Tektronix VITS 200 Instruction Manual page 191

Replaceable Electrical Parts
Component Tektronix Serial / Assembly Number
Number Part Number Effective
A1Q7 151–0341–00
A1Q8 151–0190–00
A1Q9 151–0656–00
A1Q11 151–0190–00
A1Q12 151–0254–00
A1Q13 151–0190–00
A1Q14 151–0190–00
A1Q15 151–0528–00
A1Q16 151–0908–00
210–0589–00
210–1178–00
211–0097–00
214–2953–00
342–0354–00
A1Q17 151–1171–00
A1Q18 151–0188–00
A1Q180 151–0190–00
A1R3 307–0539–00
A1R4 307–0539–00
A1R5 307–0650–00
A1R6 307–0446–00
A1R7 307–0446–00
A1R8 307–0446–00
A1R9 307–0446–00
A1R10 322–3235–00
A1R11 307–0650–00
A1R12 307–0650–00
A1R13 307–0650–00
A1R14 322–3235–00
A1R18 322–3306–00
A1R19 322–3147–00
A1R20 322–3318–00
A1R21 322–3318–00
A1R22 322–3318–00
A1R23 322–3193–00
A1R24 322–3295–00
A1R25 322–3126–01
A1R26 322–3126–01
A1R27 322–3295–00
A1R28 322–3258–00
A1R29 322–3482–02
A1R30 311–2230–00
A1R31 322–3304–00
A1R32 322–3143–00 671–2132–00
A1R32 322–3154–00 671–2132–13
A1R33 311–2226–00 671–2132–00
A1R33 311–2227–00 671–2132–03
A1R33 311–2228–00 671–2132–13
8–14
Discontinued Name & Description
XSTR,SIG:BIPOLAR,NPN;45V,50MA,40MHZ,AMPL
XSTR,SIG:BIPOLAR,NPN;40V,200MA,300MHZ,AMPL
XSTR,PWR:BIPOLAR,NPN;80V,8.0A,4.0MHZ,DARLING-
TON,AMPL
XSTR,SIG:BIPOLAR,NPN;40V,200MA,300MHZ,AMPL
XSTR,SIG:BIPOLAR,NPN;30V,500MA,125MHZ,AMPL,DAR-
LINGTON
XSTR,SIG:BIPOLAR,NPN;40V,200MA,300MHZ,AMPL
XSTR,SIG:BIPOLAR,NPN;40V,200MA,300MHZ,AMPL
THYRISTOR,PWR:BIPOLAR,SCR;50V,16A RMS,PHASE
XSTR,PWR:BIPOLAR,NPN;500V
VCEO,1000VVCEV,5A,SWITCHING
*ATTACHED PARTS*
NUT,SLFLKG,HEX:4–40 X 0.246,STL CD PL
WASHER,SHLDR:U/W TO–220 XSTR
SCREW,MACHINE:4–40 X 0.312,PNH,STL
HEAT SINK,SEMIC:XSTR,TO–220;VERTICALMOUNT,SLOT
HOLE,(3)SOLDERABLE TABS,COPPER,BLACK PAINT
INSULATOR,PLATE:XSTR,SILICONE RUBBER
*END ATTACHED PARTS*
XSTR,PWR:MOS,N–CH;50V,12A,0.12 OHM
XSTR,SIG:BIPOLAR,PNP;40V,200MA,250MHZ,AMPL
XSTR,SIG:BIPOLAR,NPN;40V,200MA,300MHZ,AMPL
RES NTWK,FXD,FI:(7)510 OHM,10%,1W
RES NTWK,FXD,FI:(7)510 OHM,10%,1W
RES NTWK,FXD,FI:9,2.7K OHM,5%,0.150W
RES NTWK,FXD,FI:10K OHM,20%,(9)RES
RES NTWK,FXD,FI:10K OHM,20%,(9)RES
RES NTWK,FXD,FI:10K OHM,20%,(9)RES
RES NTWK,FXD,FI:10K OHM,20%,(9)RES
RES,FXD:METAL FILM;2.74K OHM,1%,0.2W,TC=100
RES NTWK,FXD,FI:9,2.7K OHM,5%,0.150W
RES NTWK,FXD,FI:9,2.7K OHM,5%,0.150W
RES NTWK,FXD,FI:9,2.7K OHM,5%,0.150W
RES,FXD:METAL FILM;2.74K OHM,1%,0.2W,TC=100
RES,FXD:METAL FILM;15K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;332 OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;20K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;20K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;20K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;11.5K OHM,1%,0.2W,TC=100
RES,FXD,FILM:200 OHM,0.5%,0.2W,TC=TOSMALL BODY
RES,FXD,FILM:200 OHM,0.5%,0.2W,TC=TOSMALL BODY
RES,FXD:METAL FILM;11.5K OHM,1%,0.2W,TC=100
RES,FXD:METAL FILM;4.75K OHM,1%,0.2W,TC=100
RES,FXD,FILM:14.2K OHM,5%,0.2W,TC=TO
RES,VAR,TRMR:CERMET;500 OHM,20%,0.5W,0.197SQ,TOP
ADJUST
RES,FXD,FILM:14.3K OHM,1%,0.2W,TC=T0TAPED &
671–2132–12 RES,FXD,FILM:301 OHM,1%,0.2W,TC=T0MI,SM BODY
RES,FXD:METAL FILM;392 OHM,1%,0.2W,TC=100 PPM
671–2132–02 RES,VAR,TRMR:CERMET;50 OHM,20%,0.5W,0.197 SQ,TOP
ADJUST
671–2132–12 RES,VAR,TRMR:CERMET;100 OHM,20%,0.5W,0.197SQ,TOP
ADJUST
RES,VAR,TRMR:CERMET;200 OHM,20%,0.5W,0.197SQ,TOP
ADJUST
Mfr. Mfr. Part
Code Number
04713 MPS6520
04713 2N3904
04713 2N6044
04713 2N3904
0JR04 MPS–A14
04713 2N3904
04713 2N3904
04713 2N6400
04713 MJH16002A
TK0409 CF22NM40
13103 7721–7PPS
TK0435 ORDER BY DESC
13103 6030B–TT
2K262 342–0354–00
04713 MTP15N05E
04713 2N3906
04713 2N3904
11236 750–81–R510 OHM
11236 750–81–R510 OHM
11236 750–101–R2.7K
11236 750–101–R10K
11236 750–101–R10K
11236 750–101–R10K
11236 750–101–R10K
91637 CCF501G27400F
11236 750–101–R2.7K
11236 750–101–R2.7K
11236 750–101–R2.7K
91637 CCF501G27400F
91637 CCF50–2–G1502F
91637 CCF501G332R0F
91637 CCF501G20001F
91637 CCF501G20001F
91637 CCF501G20001F
91637 CCF501G10000F
91637 CCF50G11501F
91637 CCF501G200R0D
91637 CCF501G200R0D
91637 CCF50G11501F
56845 CCF50–2–G4751FT
91637 CCF501D14201D
TK2073 GF06UT2 501 M L
91637 CCF50G14301F
91637 CCF501G301ROF
91637 CCF501G392R0F
TK2073 GF06UT2 500 M L
TK2073 GF06UT2 101 M L
TK2073 GF06UT2 201 M L
VITS 200
