Performance Verification
Characteristics
Sync
Amplitude
Rise Time
Burst
Amplitude
Rise Time
Delay from Sync
Duration
Breezeway Duration
Front Porch Duration
Horizontal Sync Duration
Equalizing Pulse Duration
Genlock Characteristics
Burst Lock
Genlock Phase Change
with Input Amplitude
Genlock Phase Change
with Input Signal APL
Frequency Dependence on
Input Burst
Lock Range
Frequency
Amplitude
Sync Lock Jitter
Noise Performance
1
Certificate number not provided, unless "Certificate of Traceability" is issued.
5–6
Performance Requirement
285 mV "3 mV
140 ns "20 ns
285 mV "6 mV
p-p
300 ns "35 ns
5.3 ms "100 ns
2.5 ms "100 ns
600 ns "100 ns
1.5 ms "100 ns
4.7 ms "100 ns
2.3 ms "100 ns
v 2 burst phase change for input
sync or burst amplitude range of
287 mV "3 dB
v 4 burst phase change for
amplitude range of 287 mV "6 dB
v 1 burst phase change over 10%
to 90% APL
v 1 burst phase change for
"20 Hz change in incoming
subcarrier
3.579545 MHz "20 Hz
+6 dB to –12 dB
v 10 ns for input sync amplitude
range of 287 mV "3 dB
Locks to 28 dB S/N Ratio Video
Step Incoming Outgoing
28
28
28
28
28
28
28
31
28
32
37
36
34
38
38
36
35
39
