FOREWORD

Dear Customer,

Thank you for selecting your new Kia vehicle.

As a global car manufacturer focused on building high-quality vehicles with excep-

tional value, Kia is dedicated to providing you with a customer service experience that

exceeds your expectations.

This Owner's Manual will acquaint you with the operation of features and equipment

that are either standard or optional on this vehicle, along with the maintenance needs

of this vehicle. Therefore, you may find certain descriptions and illustrations not appli-

cable to your vehicle. You are advised to read this publication carefully and follow the

instructions and recommendations. Please always keep this manual in the vehicle for

your and any subsequent owner's reference.

If you need technical assistance, visit an authorised Kia dealership where factory

trained technicians, recommended special tools, and genuine Kia replacement parts

can be provided.

All information contained in this Owner's Manual was accurate at the time of publica-

tion. However, as Kia continues to make improvements to its products, the company

reserves the right to make changes to this manual or any of its vehicles at any time

without notice and without incurring any obligations.

Please drive safely, and enjoy your Kia vehicle!

2022 Kia Corporation

All rights reserved. May not be reproduced or translated in whole or in part without the written consent of Kia

Corporation.

Printed in Korea

Table of Contents

Advertisement

Chapters

Table of Contents

Need help?

Need help?

Do you have a question about the CARNIVAL 2023 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kia CARNIVAL 2023

