Tektronix VITS 200 Instruction Manual page 213

Replaceable Electrical Parts
Component Tektronix Serial / Assembly Number
Number Part Number Effective
A3U26 163–1014–00
136–0963–00
A3U27 156–2991–00
136–0755–00
A3U28 160–8578–00 671–2131–00
A3U28 160–8578–01 671–2131–03
136–0752–00
A3U29 156–2992–00
A3U30 156–2259–00
A3U31 160–8581–00
136–0755–00
A3U32 156–2992–00
A3U33 156–0982–03
A3U34 156–1702–00
A3U35 160–8579–00 671–2131–00
A3U35 160–8579–01 671–2131–02
136–0752–00
A3U36 156–1065–00
A3U37 160–8582–00
136–0755–00
A3U38 160–8583–00
136–0925–00
A3U39 156–0382–02
136–0728–00
A3U40 156–2724–00
A3U41 234–0428–20
136–0752–00
A3U42 156–2321–00
A3U43 156–0728–02
A3U44 156–3142–00
8–36
Discontinued Name & Description
IC,MEMORY: CMOS,EPROM;64K X 8 (Opt 1K Korean GCR)
*MOUNTING PARTS*
SKT,PL–IN ELEK:MICROCKT,32 PIN
*END MOUNTING PARTS*
IC,MEM:CMOS,NVRAM;8K X 8,200NS,SRAM,INTEGRAL
BTRY
*MOUNTING PARTS*
SOCKET,DIP:PCB;FEMALE,STR,2 X 14,28 POS,0.1 X 0.6
CTR,0.175 H X0.130 TAIL,BECU,TIN,ACCOM 0.008–0.0015 X
0.014–0.022
*END MOUNTING PARTS*
671–2131–02 IC,DIGITAL:CMOS,PLD;EEPLD,16V8,25NS,90MA
IC,DIGITAL:CMOS,PLD;EEPLD,16V8,25NS,90MA
*MOUNTING PARTS*
SKT,PL–IN ELEK:MICROCIRCUIT,20 DIP
*END MOUNTING PARTS*
IC,MEMORY:CMOS,SRAM;2K X 8,35NS,OE
IC,DIGITAL:FTTL,RGTR;8–BIT UNIVERSAL SHIFT
IC,MEMORY:CMOS,EPROM;16K X 8
*MOUNTING PARTS*
SOCKET,DIP:PCB;FEMALE,STR,2 X 14,28 POS,0.1 X 0.6
CTR,0.175 H X0.130 TAIL,BECU,TIN,ACCOM 0.008–0.0015 X
0.014–0.022
*END MOUNTING PARTS*
IC,MEMORY:CMOS,SRAM;2K X 8,35NS,OE
IC,DIGITAL:LSTTL,FLIP FLOP
IC,DGTL:TTL,RGTR;10–BIT BFRED, NONINV, 3–STATE
671–2131–01 IC,DGTL:CMOS,PLD;EEPLD,16V8,25NS,90MA,16V8–25,DIP2
0.3,TUBE
IC,DIGITAL:CMOS,PLD;EEPLD,16V8,25NS,90MA
*MOUNTING PARTS*
SKT,PL–IN ELEK:MICROCIRCUIT,20 DIP
*END MOUNTING PARTS*
IC,DIGITAL:LSTTL,LATCH;OCTAL D TRANSPARENT
IC,MEMORY:CMOS,EPROM;16K X 8
*MOUNTING PARTS*
SOCKET,DIP:PCB;FEMALE,STR,2 X 14,28 POS,0.1 X 0.6
CTR,0.175 H X0.130 TAIL,BECU,TIN,ACCOM 0.008–0.0015 X
0.014–0.022
*END MOUNTING PARTS*
IC,DIGITAL:CMOS,PLD;OTP,22V10,25NS,33.3MHZ,90MA
*MOUNTING PARTS*
SOCKET,DIP:PCB;24 POS,2 X 12,0.1 X 0.3 CTR,0.196 H X
0.130 TAIL,BECU,TIN,ACCOM 0.008–0.015THRU 0.014 X
0.022 LEADS
*END MOUNTING PARTS*
IC,DIGITAL:LSTTL,GATES
*MOUNTING PARTS*
SKT,PL–IN ELEK:MICROCKT,14 CONTACT
*END MOUNTING PARTS*
IC,MISC:CMOS,INTERFACE;DUAL RS–232LINE DRVR/RE-
CEIVER,+5V VCC,EXTERNAL CAPS REQUIRED
QUICK CHIP:VIDEO CHANNEL SWITCH,PKG
*MOUNTING PARTS*
SKT,PL–IN ELEK:MICROCIRCUIT,20 DIP
*END MOUNTING PARTS*
IC,DIGITAL:ASTTL,GATE;QUAD 2–INPUT AND
IC,DIGITAL:LSTTL,GATES
IC,DIGITAL:HCTCMOS,GATE;QUAD 2–INPUT NAND
Mfr. Mfr. Part
Code Number
80009 163101400
00779 2–644018–3
0B0A9 DS1225Y
09922 DILB28P–108
80009 160857800
80009 160857801
09922 DILB20P–108
65786 CY7C128A–35PC
01295 SN74F299N
80009 160858100
09922 DILB28P–108
65786 CY7C128A–35PC
01295 SN74LS374N
34335 AM29821PC
80009 160857900
80009 160857901
09922 DILB20P–108
01295 SN74LS373N
80009 160858200
09922 DILB28P–108
80009 160858300
00779 2–641932–3
01295 SN74LS00N
09922 DILB14P–108
1ES66 MAX232EPE
TK2598 234042820
09922 DILB20P–108
01295 SN74AS08N
01295 SN74LS09N
01295 SN74HCT00N
VITS 200
