TYPICAL INSTALLATION AND USAGE
Software setup
Prior to hardware installation, make sure you have the correct software installed on the Jetson AGX
Xavier™ module. Installation instructions can be found at https://connecttech.com/resource-
center/kdb373/. All other FPDLINK cameras should work with proper software and firmware
configuration as long as the power requirements match what JCB006 provides.
Hardware setup
1. Ensure all external system power supplies are off.
2. Connect camera(s) to miniCoax connector(s).
a. Optionally connect an external 12V DC power supply to J1.
b. The external power connector provides unregulated power to the cameras. Do not
exceed camera input voltage.
3. Switch ON the Power Supply. DO NOT power up your system by plugging in live power.
Note: 10mm M3 extension standoffs are recommended to be added to the 18mm standoffs provided with the Rogue carrier for
clearance.
Document: CTIM-00061
Revision: 0.00
NVIDIA® Jetson™ FPD-Link III Camera Platform
Page 13 of 17
Users Guide
www.connecttech.com
Date: 2023-02-07