Page 1 Please drive safely, and enjoy your Kia vehicle! 2022 Kia Corporation All rights reserved. May not be reproduced or translated in whole or in part without the written consent of Kia Corporation. Printed in Korea...
Page 3 How to use this manual WARNING We want to help you get the greatest A WARNING indicates a situation in possible driving pleasure from your which harm, serious bodily injury or vehicle. Your Owner's Manual can assist death could result if the warning is you in many ways.
Page 5: Table Of Contents
Table of Contents Introduction Your vehicle at a glance Safety features of your vehicle Features of your vehicle Infotainment system Driving your vehicle What to do in an emergency Maintenance Specifications & Consumer information Abbreviation Index...
Page 7: Introduction
Introduction Introduction Fuel requirements ................1-2 Vehicle modifications..............1-6 Vehicle break-in process ...............1-7 Risk of burns when parking or stopping vehicle .......1-7 Vehicle handling instructions ............1-8...
Page 8: Fuel Requirements
Octane Number) 95/AKI (Anti Knock designed to use leaded petrol. When you Index) 91 or higher. are going to use leaded petrol, Kia rec- You may use unleaded petrol with an ommends to visit an authorised Kia octane rating of RON 91~94/AKI 87~90...
Page 9 Fuel additives eration, engine stalling, catalyst melting, Kia recommends that you use unleaded abnormal corrosion, life cycle reduction, petrol which has an octane rating of etc. RON (Research Octane Number) 95/AKI...
Page 10 僅 Below -5°C (23°F) ... Winter type diesel sional workshop along with information fuel. on how to use them. Kia recommends to Watch the fuel level in the tank very visit an authorised Kia dealer/service carefully : If the engine stops through partner.
Page 11 Introduction Fuel requirements Biodiesel (Except New Zealand/ Biodiesel (for New Zealand) Thailand/Indonesia/Malaysia) Commercially supplied diesel blends of no more than 7% biodiesel, commonly Commercially supplied diesel blends of known as "B7 diesel" may be used in no more than 7% biodiesel, commonly your vehicle if biodiesel meets EN 14214 known as "B7 diesel"...
Page 12: Vehicle Modifications
Introduction Vehicle modifications Biodiesel (for Thailand/Indone- Vehicle modifications sia/Malaysia) This vehicle should not be modified. Use commercially supplied diesel blends Modification of your vehicle could affect containing up to 7% biodiesel and meet- its performance, safety or durability and ing EN14214 or equivalent specifications, may even violate governmental safety commonly known as “B7 diesel", for your and emissions regulations.
Page 13: Vehicle Break-In Process
Introduction Vehicle break-in process Vehicle break-in process Risk of burns when parking or stopping vehicle By following a few simple precautions for the first 1,000 km (600 miles) you WARNING may increase the performance, econ- 僅 Do not park or stop the vehicle near omy and life of your vehicle.
Page 14: Vehicle Handling Instructions
Introduction Vehicle handling instructions Vehicle handling instructions As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control, an accident or vehicle rollover. Specific design characteristics (higher ground clearance, track, etc.) give this vehicle a higher centre of gravity than other types of vehicles.
Page 15: Your Vehicle At A Glance
Your vehicle at a glance Your vehicle at a glance Exterior overview ................2-2 Interior overview ................2-4 Instrument panel overview ............2-6 Engine compartment..............2-8...
Page 16: Exterior Overview
Your vehicle at a glance Exterior overview Your vehicle at a glance Exterior overview Front view OKA4010001N * The actual shape may differ from the illustration. 1. Bonnet 4-51 2. Head lamp 4-123, 8-62, 8-63 3. Front fog lamp 8-63 4.
Page 17 Your vehicle at a glance Exterior overview 12.Roof rack 4-182 Rear view OKA4011002L * The actual shape may differ from the illustration. 1. Doors 4-16 2. Sliding doors 4-24 3. Fuel filler door 4-54 4. Rear combination lamp 8-61, 8-64, 8-66 5.
Page 18: Interior Overview
Your vehicle at a glance Interior overview Interior overview OKA4011003R * The actual shape may differ from the illustration. 1. Inside door handle 4-17 2. Power window switch 4-47 3. Central door lock switch 4-18 4. Central door unlock switch 4-18 5.
Page 19 Your vehicle at a glance Interior overview 14.Power sliding door OFF button 4-28 15.Steering wheel 4-62 16.Steering wheel tilt/telescopic lever 4-63 17.Instrument fuse panel 8-46 18.Shift dial/Shift lever 6-16, 6-22 19.Bonnet release lever 4-51 20.Seat 21.Seat position memory system 4-22...
Page 20: Instrument Panel Overview
Your vehicle at a glance Instrument panel overview Instrument panel overview OKA4011004R * The actual shape may differ from the illustration. 1. Driver's front air bag 3-75 2. Horn 4-65 3. Instrument cluster 4-70 4. Light control/turn signals lever 4-123 5.
Page 21 Your vehicle at a glance Instrument panel overview 14.AUTO HOLD button 6-36 15.Front seat warmer/air ventilation seat switch 4-172, 4-173 16.Steering wheel heater button 4-64 17.Parking Safety button 4-115, 4-118 18.Parking/View button 4-107, 4-110 19.Centre console storage box 4-168 20.Power outlet 4-176 21.Glove box 4-169...
Page 22: Engine Compartment
Your vehicle at a glance Engine compartment Engine compartment Smartstream G3.5 GDi/MPI (Petrol) OKA4071002R Smartstream D2.2 (Diesel) OKA4071001R * The actual engine room in the vehicle may differ from the illustration. 1. Engine coolant reservoir 8-23 2. Brake fluid reservoir 8-26 3.
Page 23 Safety features of your vehicle Safety features of your vehicle Seat....................3-3 僅 Feature of Seat Leather................3-10 僅 Front seat adjustment for manual seat..........3-10 僅 Front seat adjustment for power seat ........... 3-11 僅 Headrest (for front seat) ................3-13 僅...
Page 24 Safety features of your vehicle 僅 Why didn't my air bag go off in a collision? (Inflation and non-inflation conditions of the air bag)..........3-82 僅 SRS care ......................3-86 僅 Additional safety precautions..............3-86 僅 Adding equipment to or modifying your air bag-equipped vehicle........................3-87 僅...
Page 25: Safety Features Of Your Vehicle
Safety features of your vehicle Seat Safety features of your vehicle Seat 11 seats Front seat OKA4031001R * The actual feature in the vehicle may differ from the illustration. Front seat 1 Forward and backward 2 Seatback angle 3 Seat cushion tilt 4 Seat cushion height 5 Lumbar support 6 Driver position memory system...
Page 26 Safety features of your vehicle Seat Rear seat OKA4031002L 2nd, 3rd row seat 9 Forward and backward 10 Seatback angle 11 Headrest 4th row seat 12 Headrest 13 Seat sinking...
Page 27 Safety features of your vehicle Seat 7,8 seats Front seat OKA4031003R * The actual feature in the vehicle may differ from the illustration. * There is no centre seat on rear 2nd row for vehicle with 7 seats. Front seat 1 Forward and backward 2 Seatback angle 3 Seat cushion tilt...
Page 28 Safety features of your vehicle Seat Rear seat OKA4031143L * There is no centre seat on rear 2nd row for vehicle with 7 seats. 2nd row seat 9 Forward and backward 10 Seatback angle 11 Walk-in lever 12 Headrest 3rd row seat 13 Seatback angle/folding 14 Seat sinking 15 Headrest...
Page 29 Safety features of your vehicle Seat Rear seat (Relaxion seat) (if equipped) OKA4031118L 2nd row seat 16 Left and right 17 Forward and backward 18 Seatback angle 19 Leg support 20 Seat cushion height 21 Relaxion seat adjustment 22 Relaxion seat one touch 23 Headrest 3rd row seat 24 Seatback angle/folding...
Page 30 Safety features of your vehicle Seat Serious or fatal internal injuries could WARNING result. The driver must advise the pas- Loose objects senger to keep the seatback in an Loose objects in the driver's foot area upright position whenever the vehicle is could interfere with the operation of the in motion.
Page 31 Safety features of your vehicle Seat 僅 In order to avoid unnecessary and WARNING perhaps severe air bag injuries, After adjusting the seat, always check always sit as far back as possible from that it is securely locked into place by the steering wheel whilst maintaining attempting to move the seat forward or comfortable control of the vehicle.
Page 32: 僅 Feature Of Seat Leather
Safety features of your vehicle Seat Feature of Seat Leather (if Front seat adjustment for man- equipped) ual seat (if equipped) Our car seats are upholstered with a The front seat can be adjusted by using combination of artificial and genuine the control levers located on the outside leather.
