CHAPTER 5: APPENDIX
SPECIFICATIONS
DIMENSIONS (W x D x H)
10.5" x 4.5" 2.75"
WEIGHT
2.0 lbs.
ENVIRONMENTAL
Operating Temperature: -32 to 122° F)
Operating Humidity: 15 to 80%
POWER SUPPLY
Input: 100 to 240 VAC, 50-60 Hz, 0.5 A
Output: 12 VDC, 0.83 A
RS-232 CONTROL PORT
DB9 Female
38,400/57,600 baud rate: 8 bits, 1 stop,
no parity
Flow Control: None
MAXIMUM DISTANCE FROM CONTROLLER
TO MIXER
150' CAT 3 Cable
MODELS
910-151-890 Tabletop Controller
Chapter 5: Appendix
19
