Free2Move eSolutions eProWallbox Series Configuration Manual

Modbus rtu
Hide thumbs

Advertisement

Quick Links

Download this manual
EN
MODBUS RTU
C o n f i g u r a t i o n G u i d e

Advertisement

loading
Need help?

Need help?

Do you have a question about the eProWallbox Series and is the answer not in the manual?

Questions and answers

Related Manuals for Free2Move eSolutions eProWallbox Series

Summary of Contents for Free2Move eSolutions eProWallbox Series

  • Page 1 MODBUS RTU C o n f i g u r a t i o n G u i d e...
  • Page 2 MODBUS RTU C o n f i g u r e a t i o n G u i d e TABLE OF CONTENT INTRODUCTION ........................................CONFIGURATION ........................................LIST OF CHARGING STATION REGISTERS ..........................ADDRESS DESCRIPTION ....................................

  • Page 3: Introduction

    The following document is an extension to the supplied manuals of eProWallbox Family Please always refer to th e dedicated installation manual before operating on the product. Free2move eSolutions S.p.A. recommends only using experienced professionals who comply with current regulations to install the product correctly.

  • Page 4: List Of Charging Station Registers

    Once the connection is completed and the communication is established, follow the steps: Open the service tool for PC provided by Free2Move eSolutions Select the serial port COM4 by inserting 1 Select the BaudRate 115200 by inserting 4...
  • Page 5 DPM_LIMITING 40107 UINT16 TEMP_DERATING_STAUTS 40108 UINT16 RTU_ADR 40200 UINT16 NEW_RTU_ADR 40201 UINT16 MODBUS RTU ACTIVATE_NEW_RTU_ADR 40202 UINT16 BAUD_RATE 40210 UINT16 NEW_BAUD_RATE 40211 UINT16 C o n f i g u r e a t i o n G u i d e ACTIVATE_NEW_BAUD_RATE 40212 UINT16...

  • Page 6: Address Description

    MODBUS RTU C o n f i g u r e a t i o n G u i d e ADDRESS DESCRIPTION Hereafter the description of charging station addresses: SERIAL_NUMBER: 40000 The address contains the unique serial number of the charging station. SW_VERSION: 40008 The address contains the revision of software or firmware of the charging station.
  • Page 7 MODBUS RTU C o n f i g u r e a t i o n G u i d e GENERAL_STATUS: 40101 The address contains the status of the charging station according to IEC 61851 State Machine as it follows: •...
  • Page 8 MODBUS RTU C o n f i g u r e a t i o n G u i d e DPM_LIMITING: 40107 The address contains the status of the DPM function: • 0 = function disabled • 1 = function enabled. Charging current limited by the DPM TEMP_DERATING_STAUTS: 40108 The address contains the status of the current derating function: •...
  • Page 9 MODBUS RTU C o n f i g u r e a t i o n G u i d e BAUD_RATE: 40210 The address contains the number of transitions per second occurring on the communication line expressed as Baud Rate: •...
  • Page 10 MODBUS RTU C o n f i g u r e a t i o n G u i d e LOAD_UNBALANCE_ENABLED: 40402 The address contains the status of the Load unbalance function: • 0 = disabled • 1 = enabled To enable this parameter, you can connect to the wallbox following the procedure described in this manual in the Configuration chapter.
  • Page 11 MODBUS RTU C o n f i g u r e a t i o n G u i d e CURRENT_LIMIT: 40407 The address contains the current limitation value that can be set remotely through third-party EMS in real time. NOTE: The lower current limit value set (e.g.
  • Page 12 MODBUS RTU C o n f i g u r e a t i o n G u i d e RESET_LAST_ERRORS: 40500 The address is used to reset the last error occurred on the wallbox: enter 0x5555 to activate. RESET_ENERGY: 40501 The address is used to reset the energy measures registered on each phase: enter 0x5555 to activate.
  • Page 13 MODBUS RTU C o n f i g u r e a t i o n G u i d e L1_THD_V: 40610 This address contains the measured THD of voltage on phase 1, expressed in % L2_THD_V: 40612 This address contains the measured THD of voltage on phase 2, expressed in % L3_THD_V: 40614 This address contains the measured THD of voltage on phase 3, expressed in % L1_Iac: 40620...
  • Page 14 MODBUS RTU C o n f i g u r e a t i o n G u i d e L1_Pac: 40636 This address contains the Active Power value measured on phase 1, expressed in W L2_Pac: 40638 This address contains the Active Power value measured on phase 2, expressed in W L3_Pac: 40640 This address contains the Active Power value measured on phase 3, expressed in W L1_Qac: 40642...
  • Page 15 MODBUS RTU C o n f i g u r e a t i o n G u i d e L1_ACTIVE_ENERGY: 40658 This address contains the Active Energy value measured on phase 1, expressed in Wh L2_ACTIVE_ENERGY: 40660 This address contains the Active Energy value measured on phase 2, expressed in Wh L3_ACTIVE_ENERGY: 40662 This address contains the Active Energy value measured on phase 3, expressed in Wh L1_REACTIVE_ENERGY: 40664...
  • Page 16 MODBUS RTU C o n f i g u r e a t i o n G u i d e Registered office Free2move eSolutions S.p.A. Piazzale Lodi, 3 20137 Milan – Italy esolutions.free2move.com...
