●Do not charge the phone after the fast charge is triggered.The manufacturer is not
responsible if the phone is damaged by doing so.
4.Performance description
【 4.0.1 】 Human-computer interaction
1. 1.77 inch TFT-LCD screen
2. Multi-function switch
【 4.0.2】 Voltage and Current
1. The highest six-digit display of voltage, current and power, the highest resolution is
0.00001 (V/A/W).
2. Record the minimum, maximum and average values of voltage, current,and power
during operation.
3. 10 sets of switchable capacity, power, and time statistics.
4. 1 set of voltage and current curve records, maximum support 9 hours.
5.Support low-speed waveform (voltage, current, D+, D-) drawing, 2sps->100sps
sampling rate.
6. Support high-speed ripple (voltage, AC coupling) drawing, up to 3.2Msps sampling rate.
【 4.0.3】 Fast charge trigger
1. QC2.0,QC3.0 trigger;
2. Huawei FCP,SCP trigger;
3. Samsung AFC trigger;
4. PD2.0/3.0 Trigger;
5. VOOC/WARP Trigger;
6. SuperVOOC Trigger;
【 4.0.4 】 Wire identification class
1. The internal resistance measurement of the
wire by the differential pressure method;
3.Touch switch
7. The above protocols all support automatic monitoring;
8. MTK-PE automatic detection;
9. Support QC2.0->PD2.0 protocol conversion;
10. Support a maximum of 24 hours for a limited time
trigger, and automatically close the trigger when the
time comes.
2
2. E-Marker Cable chip reading;
3. DASH Cable data reading;