Page 33: 僅 Front Seat Adjustment For Power Seat
Safety features of your vehicle Seat 僅 To lower the seat cushion, push down Reclining seatback the lever several times. 僅 To raise the seat cushion, pull up the lever several times. Front seat adjustment for power seat (if equipped) The front seat can be adjusted by using the control switches located on the out- side of the seat cushion.
Page 34 Safety features of your vehicle Seat Forward and backward adjust- Changing seat cushion tilt and ment height OKA4031008R OKA4031010R To move the seat forward or backward: To change the height of the seat: 1. Push the control switch forward or 1.
Page 35: 僅 Headrest (For Front Seat)
Safety features of your vehicle Seat Sliding forward or rearward: 僅 To move the front passenger seat for- ward, press the switch (1). To move the front passenger seat rearward, press the switch (2). Angle adjustment: 僅 To recline the front passenger seat forward, press the switch (3).
Page 36 Safety features of your vehicle Seat WARNING CAUTION 僅 For maximum effectiveness in case of When there is no occupant in the rear an accident, the headrest should be seats, adjust the height of the headrest adjusted so the middle of the head- to the lowest position.
Page 37 Safety features of your vehicle Seat Removing headrest Type A ODEEV058008NR Forward and backward adjust- OKA4031016R ment Type B OKA4030015L OKA4031017R The headrest may be adjusted forward To remove the headrest: to 4 different positions by pulling the 1. Recline the seatback (2) with the headrest forward to the desired position.
Page 38: 僅 Seatback Pocket
Safety features of your vehicle Seat Reinstalling headrest Seatback pocket There is a double pocket (1) in the front Type A seat back for storing simple books or atlases, USB charger (2), and the hook (if equipped) for rear passengers. OKA4031018R Type B OKA4030020R...
Page 39 Safety features of your vehicle Seat Rear seat adjustment (11 seats) Walk-in seat (2nd row seat) Forward and backward adjust- 2nd row outboard seat ment (2nd, 3rd row seat) OKA4030098 OKA4030021R To move the seat forward or backward: 1. Pull the seat slide adjustment lever up and hold it.
Page 40 Safety features of your vehicle Seat 3. Release the lever or strap and make WARNING sure the seatback is locked in place. Never attempt to adjust the 2nd row (The lever MUST return to its original seat whilst the vehicle is moving or the position for the seatback to lock.) seat is occupied as the seat may sud- Seatback angle (2nd, 3rd row...
Page 41 Safety features of your vehicle Seat Folding the rear seat (3rd row WARNING seat) 僅 The seatback recline angle of the 2nd, The rear seatbacks can be folded to 3rd row centre seats in a 11 seater facilitate carrying long items or to vehicle is limited.
Page 42 Safety features of your vehicle Seat 2. Set the front seatback to the upright 3. Maintain a firm hold of the lower part position and if necessary, slide the of the centre seat and fold toward the front seat forward. driver side seat (3).
Page 43 Safety features of your vehicle Seat 4. Firmly press on the seatback to Stowing the rear seat (4th row securely stow the seats in place. seat) The rear seat can be folded and stowed in the luggage compartment to provide additional cargo space.
Page 44 Safety features of your vehicle Seat 僅 If the 4th row seatback's folding strap WARNING is pulled whilst either passenger, pet, Cargo loading or luggage is in the seat, the folded Make sure the engine is off, the shift 4th row seats will cause harm to the lever or dial is in P (Park) position, and occupant or luggage.
Page 45 Safety features of your vehicle Seat Full flat seats (if equipped) NOTICE 僅 When returning the seats to upright positions, reinstall the headrests to original positions. 僅 Do not put heavy pressure nor load heavy cargo on the seatback when in full flat position.
Page 46 Safety features of your vehicle Seat To recline the seatback: Seatback angle (2nd, 3rd row seat) 1. Pull up the seatback recline lever (for 2nd row outboard seat) or strap (for 2nd row outboard seat 2nd row centre or 3rd row seat). 2.
Page 47 Safety features of your vehicle Seat 3rd row seat WARNING Never attempt to adjust the 2nd row seat whilst the vehicle is moving or the seat is occupied as the seat may sud- denly move and cause the passenger on the seat to be injured.
Page 48 Safety features of your vehicle Seat 6. Return the rear seat belt to the proper 3. Slide the seat to the farthest forward. position. 4. Fold the seat back by pulling up the reclining lever or strap. 5. Pull the removal lever or strap and lift the rear portion of the seat cushion.
Page 49 Safety features of your vehicle Seat 4. Make sure the green mark on the rear Installing the seat (2nd row seat seat cushion frame is visible and the for 7, 8 seats) catches are locked in position by mov- 1. Put the front anchor strikers along the ing the seat forward and backward or front anchors on the floor.
Page 50 Safety features of your vehicle Seat WARNING Installing or removing the seat OKA4030123L OYP034233N 僅 Do not install or remove the 2nd row seat if there are occupants in the 3rd row seats, as this may injure occu- pants. 僅 Rise both side seatback up before installing the tumble seat.
Page 51 Safety features of your vehicle Seat 4. Make sure the green mark on the rear Installing the tumble seat in seat cushion frame is visible and the opposite direction catches are locked in position by mov- 1. Put the front anchor strikers along the ing the seat forward and backward or rear anchors on the floor.
Page 52 Safety features of your vehicle Seat 3. Stow the seat by pushing down firmly. Stowing the rear seat (3rd row) The rear seat can be folded and stowed in the luggage compartment to provide additional cargo space. To stow the rear seat: 1.
Page 53 Safety features of your vehicle Seat To use the rear seat: 4. Pull out and hold the folding strap. 1. Lift the seat by pulling up the stowing lever. OKA4030100 5. Hold the seat back when you adjust the seat back angle until it clicks into OKA4031046R place and then release the folding 2.
Page 54: 僅 Rear Seat Adjustment (11 Seats)
Safety features of your vehicle Seat WARNING WARNING Cargo 3rd row seat 僅 Do not place heavy objects in the rear 3rd row occupants should always seats, since they cannot be properly remain in the centre of the seat cushion secured and may hit vehicle occu- so the occupants' heads are protected pants in a frontal collision.
Page 55 Safety features of your vehicle Seat Forward and backward adjust- Left and right adjustment (Relax- ment (Relaxion seat) ion seat) OKA4030035 OKA4030036 To move the seat forward or backward: To move the seat left side or right side: 1. Pull the seat slide adjustment lever up 1.
Page 56 Safety features of your vehicle Seat 2. Adjust the angle (1) and length (2) of Seatback angle (Relaxion seat) the leg support whilst holding the leg support. When using the leg rest, move the seat to the inner position, and then toward the back. If the seat is not moved far back, it may come in contact with the first row seat.
Page 57 Safety features of your vehicle Seat Relaxion seat OKA4030097 If you press the one touch switch (1), the ODL3039016 seat is automatically adjusted to the Relaxion seats distribute body pressure relaxion seat position. and concentrated weight on specific 僅 The seat cushion and seatback angle body parts that occur whilst sitting in the will be adjusted.
Page 58 Safety features of your vehicle Seat Relaxion function Return function OKA4030166N OKA4030164N OKA4030163N OKA4030167N [A]: Moves simultaneously [A]: Moves simultaneously If you push down the one touch switch If you push down the one touch switch (1), the seat will be adjusted to the relax- (1), the seat will return to the previous ion position.
Page 59: 僅 Headrest (For Rear Seat)
Safety features of your vehicle Seat Headrest (for rear seat) WARNING The rear seat(s) is equipped with head- 僅 For maximum effectiveness in case of rests in all the seating positions for the an accident, the headrest should be occupant's safety and comfort. adjusted so the middle of the head- rest is at the same height as the 11 seats...
Page 60 Safety features of your vehicle Seat 2nd row, 3rd row seat (for 11 seats) CAUTION When there is no occupant in the rear seats, adjust the height of the headrest to the lowest position. The rear seat headrest can reduce the visibility of the rear area.
