GPIO Configuration

GPIO
PoC Enable P1:Pin 119 - CAM_AVDD_EN
EXT TRIG P1:Pin86 – PWM01 OR External
GPIO0 P1:Pin86 – PWM01
GPIO1 I2C Expander:Pin1 – P00
GPIO2 I2C Expander:Pin2 – P01
GPIO3 P3:Pin6 OR P1:Pin117
GPIO4 I2C Expander:Pin3 – P02
GPIO5 I2C Expander:Pin4 – P03
GPIO6 Deserializer B/C/D GPIO6
PDB P1:Pin 95 – CAM0_RST#
GPIO0 P1:Pin86 – PWM01
GPIO1 I2C Expander:Pin5 – P04
GPIO2 I2C Expander:Pin6 – P05
GPIO3 P3:Pin5 OR P1:Pin106
GPIO4 I2C Expander:Pin7 – P06
GPIO5 I2C Expander:Pin8 – P07
GPIO6 Deserializer B/C/D GPIO6
PDB P1:Pin 95 – CAM0_PWDN
GPIO0 P1:Pin86 – PWM01
GPIO1 I2C Expander:Pin10 – P10
GPIO2 I2C Expander:Pin11 – P11
GPIO3 P3:Pin4 OR P1:Pin103
GPIO4 I2C Expander:Pin12 – P12
GPIO5 I2C Expander:Pin13 – P13
GPIO6 Deserializer B/C/D GPIO6
PDB P1:Pin 95 – CAM1_PWDN
GPIO0 P1:Pin86 – PWM01
GPIO1 I2C Expander:Pin14 – P14
GPIO2 I2C Expander:Pin15 – P15
GPIO3 P3:Pin3 OR P1:Pin104
GPIO4 I2C Expander:Pin16 – P16
GPIO5 I2C Expander:Pin17 – P17
GPIO6 Deserializer B/C/D GPIO6
PDB P1:Pin 95 – CAM1_RST#
Document: CTIM-00061
Revision: 0.00
Source
Enables Power over Coaxial
Direction selectable (via J2) External Trigger.
Global PWM Trigger
GPIO
GPIO
Interrupt pin
GPIO
GPIO
Master/Slave synchronization
Deserializer Power ON
Global PWM Trigger
GPIO
GPIO
Interrupt pin
GPIO
GPIO
Master/Slave synchronization
Deserializer Power ON
Global PWM Trigger
GPIO
GPIO
Interrupt pin
GPIO
GPIO
Master/Slave synchronization
Deserializer Power ON
Global PWM Trigger
GPIO
GPIO
Interrupt pin
GPIO
GPIO
Master/Slave synchronization
Deserializer Power ON
