PARTS LIST
ITEM QTY REFERENCE
Additional Demo Board Circuit Components
33 0 C5 (OPT)
34 0 C6-C9, C22, C23 (OPT)
35 0 C11, C12 (OPT)
36 0 C25 (OPT)
37 0 C30 (OPT)
38 0 D2 (OPT)
39 0 D6 (OPT)
40 0 L2 (OPT)
41 0 M5, M6 (OPT)
42 0 R20 (OPT)
Hardware: For Demo Board Only
43 1 D3
44 1 D4
45 4 E1, E4, E5, E8
46 4 E2, E3, E6, E7
47 10 E9 - E18
48 3 JP1, JP3, JP4
49 4 JP2, JP5-JP7
50 7 XJP1-XJP7
51 2 R18, R19
52 4 MH1-MH4
12
PART DESCRIPTION
CAP , 68µF, 50V, Alum. Electro, 20%, 8mm x 10.2mm
CAP , CHIP , X5R, 10µF, ±20%, 50V, 1210
CAP .,68uF ,ALUM. ELECT.,50V,20%,8x10.2mm,
RADIAL,AEC-Q200
CAP , 220µF, 25V, Alum. Electro, 20%, 8mm X 10.2mm
CAP , CHIP , COG, 100pF, ±5%, 50V, 0402
DIODE, SCHOTTKY, 60V, 3A, SMB
DIODE,TVS,12V,15.5V,350W,SOD323-2
IND, SMT, WE-HCI 1365
MOSFET, N-CH, 40V, 35A, 1212-8
RES, CHIP , 0Ω JUMPER, 1W, 2512
DIODE, LED, GREEN, 0603
DIODE, LED, RED, 0603
TURRET, 0.09 DIA
BANANA JACK, NON-INSULATED
TURRET, 0.061 DIA
HEADER, 4PINS, 2mm
HEADER, 3PINS, 2mm
SHUNT 2mm 1X2
RES, CHIP , 7.5KΩ, ±1%, 1/4W, 1206
STANDOFF , NYLON 0.5"
MANUFACTURER/PART NUMBER
PANASONIC, EEHZA1H680P
TDK, C3225X5R1H106M250AB
PANASONIC, EEHZA1H680P
PANASONIC, EEHZC1E221P
TDK, CGJ2B2C0G1H101J050BA
ON SEMICONDUCTOR, MBRS360BT3G
MICRO COMMERCIAL, ESD12VD3B-TP
WURTH, WE-HCI 1365
VISHAY SILICONIX, SIS434DN-T1-GE3
VISHAY, CRCW25120000Z0EG
LITE-ON, LTST-C190KGKT
LUMEX, SML-LX0603SRW-TR
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
MILL-MAX, 2308-2-00-80-00-00-07-0
WURTH, 62000411121
WURTH, 62000311121
WURTH, 60800213421
YAGEO, RC1206FR-077K5L
KEYSTONE, 8833