Page 61 Safety features of your vehicle Seat 1. Push and hold the release button (2) 3rd row seat (for 7,8 seats) on the headrest support. 2. Lower the headrest to the desired position (3). Removal and re-installation 2nd row seat (for 7,8 seats) OKA4030033L 4th row seats (for 11 seats) OKA4030032L...
Page 62 Safety features of your vehicle Seat A headrest installed reversely could Forward and backward adjust- increase whiplash injury during rear ment (if equipped) impact. NOTICE Do not remove the 2nd row outboard headrest. It cannot be removed com- pletely due to the cable installed for headrest auto folding function.
Page 63: Seat Belts
Safety features of your vehicle Seat belts Armrest (if equipped) Seat belts Seat belts are designed to bear upon the bony structure of the body, and should be worn low across the front of the pel- vis, chest and shoulders. Seat belt restraint system WARNING 僅...
Page 64 Safety features of your vehicle Seat belts ous and you may not be protected by WARNING the seat belt properly. Seat belts are designed to bear upon the 僅 Do not unfasten the seat belt and do bony structure of the body, and should not fasten and unfasten the seat belt be worn low across the front of the pel- repeatedly whilst driving.
Page 65 Safety features of your vehicle Seat belts 僅 If you start to drive without the Rear passenger's seat belt warn- driver's seat belt fastened, when you ing (if equipped) drive under 20 km/h (12 mph) or stop, 7/8 seats the warning light will appear. When you drive 20 km/h (12 mph) or faster, the warning light will blink and warn- ing chime will sound for approxi-...
Page 66 Safety features of your vehicle Seat belts 僅 If you unfasten the seat belt when you For Australia/New Zealand - 8 drive over 20 km/h (12 mph), the seat seats (For 2nd row centre and 3rd belt warning chime will sound for row all seat) approximately 35 seconds and the 僅...
Page 67 Safety features of your vehicle Seat belts Seat belt - Driver's 3-point system WARNING with emergency locking retractor You should place the lap belt portion as low as possible and snugly across your Fastening the seat belt hips, not on your waist. If the lap belt is located too high on your waist, it may increase the chance of injury in the event of a collision.
Page 68 Safety features of your vehicle Seat belts * The 2nd-row centre seat is only avail- When using the rear centre seat belt, the able in 8 seating positions. buckle with the "CENTER" mark must be used. 3rd row (7, 8 seats) OKA4030139L OKA4030137L WARNING...
Page 69 Safety features of your vehicle Seat belts When it is released, the belt should auto- Release the button to lock the anchor matically draw back into the retractor. into position. Try sliding the height adjuster to make sure that it has locked If this does not happen, check the belt to into position.
Page 70 Safety features of your vehicle Seat belts 3-point rear centre belt (3rd row centre seat for 7, 8 seats) (if equipped) To fasten the rear centre belt 1. Pull out the mini tongue from hole on the belt assembly cover (1) and then slowly pull the seat belt out from the retractor.
Page 71 Safety features of your vehicle Seat belts There will be an audible "click" when the tab locks in the buckle. The seat belt automatically adjusts to the proper length only after the lap belt is adjusted manually so that it fits snugly around your hips, if you lean forward in a slow, easy motion, the belt will extend and let you move around.
Page 72 Safety features of your vehicle Seat belts [A]: Shorten, [B]: Lengthen 2-point rear centre belt (2nd, 3rd, 4th row centre seat for 11 seats) The belt should be placed as low as pos- (if equipped) sible on your hips, not on your waist. If the belt is too high, it could increase the possibility of you being injured in an To fasten the rear centre belt...
Page 73 Safety features of your vehicle Seat belts 3rd row seat (7, 8 seats) To unfasten the rear centre belt When you want to release the seat belt, press the button (1) in the locking buckle. OKA4030150L The rear seat belt buckles can be stowed in the pocket between the rear seatback OSP2I039049 and cushion when not in use.
Page 74 Safety features of your vehicle Seat belts 3rd row centre seat (7, 8 seats) Pre-tensioner seat belt OKA4030093 OSP2I039024 3rd row outboard seat (7, 8 seats) Your vehicle is equipped with driver's and front passenger's pre-tensioner seat belts. The purpose of the pre-tensioner is to make sure that the seat belts fit tightly against the occupant's body in certain collisions.
Page 75 Safety features of your vehicle Seat belts WARNING WARNING For your safety, be sure that the belt To obtain maximum benefit from a pre- webbing is not loose or twisted and tensioner seat belt: always sit properly on your seat. 1.
Page 76: 僅 Seat Belt Precautions
Kia recommends the vehicle is in ON position, or if it to visit an authorised Kia dealer/ser- remains ON after appearing for approxi- vice partner. mately 3~6 seconds, or if it appears...
Page 77 Safety features of your vehicle Seat belts Infant or small child Larger children You should be aware of the specific Children who are too large for child requirements in your country. Child and/ restraint systems should always occupy or infant seats must be properly placed the rear seat and use the available lap/ and installed in the rear seat.
Page 78: 僅 Care Of Seat Belts
Safety features of your vehicle Seat belts rear seat or if the front seat is in a Pregnant women reclined position. The use of a seat belt is recommended for pregnant women to lessen the WARNING chance of injury in an accident. When a Riding with a reclined seatback seat belt is used, the lap belt portion increases your chance of serious or fatal...
Page 79: Child Restraint System (Crs)
Child Restraint Kia recommends to consult an System differs among countries, so you authorised Kia dealer/service partner. should be aware of the specific require- ments in your country, and where you are travelling.
Page 80: 僅 Using A Child Restraint System (Crs)
僅 After an accident, have the system 僅 Rearward-facing CRS checked by a professional workshop. 僅 Forward-facing CRS Kia recommends to visit an authorised 僅 Booster seat Kia dealer/service partner. They are classified according to the child's age, height and weight.
Page 81 Safety features of your vehicle Child restraint system (CRS) Rearward-facing Child Restraint Forward-facing Child Restraint System System ODEEV058035NR ODEEV058036NR A rearward-facing Child Restraint Sys- A forward-facing Child Restraint System tem provides restraint with the seating provides restraint for the child's body surface against the back of the child.
Page 82: 僅 Securing A Child Restraint System With A Lap/Shoulder Belt
Safety features of your vehicle Child restraint system (CRS) When installing a Child Restraint Sys- Installing a Child Restraint Sys- tem, adjust the vehicle seat and seat- tem (CRS) back (up and down, forward and WARNING rearward) so that your child fits in the Child Restraint System in a comfort- Before installing your Child Restraint able manner.
Page 83: 僅 Isofix Anchorage And Top-Tether Anchorage
Safety features of your vehicle Child restraint system (CRS) Restraint System, following the Child If your Child Restraint System manufac- Restraint System manufacturer's turer recommends the use of a top- instructions. tether with the lap/shoulder belt. Make sure the seat belt webbing is To remove the Child Restraint System, not twisted.
Page 84 Safety features of your vehicle Child restraint system (CRS) 11 seats WARNING Do not attempt to install a Child Restraint System using ISOFIX anchor- ages in the rear centre seating position. There are no ISOFIX anchorages pro- vided for this seat. Using the outboard seat anchorages, for the CRS installation on the rear centre seating position, can damage the anchorages.
Page 85 Safety features of your vehicle Child restraint system (CRS) NOTICE WARNING Take the following precautions when When installing CRS in centre seat (For 8 using the ISOFIX system: seats), the seat belt buckle should be extracted from the seat cushion before- 僅...
Page 86 Safety features of your vehicle Child restraint system (CRS) 3rd row seat (7, 8 seats) Securing a Child Restraint System seat with "Top-tether Anchorage" system 2nd row outboard seat (11 seats) OKA4030108L Child restraint system tether anchorages are located on the back of the rear cush- ions.
Page 87 Safety features of your vehicle Child restraint system (CRS) 1. Route the child restraint system top WARNING tether over the seatback. For vehicles Do not use the relaxion mode after with adjustable headrest, route the installing the Child Restraint System or top tether under the headrest and install the Child Restraint System in the between the headrest posts, other-...
