Chapter 2 Use Your Product

The LCD display screen will light up after power and turned on. It shows the current operation status, press
MENU button, it will keep recycling between VIEW, SWITCH, SCENE, SETUP four different interface. The default
interface is VIEW.

2.1 Front Buttons Switching Operation

2.1.1 Switching operation

Switching with industry 2-key fast switching, first press the input button and then select/press output button.
Details are as follow:
There are 1~9 nine input buttons, 1~9 nine output buttons. First press MENU to show SWITCH interface,

then can continue the next switching step.
Press input number at the INPUT area, the input button will light up with blue light.

Then press output number at the OUTPUT area, and the output button will light up. Users also can press

the UP button to realize 1 to ALL switching.
If need to cancel switching, can press the button again to cancel. Users also can press the DOWN button

to cancel all outputs.

2.1.2 Scene Operation

The system can save 40 scenes, after switching successfully in the SWITCH interface, press MENU button

and switch to SCENE interface.
Enter the wanted scene save number(1~9), then press SAVE. If want to reload the saved scene, press the

scene number and press RECALL button.

2.1.3 Setup Operation

First press MENU switch to SETUP interface, then continue next operation.

Via SETUP, it can realize IP address changing, in SETUP interface can use UP/ DOWN button to position,

enter the needed IP address from the left button side, then press SAVE button to save.

2.1.4 View Operation

Via MENU button switch to VIEW interface, will display the current switching status


2.2 WEB Control

The default IP address are 192.168.0.80(LAN1) and 192.168.1.80(LAN2).

2.2.1 Login Operation

Accordingly to connected LAN port, enter the corresponding IP address, if using the LAN2, then enter
192.168.1.80 in the browse(Recommend with Google Chrome) as below:
