Connector Summary & Locations
Connectors
Designator
P1
MIPI Camera Expansion Connector (Samtec QTH)
P2A, P2B
Quad FAKRA Connector (Mate-AX Style, 4-position miniCoax)
P3
IO Connector
J1
External power Connector (Mini-Fit Jr.)
J2
Trigger Control Jumper
LEDs
Designator
D1
D1A, D1B, D1C, D1D are the PASS LED indicator for the corresponding Deserializer
D2
D2A, D2B, D2C, D2D are the LOCK LED indicator for the corresponding Deserializer
D3
Power LED indicator from J1
D4
Power LED indicator from P1