Page 88 Safety features of your vehicle Child restraint system (CRS) Suitability of each seating position for belted & ISOFIX Child Restraint Systems (CRS) according to UN regulations (7 & 8 Passenger) 僅 Yes : Suitable for fitment of the designated category of CRS 僅...
Page 89 Safety features of your vehicle Child restraint system (CRS) Suitability of each seating position for belted & ISOFIX Child Restraint Systems (CRS) according to UN regulations (11 Passenger) 僅 Yes : Suitable for fitment of the designated category of CRS 僅...
Page 90: Air Bag - Supplemental Restraint System
Safety features of your vehicle Air bag - supplemental restraint system Air bag - supplemental restraint system 11 seats OKA4030061R * The actual feature in the vehicle may differ from the illustration. 1 Driver's front air bag 2 Passenger's front air bag 3 Side air bag* 4 Curtain air bag* 5 Driver's knee air bag...
Page 91 Safety features of your vehicle Air bag - supplemental restraint system 7, 8 seats OKA4030102R * There is no centre seat on rear 2nd row for vehicle with 7 seats. * The actual feature in the vehicle may differ from the illustration. 1 Passenger's front air bag 2 Driver's front air bag 3 Side air bag*...
Page 92: 僅 How Does The Air Bag System Operate
The determining, factors are shop. Kia recommends to visit an not limited to those mentioned above. authorised Kia dealer/service partner. 僅 The front air bags will completely 僅...
Page 93 Safety features of your vehicle Air bag - supplemental restraint system 僅 There are even circumstances WARNING under which contact with the steer- 僅 When the air bags deploy, the air bag ing wheel air bag can cause fatal related parts in the steering wheel injuries, especially if the occupant is and/or instrument panel and/or in positioned excessively close to the...
Page 94: 僅 Air Bag Warning And Indicator
Safety features of your vehicle Air bag - supplemental restraint system Inflation of side and/or curtain air WARNING bags could cause serious injury or 僅 Never place a rear facing child death to an infant or child. restraint in the front passenger seat, unless the passenger-side air bag is Air bag warning and indicator deactivated.
Page 95: 僅 Srs Components And Functions
SRS. In this case, have the system inspected by a professional workshop. Kia recom- mends to visit an authorised Kia dealer/ service partner. 僅 The light does not turn on briefly when you turn the vehicle ON.
Page 96 Safety features of your vehicle Air bag - supplemental restraint system Driver's front air bag (2) Passenger's front air bag OMQ4A030342 ODEEV058051NR Upon deployment, tear seams molded WARNING directly into the pad covers will separate 僅 Do not install or place any accessories under pressure from the expansion of (drink holder, CD holder, sticker, etc.) the air bags.
Page 97 SRS is not working prop- erly. In this case, have the system inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. 僅 Before you replace a fuse or discon- nect a battery terminal, turn the igni-...
Page 98 Kia recom- inflates. Always follow the precautions mends to visit an authorised Kia about seat belts, air bags and occupant dealer/service partner. safety contained in this manual.
Page 99 All occupants should sit upright with the seat back in an upright posi- Kia recommends to visit an authorised tion, centre on the seat cushion with Kia dealer/service partner. their seat belt on, legs comfortably 僅...
Page 100: 僅 Side Air Bag
Safety features of your vehicle Air bag - supplemental restraint system Side air bag (if equipped) WARNING Your vehicle is equipped with a side air Do not allow the passengers to lean their bag in each front seat. heads or bodies onto doors, put their arms on the doors, stretch their arms out of the window, or place objects between the doors and passengers when they are...
Page 101 僅 If the seat or seat cover is damaged, have the system serviced by a profes- sional workshop. Kia recommends to visit an authorised Kia dealer/service partner. WARNING OKA4031071R No attaching objects 僅...
Page 102 If necessary, have the system serviced 僅 Also, both side of the side air bags by a professional workshop. Kia rec- deploy in certain rollover situations. ommends to visit an authorised Kia dealer/service partner.
Page 103: 僅 Air Bag Collision Sensors
Safety features of your vehicle Air bag - supplemental restraint system Air bag collision sensors OKA4032075N OKA4031076R OKA4032078N OKA4030077 OKA4030079 * The actual shape and position of sensors may differ from the illustration. 1 Supplemental Restraint System (SRS) control module/rollover sensor* 2 Front impact sensor 3 Side impact sensors (B,C-pillar) 4 Side pressure sensors (front door)
Page 104 僅 Your vehicle has been designed to absorb impact and deploy the air bag(s) in certain collisions. Use only Kia Genuine Parts or those of an equivalent standard to install bumper guards or replace a bumper. If not, it may adversely affect your...
Page 105 Safety features of your vehicle Air bag - supplemental restraint system Although the front air bags (driver's and Side and curtain air bags (if front passenger's air bags) are designed equipped) to inflate only in frontal collisions, they also may inflate in other types of colli- sions if the front impact sensors detect a sufficient impact.
Page 106 Safety features of your vehicle Air bag - supplemental restraint system Air bag non-inflation conditions 僅 Front air bags may not inflate in side impact collisions, because occupants 僅 In certain low-speed collisions the air move to the direction of the collision, bags may not deploy.
Page 107 Safety features of your vehicle Air bag - supplemental restraint system 僅 Just before impact, drivers often NOTICE brake heavily. Such heavy braking However, side and/or curtain air bags lowers the front portion of the vehicle may inflate when the vehicle is rolled causing it to "ride"...
Page 108 僅 If the air bags inflate, have the system replaced by a professional workshop. 僅 Each seat belt is designed to Kia recommends to visit an authorised restrain one occupant. If more than Kia dealer/service partner. one person uses the same seat belt, they could be seriously injured or 僅...
Page 109 Safety features of your vehicle Air bag - supplemental restraint system 僅 Do not use any accessories on seat WARNING belts. Devices claiming to improve 僅 Sitting improperly or out of position occupant comfort or reposition the can cause occupants to be shifted too seat belt can reduce the protection close to a deploying air bag, strike the provided by the seat belt and increase...
Page 110 Safety features of your vehicle Air bag - supplemental restraint system Air bag warning labels Air bag warning labels are attached to alert the passengers of potential risk of air bag system. OKA4030087R OKA4030153R Note that these government warnings focus on the risk of children. We also want you to be aware of the risks adults are exposed to which have been described in previous pages.
Page 111 Features of your vehicle Features of your vehicle Keys ....................4-7 僅 Record your key number................4-7 僅 Battery replacement ..................4-7 僅 Remote key......................4-8 僅 Smart key......................4-10 僅 Theft-alarm system..................4-12 僅 Immobiliser system ..................4-14 Door locks..................4-16 僅...
Page 112 Features of your vehicle Smart Sliding Door with Auto Open.......... 4-31 僅 How to use the Smart sliding door with auto open ......4-31 僅 How to deactivate the smart sliding door with auto open function using the smart key ..............4-32 僅...
Page 113 Features of your vehicle 僅 Closing the bonnet ..................4-53 Fuel filler door................4-54 僅 Opening the fuel filler door ..............4-54 僅 Closing the fuel filler door................. 4-55 Dual sunroof.................4-57 僅 Sunshade (Front/Rear) ................4-58 僅 Tilt open/close (Front)................. 4-58 僅...
Page 114 Features of your vehicle Warning and indicator lights............. 4-95 僅 Warning lights ....................4-95 僅 Indicator lights....................4-103 Rear View Monitor (RVM)............4-107 僅 Rear View Monitor settings ..............4-107 僅 Rear View Monitor operation..............4-108 僅 Rear View Monitor Malfunction and limitations......4-109 Surround View Monitor (SVM)..........
