9.4.8 Query Sensor Parameter

Command = QS <Command ID> <Sensor Number>
Command ID = <Byte> See
Sensor Number = <Byte> Sensor number 1 - 6
Response = <Integer> | <Float>
Type of response depends on command ID, see "Data Type" column in

9.4.9 Update Sensor Parameter

Command: = US <Command ID> <Sensor Number> <Parameter Value>
Command ID = <Byte> See
Sensor Number = <Byte> Sensor number 1 - 6
Parameter Value = <Integer> | <Float> Type of value depends on command ID,
see Data Type column in
Response = None (Just header and trailer)
Table 9-7 Sensor parameters
QS
& Name
US
(Units)
Cmnd
ID
1 (Sensor) Shutter
(0x01)
Out(put)
Sensor Type
2
(0x02)
3 (Sensor) Switch
(0x03)
Out(put)
4 Auto-Z
(0x04)
9 - 22
Table
Table 9-7
Table 9-7.
Range:
Low Limit/
High Limit/ Data Type
Default
0/ 38/ 0 Integer
0/ 4/ 0 Encode
0/ 38/ 0 Integer
0/ 1/ 0 Encode
9-7.
Notes
0 = not defined
Update not allowed if the Sensor is running. Not
accepted if output in use by other hardware
0 = Single 1 = XtalTwo
2 = XtalSix 3 = Xtal12
4 = Generic
0 = not defined
Gray font if Sensor Type =
Single
0 = No, 1 = Yes
Cygnus 2 Operating Manual
Table 9-7.
Update Restrictions
and Display Notes
Update not allowed if
the Sensor is running.
Update not allowed if
the Sensor is running.
Not accepted if output
in use by other
hardware.
