9.4.25 Update Logic Statement

Command = UL<Statement Number><Length of logic elements> <Set of
elements>
Statement Number = <Byte> 1 - 100
Length of logic elements = <Byte> number of bytes of the Logic element for each
statement, including the 0x03 (ETX) terminator.
Set of elements = See description in QL above.
Example: IF External Input 21 and External Input 2 and External Input 18 and
External Input 8
THEN Start Timer 1 and Extern Out On 10
Hex code for above including length and checksum:
1500554C01114115264102264112264108205101410A031A
Response = None (Just header and trailer)
Logic changes are not allowed while a process is running or if Cygnus 2 is in a stop.

9.4.26 Cygnus 2 Event List

Events used in the Logic Statement IF section. Logic codes are used in the
remote communication query and update commands. The Logic codes start at
0x41 because there are formatting codes (for connectors, parentheses, etc.)
used in the logic statements that are ASCII codes below 0x41. See
Table 9-10 Event list
Events
Parenthesis
External Input
Pre-Deposit
In Deposit
Post-Deposit
Non Deposit
Ready
Crucible Switch
PreCond Rise
PreCond Soak
9 - 30
1st Min Max
numeric
numeric
(1 Byte)
(Integer)
(XXX)
Input # 1 28
Cygnus 2 Operating Manual
2nd Min Max
(YYY)
.
Table 9-10
Logic Logic
Code Code
Negated
0x41 0xBF
0x42 0xBE
0x43 0xBD
0x44 0xBC
0x45 0xBB
0x46 0xBA
0x47 0xB9
0x48 0xB8
0x49 0xB7