Page 115 Features of your vehicle 僅 Operating rear window wiper and washer switch......4-133 僅 Auto rear wiper .....................4-133 僅 Heated washer nozzle................4-133 Welcome system ................ 4-134 Interior lights................4-135 僅 Automatic turn off function..............4-135 僅 Map lamp......................4-136 僅 Room lamp......................4-137 僅 Luggage room lamp ...................4-137 僅...
Page 116 Features of your vehicle Windscreen defrosting and defogging........4-163 僅 Defogging inside windscreen with manual climate control system .......................4-163 僅 Defrosting outside windscreen with manual climate control system .......................4-163 僅 Defogging inside windscreen with automatic climate control 4-164 僅 Defrosting outside windscreen with automatic climate control.......................
Page 117: Features Of Your Vehicle
Record your key number The key code number is stamped on the key code tag attached to the key set. If you lose your keys, Kia recommends to contact an authorised Kia dealer/ser- vice partner. Remove the key code tag and store it in a safe place.
Page 118 Kia recommends ing lights will not operate. If all doors, to contact an authorised Kia dealer/ engine bonnet and tailgate are closed service partner. after the lock button is pressed, the haz- 僅...
Page 119 NOTICE The transmitter will not work if any of WARNING the following occurs: Kia recommends to use parts for 僅 The ignition key is in the ignition replacement from an authorised Kia switch. dealer/service partner. If an aftermarket 僅 You exceed the operating distance key is used, the ignition switch may not limit (about 10 m [30 feet]).
Page 120 Features of your vehicle Keys Smart key (if equipped) Unlock (2) With a smart key, you can lock or unlock All doors are unlocked if the unlock but- a door and even start the engine without ton is pressed. inserting the key. The hazard warning lights will blink twice to indicate that all doors are A Type...
Page 121 Tow the vehi- With the smart key, the driver can move cle, if necessary, contact a profes- the vehicle forward or backward using sional workshop. Kia recommends to the forward/backward button (7, 8) on contact an authorised Kia dealer/ser- the smart key.
Page 122: 僅 Theft-Alarm System
僅 A maximum of 2 smart keys can be Theft-alarm system (if equipped) registered to a single vehicle. If you Theft-alarm system is designed to pro- lose a smart key, Kia recommends to vide protection from unauthorised entry contact an authorised Kia dealer/ser- into the vehicle.
Page 123 Features of your vehicle Keys hazard warning lights won't oper- Armed stage ate and theft-alarm will not arm. Theft Alarm System goes to Armed After this, if the tailgate and engine stage after 30 seconds from the doors bonnet are closed, the hazard are locked by switch on a Outside Door warning lights will blink once.
Page 124 Have the system serviced by a professional Using the remote key workshop. Kia recommends to visit an 僅 The door unlock button is pressed. authorised Kia dealer/service partner. 僅 The engine is started.
Page 125 If the key is invalid, the engine will not start. NOTICE If you need additional keys or lose your To deactivate the immobiliser keys, Kia recommends to visit an system authorised Kia dealer/service partner. Change the ENGINE START/STOP but- ton to the ON position.
Page 126: Door Locks
Do not change, alter or adjust the immobiliser system because it could cause the immobiliser system to mal- function. In this case, have the system serviced by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. Malfunctions caused by improper alter-...
Page 127: 僅 Operating Door Locks From Inside The Vehicle
Features of your vehicle Door locks lock and the chime will sound for 3 sec- 2. Press the lever (1) located inside the onds if any of following occur: bottom part of the cover with a key or flat-head screwdriver. 僅...
Page 128 Features of your vehicle Door locks Passenger side WARNING Door lock malfunction If a power door lock ever fails to function whilst you are in the vehicle, try one or more of the following techniques to exit: 僅 Operate the door unlock feature repeatedly (both electronic and man- ual) whilst simultaneously pulling on the door handle.
Page 129 Features of your vehicle Door locks 僅 Be careful when opening doors and With the door lock button watch out for vehicles, motorcycles, bicycles or pedestrians approaching the vehicle in the path of the door. Opening a door when something is approaching can result in an accident to cause vehicle damage or serious injury.
Page 130: 僅 Door Lock/Unlock Features
Features of your vehicle Door locks Door lock/unlock features ( ) position. When the child safety lock is in the lock position, the rear The vehicle is equipped with door lock/ door will not open even though the unlock features for the safety and con- inner door handle is pulled.
Page 131: 僅 Rear Occupant Alert (Roa)
Features of your vehicle Door locks 1. Press the SETUP button of the info- Rear Occupant Alert (ROA) (if tainment system. equipped) 2. Press 'Vehicle → Convenience → Rear The Rear Occupant Alert (ROA) is pro- Occupant Alert' on the infotainment vided to help prevent exiting the vehicle system screen.
Page 132 2 button recalls the "2" memory system checked by a professional position. workshop. Kia recommends to visit an authorised Kia dealer/service partner. 僅 Whilst recalling the "2" memory posi- tion, pressing the SET or 2 button temporarily stops the adjustment of the recalled memory position.
Page 133: Driver Position Memory System
Features of your vehicle Driver Position Memory System 僅 Whilst recalling the stored positions, 僅 When pushing driving position mem- pressing one of the control buttons ory system button for the driver's seat, outside rearview 僅 When pushing driver's seat height mirror, or instrument panel illumina- adjustment switch tion will cause the movement of that...
Page 134: Sliding Door
Features of your vehicle Sliding door 僅 When the door is fully open, the door Sliding door will lock into an open position. To Opening the sliding door close the door, pull out the door han- dle (1) once. And then the sliding door will be closed (for power sliding doors).
Page 135: Power Sliding Door
Features of your vehicle Power sliding door Power sliding door (if CAUTION equipped) Sliding door hinge Power sliding door operating conditions The power sliding door operates when the gear is in P (Park) with the engine running. However, the power sliding door will operate regardless of the gear position when the engine is off.
Page 136: 僅 Operating The Power Sliding Door
Features of your vehicle Power sliding door 僅 Make sure the sliding door is fully INFORMATION opened and fixed before getting in or The left side sliding door does not open out of the vehicle. If the vehicle is if the fuel filler door is opened. parked on an incline, the sliding door may suddenly close.
Page 137 Features of your vehicle Power sliding door With the smart key From the front seats OKA4040036N OKA4041026R Press the left side (1) or right side (2) 1 Right side power sliding door button on the smart 2 Left side key for more than one second. The slid- Press either button for more than one ing door opens or closes automatically.
Page 138: 僅 Power Sliding Door Off Button
Features of your vehicle Power sliding door Automatic reverse Power sliding door OFF button (if equipped) During power sliding door operation if the power sliding door senses any obstacle, the sliding door will stop or will fully open. The automatic reverse fea- ture may not operate properly, or it may operate unexpectedly under the follow- ing circumstances:...
Page 139: Remote Power Doors And Tailgate
Features of your vehicle Remote power doors and tailgate Remote power doors and tail- WARNING gate When a child is in the rear seat, deacti- The sliding doors and tailgate can be vate the power sliding door by turning opened simultaneously by pressing the on the power sliding door OFF button.
Page 140: 僅 Closing Remote Power Doors And Tailgate
Features of your vehicle Remote power doors and tailgate 僅 Open tailgate and sliding doors WARNING Make sure there are no people or objects around before using the remote power doors and tailgate feature. INFORMATION 僅 If your vehicle is equipped with the remote window control feature, the driver side and passenger side win- dows will open or close at the same...
Page 141 Features of your vehicle Smart Sliding Door with Auto Open 僅 The smart key is in the vehicle. Smart Sliding Door with Auto Open (if equipped) On a vehicle equipped with a smart key, 1. Setting the sliding door can be opened using the To activate the smart sliding door with Smart sliding door with auto open sys- auto open, go to User Settings Mode and...
