2.6

Description of ports

The following table summarises the ports available on eProWallbox:
ETH 1x
(CN12) RS485 x1 DPM
(CN9-CN10) RS485 x1 DC
4GLTE, WI-FI,
BLE Board
SIM Card
(SW2) DIP Switch
(CN1) Power input Cable
Relays
Type
Input
Communication
Configuration
Safety
Port
Power Cables
RS485 DC
RS485 DPM
Rotary Switch
DIP Switch
Shunt trip contact
Port code Scope
CN1 Terminals for power cables
CN9 RS485 Modbus for Daisy Chain
CN10 communication
RS485 Modbus for external meter
CN12
communication
SW1 Power safety limit setting
SW2 Setting for IT grid connection
CN3 Free contact NO for MCB release
15
Inst a llat io n M an ual
RFID reader
(SW1) Rotary Switch
(CN3) Shunt Trip
ISO15118
PP/CP
Power output cable
N
1x
2x
1x
1x
1x
1x
