2.5 COM Control Commands

RS232 cable with straight-through connection(USB-RS232 can be used directly to control)
Communication protocol:
Baud rate: 115200
Data bit: 8
Stop bit: 1
Check bit: None
Commands
YAll.
All1.
YXZ.
YXZ&Q&W.
SaveY.
RecallY.
BeepON.
BeepOFF.
Y?.
Note:
© Xiamen RGBlink Science & Technology Co., Ltd.
| support@rgblink.com | www.rgblink.com
Ph: +86 592 5771197
Explanation
Y=1,2,3,4......
Eg. "1ALL." means switch input 1 to all outputs
Switch all the channels to be one to one. Eg.1->1，
One to one
Y=1,2,3,4......
Z=1,2,3,4...... Eg. "1X2." means switch Input 1 to output 2
Y=1,2,3,4......
Z=1,2,3,4......
Eg. "1X2&3&4." means switch Input 1 to Output 2,
Q=1,2,3,4......
W=1,2,3,4......
Y=1,2,3,4......
Eg. "Save2." means saving current status to Scene 2
Y=1,2,3,4......
Eg. "Recall2." means recall the saved Scene 2
Beep sound
Check the Input Y to outputs switching status
Y=1,2,3,4.......
Eg. "1?." means to check Input 1 switching status
Function description
Switch Input Y to all the outputs
2->2，3->3......
Switch Input Y to Output Z
Switch Input Y to Output Z, Q, W
3, 4
Save current status to scene Y
Recall the saved scene Y
Buzzer on
Buzzer off