Page 142 Features of your vehicle Smart Sliding Door with Auto Open 3. Automatic opening How to deactivate the smart slid- ing door with auto open function using the smart key OKA4040474 The hazard warning lights will blink and chime will sound 2 times and then the OKA4040044N sliding door will open.
Page 143: Smart Sliding Door With Auto Open
Features of your vehicle Smart Sliding Door with Auto Open 僅 The alert stops at once if the smart NOTICE key is positioned outside the detecting 僅 If you press the door unlock button area during the Detect and Alert (5), the smart sliding door with auto stage.
Page 144: Tailgate
Features of your vehicle Tailgate 僅 If unlocked, the tailgate can be Tailgate opened by pressing the handle and WARNING pulling it up. Exhaust fumes 僅 Once the tailgate is opened and then closed, the tailgate locks automati- If you drive with the tailgate open, you cally.
Page 145: 僅 Emergency Tailgate Safety Release
Features of your vehicle Tailgate 2. Push the mechanical key to the right WARNING (1). Make sure your hands, feet and other 3. Push up the tailgate. parts of your body are safely out of the way before closing the tailgate. WARNING 僅...
Page 146: Power Tailgate
Features of your vehicle Power tailgate 4. Tailgate Auto Close OFF button Power tailgate (if equipped) 1. Power tailgate open/close button OKA4040031L 5. Power tailgate open/close button OKA4041445R 2. Power tailgate handle switch OKA4041038L When the power door ON/OFF button is OKA4041019L OFF, the power tailgate can be opened 3.
Page 147: 僅 Opening The Tailgate
Features of your vehicle Power tailgate WARNING WARNING Never leave children or animals unat- Make sure there are no people or tended in your vehicle. Children or ani- objects around the tailgate before open- mals might operate the power tailgate ing or closing the power tailgate.
Page 148: 僅 Closing The Tailgate
Features of your vehicle Power tailgate 僅 Press the tailgate handle switch carry- ing the smart key with you. OKA4040039L The tailgate will close automatically. OKA4041019L 僅 Press the Tailgate Auto Close OFF Closing the tailgate button to deactivate the Tailgate Auto Close function.
Page 149: 僅 Power Tailgate Opening Height Setting
Features of your vehicle Power tailgate Power tailgate opening height 2. Press the power tailgate close button for approximately 3 seconds. setting 3. After the beep sound appears, the The driver may set the height of a fully setup is finished. opened tailgate by following the below instruction.
Page 150 Kia recommends to visit an 僅 If the resistance is detected whilst authorised Kia dealer/service partner. opening the tailgate, it will stop and 僅...
Page 151: 僅 How To Reset The Power Tailgate
3 seconds. erly after the above procedure, have the system checked by a professional work- NOTICE shop. Kia recommends to visit an The smart tailgate with auto open func- authorised Kia dealer/service partner. tion does not operate when: NOTICE 僅...
Page 152 Features of your vehicle Smart Tailgate with Auto Open 1. Setting 3. Automatic opening To activate the smart tailgate with auto open function, go to User Settings Mode and select Smart Tailgate on the LCD display. For more details, refer to "User settings mode"...
Page 153 Features of your vehicle Smart Tailgate with Auto Open How to deactivate the Smart Tail- NOTICE gate with Auto Open function 僅 If you press the door unlock button using the smart key (5), the smart tailgate with auto open function will be deactivated temporar- ily.
Page 154: Tailgate Auto Close
Features of your vehicle Tailgate Auto Close 僅 The alert stops at once if the smart Tailgate Auto Close (if key is positioned outside the detecting equipped) area during the Detect and Alert On a vehicle equipped with a smart key, stage.
Page 155: 僅 Releasing Tailgate Auto Close
Features of your vehicle Tailgate Auto Close 2. Detect and Alert Releasing Tailgate Auto Close OKA4041476L OKA4040031L If you are positioned in the detecting If you press the Tailgate Auto close area (50~100 cm [20~40 in] behind release button with the tailgate open, the vehicle) carrying a smart key Tailgate Auto close function will be dis- when the tailgate is opened, the haz-...
Page 156: Windows
Features of your vehicle Windows Windows The doors of this vehicle are equipped with power windows that can be operated by a switch. OKA4040050R 1 Driver's door power window switch 2 Front passenger's door power window switch 3 Rear door (right) power window switch 4 Rear door (left) power window switch 5 Window opening and closing 6 Automatic power window up/down...
Page 157 Features of your vehicle Windows NOTICE WARNING In cold and wet climates, power windows Do not install any accessories in the area may not work properly due to freezing of windows. It may impact jam protec- conditions. tion. The ignition switch or ENGINE START/ Window opening and closing STOP button must be in the ON position You can open and close windows using...
Page 158 Features of your vehicle Windows Type B - Auto up/down window Automatic reversal (if equipped) (if equipped) ODEEV068020NR OMQ4040445 If the upward movement of the window Pressing or pulling up the power window is blocked by an object or part of the switch momentarily to the second detent body, the window will detect the resis- position (6) completely lowers or raises...
Page 159: 僅 Power Window/Rear Sunroof Lock Button
Features of your vehicle Windows When the power window and rear sun- WARNING roof lock switch is pressed: Always check for obstructions before 僅 The driver's master control can oper- raising any window to avoid injuries or ate all passengers' power windows. vehicle damage.
Page 160: 僅 Remote Window Closing/Opening System
Features of your vehicle Windows Remote window closing/opening WARNING system Windows Remote key 僅 NEVER leave the keys in your vehicle with unsupervised children, when the engine is running. 僅 NEVER leave any child unattended in the vehicle. Even very young children may inadvertently cause the vehicle to move, entangle themselves in the windows, or otherwise injure them-...
Page 161: Bonnet
Features of your vehicle Bonnet 僅 Press the door unlock button (2) for Bonnet more than 3 seconds. The window The bonnet serves as a cover for the moves down after the doors are engine compartment. unlocked, as long as you press the Open the bonnet if maintenance work door unlock button (2).
Page 162 Features of your vehicle Bonnet 2. Go to the front of the vehicle, raise the WARNING bonnet slightly, push the secondary Support rod latch (1) up side and lift the bonnet (2). 僅 After driving, the engine compart- ment and support rod will be hot. Grasp the support rod in the area wrapped in rubber to prevent burns.
Page 163: 僅 Closing The Bonnet
Features of your vehicle Bonnet 2. Lower the bonnet until it is about 30 Bonnet open warning cm above the closed position and let it The bonnet warning message will drop. Make sure that it locks into appear on the LCD display when bonnet place.
Page 164: Fuel Filler Door
Features of your vehicle Fuel filler door Diesel Fuel filler door The vehicle's fuel filler door must be opened and closed by hand from out- side the vehicle. Opening the fuel filler door 1. Turn the engine off. 2. Ensure all of the doors are unlocked. 3.
Page 165: 僅 Closing The Fuel Filler Door
Features of your vehicle Fuel filler door WARNING WARNING Before refuelling, be sure to check what Petrol is highly flammable and explosive. type of fuel is used for your vehicle. Failure to follow these guidelines may result in SERIOUS INJURY or DEATH: If you put diesel fuel into a petrol-pow- ered vehicle or petrol into a diesel-pow- 僅...
Page 166 僅 If the fuel filler cap requires replace- should be maintained until the filling ment, use only Kia Genuine Parts or is complete. those of an equivalent standard for 僅 Use only approved portable plastic your vehicle.
Page 167: Dual Sunroof
Features of your vehicle Dual sunroof Dual sunroof (if equipped) WARNING If your vehicle is equipped with a sun- 僅 Adjust the sunroof or sunshade when roof, you can slide or tilt your sunroof your vehicle stops. This could result in with the sunroof switch located on the loss of control and an accident that overhead console.
Page 168: 僅 Sunshade (Front/Rear)
Features of your vehicle Dual sunroof Sunshade (Front/Rear) Tilt open/close (Front) Use the sunshade to block direct sun- light coming through the sunroof glass. OKA4042637L 1 Tilt open ODEEV068029NR 2 Tilt close Open or close the sunshade by hand. 僅 Push the sunroof switch upward, the sunroof glass tilts open.
