Backend Connection Setting - Free2Move eSolutions eProWallbox Installation Manual

5.2

Backend connection setting

By default, eProWallbox is configured to connect to the eSolutions control platform
(CPMS). When requested,
platform using OCPP 1.6 JSON protocol via 4G LTE, using a third-party SIM card or via
Wi-Fi.
WARNING
Pay careful attention to ensure that the ProWallbox is switched off
before carrying out these operations.
The function supports clear text or TLS encrypted OCPP connections.
To install a third-party SIM card:
•
Turn off eProWallbox
•
Remove the external cover off eProWallbox
•
Pull the cover out removing the 6 screws using the Torx T20 ¼'' screwdriver
•
Remove the existing SIM card from the slot, as indicated in the figure, and
insert the new one
•
Close
•
Turn on eProWallbox and proceed with the configuration
(SIM card slot)
eProWallbox
eProWallbox following the instructions at paragraph 2.12
can be connected to a third-party backend
48
Inst a llat io n M an ual
