CH 1.
g. Store waveform of detected sweep as a reference.
h. Set the 11K oscilloscope with 11A34 module installed in center slot:
Control
Vertical . . . . . . . . . . . . . . . . . .
Horizontal . . . . . . . . . . . . . . . .
Horizontal Desc
Acquire Desc . . . . . . . . . . . . .
Trigger Select . . . . . . . . . . . . .
Source . . . . . . . . . . . . . . . . . . .
Level . . . . . . . . . . . . . . . . . . . .
Time Holdoff . . . . . . . . . . . . .
Mode . . . . . . . . . . . . . . . . . . . .
Coupling . . . . . . . . . . . . . . . . .
Slope . . . . . . . . . . . . . . . . . . . .
Vertical Position
Horizontal Mag.
Setting
. . . . . . . . . . High
On
On
Full
On
Setting
5 mV/div
2 ms/div
. . . . . . . . . . . 10240
continuous
main
C1
20% or as needed to stabilize waveform
6 ms
Auto Level
DC
–
. . . . . . . . . . . as needed to view waveform
. . . . . . . . . . . 1x
(switch position)
(out)
(in)
(in)
(in)
(in)
(out)
