Tektronix VITS 200 Instruction Manual page 201

Replaceable Electrical Parts
Component Tektronix Serial / Assembly Number
Number Part Number Effective
A1CR11 152–0601–01
A1CR12 152–0497–00
A1CR13 152–0582–00
A1CR14 152–0884–00
210–0586–00
210–1178–00
211–0097–00
214–2953–00
342–0563–00
A1CR15 152–0141–02
A1CR16 152–0601–01
A1CR17 152–0601–01
A1CR18 152–0141–02
A1CR19 152–1085–00
A1CR20 152–1085–00
A1CR21 152–0601–01
A1CR22 152–0601–01
A1CR24 152–0601–01
A1CR25 152–0964–00
A1CR26 152–0141–02
A1CR27 152–0964–00 671–2132–05
A1CR28 152–0964–00 671–2132–05
A1CR29 152–0964–00 671–2132–05
A1DS1 150–1090–00
A1DS2 150–1120–00
A1DS3 150–1111–00
A1DS4 150–0035–00
A1LF1 119–1946–00
A1RT1 307–0746–00
A1RV1 307–0663–00
A1TP1 214–4085–00
A1TP2 214–4085–00
A1TP3 214–4085–00
A1TP4 214–4085–00
A1TP5 214–4085–00
A1TP6 214–4085–00
A1TP7 214–4085–00
A1TP8 214–4085–00
A1TP9 214–4085–00
8–24
Discontinued Name & Description
DIODE,RECT:ULTRA FAST;150V,25NS,35A IFSM
DIODE,RECT:BRIDGE,600V,1.5A,1.05VF
DIODE,RECT:SCHTKY;20V,3A,.475VF,80A IFSM
DIODE,RECT:SCHTKY;35V,16A,150A IFSM,630MVF
*ATTACHED PARTS*
NUT,PL,ASSEM WA:4–40 X 0.25,STL CD PL
WASHER,SHLDR:U/W TO–220 XSTR
SCREW,MACHINE:4–40 X 0.312,PNH,STL
HEAT SINK,SEMIC:XSTR,TO–220;VERTICALMOUNT,SLOT
HOLE,(3)SOLDERABLE TABS,COPPER,BLACK PAINT
INSULATOR,PLATE:XSTR,FIBERGLASS REINFORCED
SILICON RUBBER
*END ATTACHED PARTS*
DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF
DIODE,RECT:ULTRA FAST;150V,25NS,35A IFSM
DIODE,RECT:ULTRA FAST;150V,25NS,35A IFSM
DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF
DIO,RECT:ULTRA FAST;1000V,1A,30A IFSM,75NS SOFT
RCVRY
DIODE,RECT:ULTRA FAST;1000V,1A,30A IFSM,75NS SOFT
RECOVERY
DIODE,RECT:ULTRA FAST;150V,25NS,35A IFSM
DIODE,RECT:ULTRA FAST;150V,25NS,35A IFSM
DIODE,RECT:ULTRA FAST;150V,25NS,35A IFSM
DIODE,SIG:ULTRA FAST;ARRAY,6 COM CATH/COMANODE
PAIR,12 DIODES,50V,200MA,4NS,2.5PF
DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF
DIODE,SIG:ULTRA FAST;ARRAY,6 COM CATH/COMANODE
PAIR,12 DIODES,50V,200MA,4NS,2.5PF
DIODE,SIG:ULTRA FAST;ARRAY,6 COM CATH/COMANODE
PAIR,12 DIODES,50V,200MA,4NS,2.5PF
DIODE,SIG:ULTRA FAST;ARRAY,6 COM CATH/COMANODE
PAIR,12 DIODES,50V,200MA,4NS,2.5PF
DIODE,OPTO:LED;RED,626NM,4MCD AT 10MA,60 DEG
VIEW ANGLE,RT ANGLE MT W/EVEN SHEARED LEADS
DIODE,OPTO:LED;AMBER,583NM,8MCD AT 20MA,T1
LT EMITTING DIO:GREEN,D565NM,35MA
LAMP,GLOW:NEON;90V,0.3MA,AID–T,WIRE LD
FILTER,RFI:1A,250V,400HZ W/PC TERMINAL
RES,THERMAL:5 OHM,10%,7A/DEG C
RES,V SENSITIVE:330 V,0.25 W
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAPCB,0.015 X
0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAPCB,0.015 X
0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAPCB,0.015 X
0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAPCB,0.015 X
0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAPCB,0.015 X
0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAPCB,0.015 X
0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAPCB,0.015 X
0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAPCB,0.015 X
0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAPCB,0.015 X
0.032 BRASS,W/RED NYLON COLLAR
Mfr. Mfr. Part
Code Number
04713 MUR115RL
14936 2KBP06M
04713 1N5820
04713 MBR1635
TK0435 ORDER BY DESC
13103 7721–7PPS
TK0435 ORDER BY DESC
13103 6030B–TT
18565 69–11–8805–1674
27014 FDH9427
04713 MUR115RL
04713 MUR115RL
27014 FDH9427
0LUA3 BYV26E
0LUA3 BYV26E
04713 MUR115RL
04713 MUR115RL
04713 MUR115RL
TK2262 DM 308BT100SP–4
27014 FDH9427
TK2262 DM 308BT100SP–4
TK2262 DM 308BT100SP–4
TK2262 DM 308BT100SP–4
15513 SP850211
15513 PCL200–BA
15513 PCL200–MG
TK0213 JH005/3011JA
0GV52 FN326–1/02–K–D–
15454 SG200–S STRAI
34371 V250LA4
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
VITS 200
