PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 3 C2, C13, C21
3 2 C3, C4
4 1 C10
5 1 C14
6 1 C15
7 1 C16
8 1 C17
9 3 C18-C20
10 1 C24
11 2 C26, C29
12 1 C27
13 1 C28
14 1 C31
15 1 D1
16 1 D5
17 1 L1
18 4 M1, M2, M3, M4
19 2 R1, R15
20 2 R2, R3
21 2 R4,R21
22 2 R5,R24
23 1 R6
24 3 R7-R9
25 1 R10
26 2 R11, R12
27 3 R13, R14, R17
28 1 R16
29 1 R22
30 1 R23
31 1 RSENSE
32 1 U1
PART DESCRIPTION
CAP , CHIP , X5R, 4.7µF, ±10%, 50V, 0805
CAP , CHIP , X5R, 68nF, ±10%, 50V, 0402
CAP , CHIP , X5R, 10µF, ±20%, 50V, 1210
CAP .,150uF ,ALUM. ELECT.,50V,20%,10x10.2mm RADIAL,FK
Series, AEC-Q200
CAP , CHIP , X5R, 4.7µF, ±20%, 6.3V, 0603
CAP , CHIP , X5R, 0.22µF, ±10%, 25V, 0402
CAP , CHIP , COG, 33pF,±5%, 50V, 0402
CAP , CHIP , X5R, 0.22µF, ±10%, 10V, 0402
CAP , CHIP , X5R, 22µF, ±20%, 25V, 1210
CAP , 220µF, 25V, Alum. Electro, 20%, 8mm X 10.2mm
CAP , CHIP , COG, 100pF, ±5%, 50V, 0402
CAP , CHIP , X7R, 47nF, ±10%, 25V, 0402
CAP , CHIP , X7R, 4.7nF, ±10%, 25V, 0402
CAP , CHIP , X5R, 10nF, ±10%, 10V, 0402
DIODE, GEN PURP , 75V, 250MA, SOD123
DIODE, GEN PURP , 75V, 150MA, SOD323F
IND, SMT, 6.8µH, ±20%
MOSFET, N-CH, 40V, 10.5A, 1212-8
RES, CHIP , 20Ω, ±1%, 1/16W, 0402
RES, CHIP , 665kΩ, ±1%, 0.1W, 0402
RES, CHIP , 40.2KΩ, ±1%, 0.1W, 0402
RES, CHIP , 10KΩ, ±1%, 1/16W, 0402
RES, CHIP , 49.9KΩ, ±1%, 1/16W, 0402
RES, CHIP , 100KΩ, ±5%, 1/16W, 0402
RES, CHIP , 3.40KΩ, ±1%, 1/16W, 0402
RES, CHIP , 86.6KΩ, ±1%, 1/16W, 0402
RES, CHIP , 100KΩ, ±1%, 1/16W, 0402
RES, CHIP , 499KΩ, ±1%, 1/16W, 0402
RES, CHIP , 0Ω, ±1%, 1/16W, 0402
RES., 4.99 OHMS, 1%, 1/16W, 0402, AEC-Q200
RES, CHIP , 10mΩ, ±1%, 1W, 1632 LONG SIDE TERM
60V SYNC. BUCK MULTI-CHEMISTRY BATTERY CHARGER
DEMO MANUAL DC2374B
MANUFACTURER/PART NUMBER
TDK, C2012X5R1H475K
TDK, CGA2B3X5R1H683M050BB
TDK, C3225X5R1H106M250AB
PANASONIC, EEE-FK1H151P
TAIYO YUDEN, JMK107BJ475MAHT
TAIYO YUDEN, TMK105BJ224KVHF
JOHANSEN TECHNOLOGY,
500R07S330JV4T
TAIYO YUDEN, LMK105BJ224KV-F
TAIYO YUDEN, TMK325BJ226MM-T
PANASONIC, EEHZC1E221P
TDK, CGJ2B2C0G1H101J050BA
MURATA, GCM155R71E473KA55D
MURATA, GRM155R71E472KA01D
KEMET, C0402C103K8PAC7867
DIODES INC, 1N4448WQ-7-F
ON SEMICONDUCTOR, 1N4148WS
WURTH, 74439358068
VISHAY SILICONIX, SI7116DN-T1-E3
VISHAY, CRCW040220R0FKED
VISHAY, CRCW0402665KFKED
VISHAY, CRCW040240K2FKED
VISHAY, CRCW040210K0FKED
VISHAY, CRCW040249K9FKED
VISHAY, CRCW0402100KJNED
VISHAY, CRCW04023K40FKED
VISHAY, CRCW040286K6FKED
VISHAY, CRCW0402100KFKED
VISHAY, CRCW0402499KFKED
VISHAY, CRCW04020000Z0ED
VISHAY, CRCW04024R99FKEDC
SUSUMU, PRL1632-R010-F-T1
ANALOG DEVICES, LTC4013EUFD#PBF