Page 169 Features of your vehicle Dual sunroof Rear seat sunroof position) before it is fully opened. To fully open the sunroof glass, push the sunroof switch rearward once more. At this time, the sunroof glass opens only whilst the switch is pushed.
Page 170: 僅 Resetting The Sunroof
Features of your vehicle Dual sunroof 僅 Never deliberately use your body Resetting the sunroof parts to test the automatic reversal Front seat sunroof function. The sunroof glass may reverse direction, but there is a risk of injury. NOTICE 僅 Do not continue to push the sunroof switch after the sunroof is fully opened, closed, or tilted.
Page 171: 僅 Sunroof Open Warning
Features of your vehicle Dual sunroof Sunroof resetting procedure: Sunroof open warning 1. It is recommended to perform the reset procedure with the vehicle engine running. Start the vehicle in P (Park). 2. Make sure the sunroof glass is in the fully closed position.
Page 172: Steering Wheel
Kia instrument cluster. The steering wheel recommends to visit an authorised Kia may become difficult to control or dealer/service partner.
Page 173: 僅 Tilt & Telescopic Steering Wheel
Features of your vehicle Steering wheel 僅 When jump starting the vehicle after Adjusting steering wheel angle battery discharge, the steering wheel and height may not function properly. It is a tem- porary situation due to low battery voltage, and upon stable battery charging, the steering wheel will func- tion normally again.
Page 174: 僅 Heated Steering Wheel
Features of your vehicle Steering wheel To use this function, it must be acti- Heated steering wheel (if vated from the Settings menu in the equipped) infotainment system screen. When the ignition switch or ENGINE For more details, refer to the sepa- START/STOP button is in the ON posi- rately supplied manual with your tion, pressing the heated steering wheel...
Page 175: Mirrors
Features of your vehicle Mirrors Horn Mirrors To sound the horn, press the area indi- This vehicle is equipped with inside and cated by the horn symbol on your steer- outside rear view mirrors to provide ing wheel (see illustration). views of objects behind the vehicle.
Page 176: 僅 Outside Rear View Mirror
Features of your vehicle Mirrors The sensor mounted in the mirror Day/night rear view mirror (if senses the light level around the vehicle, equipped) and automatically controls the headlight glare from the vehicles behind you. When the engine is running, the glare is automatically controlled by the sensor mounted in the rear view mirror.
Page 177 Features of your vehicle Mirrors CAUTION CAUTION If the mirror is jammed with ice, do not 僅 The mirrors stop moving when they adjust the mirror by force. Use an reach the maximum adjusting angles, approved spray de-icer (not radiator but the motor continues to operate antifreeze) to release the frozen mecha- whilst the switch is pressed.
Page 178 Features of your vehicle Mirrors Electric type (if equipped) Automatic adjustment of rear- view mirrors in reverse (Auto The outside rear view mirror can be reverse) (if equipped) folded or unfolded by pressing the switch when the ignition switch or When you shift the gear to the R ENGINE START/STOP button is in the (Reverse) position, the outside rearview...
Page 179 Features of your vehicle Mirrors Auto reverse user settings How to initialize auto reverse user settings If you cannot secure enough visibility with the angles provided as factory If you want to change the automatic default conditions, you can readjust and control function of rearview mirrors to store the angles of outside rearview mir- factory-default conditions, follow the...
Page 180: Instrument Cluster
Features of your vehicle Instrument cluster Instrument cluster Conventional cluster (Type A) OKA4040100L Full LCD cluster (Type B) OKA4040134L * The actual cluster in the vehicle may differ from the illustration. 1 Tachometer 2 Speedometer 3 Engine coolant temperature gauge 4 Fuel gauge 5 LCD display (including Trip computer) 6 Warning and indicator lights...
Page 181 Features of your vehicle Instrument cluster Full LCD cluster (if equipped) The full LCD type cluster provides two themes. Type A Theme A is the basic theme of the full LCD type cluster and provides different graphic styles depending on drive mode. OKA4040135L Type B (Dynamic) Theme B is set by the user and provides digital display.
Page 182 If no information is received via GPS (e.g., not subscribed to Kia Connect ser- vice), the weather and time will be dis- played as 'sunny' and 'night' on the cluster.
Page 183 Features of your vehicle Instrument cluster Type B - mph Tachometer Type A OKA4040148L Type B - km/h (mph) OKA4040102 Type B OKA4040149L The speedometer indicates the speed of OKA4040147L the vehicle and is calibrated in kilome- The tachometer indicates the approxi- ters per hour (km/h) and miles per hour mate number of engine revolutions per (mph).
Page 184 Features of your vehicle Instrument cluster Engine coolant temperature WARNING gauge Never remove the radiator cap when the engine is hot. The engine coolant is Type A under pressure and could severely burn. Wait until the engine is cool before add- ing coolant to the reservoir.
Page 185 Features of your vehicle Instrument cluster Odometer NOTICE Type A 僅 The fuel tank capacity is given in "Recommended lubricants and capac- ities" on page 9-6. 僅 The fuel gauge is supplemented by a low fuel warning light, which will appear when the fuel tank is nearly empty.
Page 186 Features of your vehicle Instrument cluster Distance to empty NOTICE Type A 僅 If the vehicle is not on level ground or the battery power has been inter- rupted, the distance to empty function may not operate correctly. 僅 The distance to empty may differ from the actual driving distance as it is an estimate of the available driving distance.
Page 187: 僅 Transmission Shift Indicator
Features of your vehicle Instrument cluster Type B Automatic transmission shift indi- cator Type A OKA4040146L This gauge indicates the current outside air temperatures by 1°C (1°F). OMQ4040120 僅 Temperature range: -40°C~60°C (- Type B 40°F~140°F) The outside temperature on the display may not change immediately like a gen- eral thermometer to prevent the driver from being inattentive.
Page 188 Features of your vehicle Instrument cluster For example Automatic transmission shift indi- cator in manual shift mode (if 僅 ▲3: Indicates that shifting up to the equipped) 3rd gear is desired (currently the shift lever is in the 2nd or 1st gear). In the Manual shift mode, this indicator 僅...
Page 189: Lcd Display
Features of your vehicle LCD display LCD display The LCD display modes can be changed by using the control buttons. LCD display control OKA4040575N : MODE button for changing modes : MOVE switch for changing items 3 OK: SELECT/RESET button for setting or resetting the selected item...
Page 190: 僅 Lcd Display Modes
Features of your vehicle LCD display LCD display modes The LCD display provides 5 modes. You can switch modes by pressing the Mode but- ton. The information provided may differ depending on which functions are applicable to your vehicle. * : if equipped Mode Driving Assist Trip Computer...
Page 191 Features of your vehicle LCD display 僅 Lane Safety (if equipped) Trip computer mode OKA4050169 OKA4040527L 僅 Driver Attention Warning (if equipped) The trip computer mode displays infor- mation related to vehicle driving param- eters including fuel economy, tripmeter information and vehicle speed. * For more details, refer to "Trip informa- tion (trip computer)"...
Page 192 Features of your vehicle LCD display 僅 High Beam Assist malfunction (if Tyre pressure status equipped) This mode displays information related At this time, a Master Warning icon to Tyre Pressure. * For more details, refer to "Tyre Pres- ) will appear beside the User Set- sure Monitoring System (TPMS) (if tings icon ( ), on the LCD display.
Page 193 Features of your vehicle LCD display 1. Driver Assistance * The information provided may differ depending on which systems are applicable to your vehicle. Items Explanation To adjust Speed Limit Speed Limit * For more details, refer to "Intelligent Speed Limit Assist (ISLA) (if equipped)" on page 6-112. 僅...
Page 194 Features of your vehicle LCD display 2. Cluster * The information provided may differ depending on which systems are applicable to your vehicle. Items Explanation Wiper/Lights Display If this item is checked, the wiper/lights display will be activated. Icy Road Warning If this item is checked, the icy road warning will be activated.
Page 195 Features of your vehicle LCD display Items Explanation To activate or deactivate the Smart Tailgate with Auto Open. Smart Tailgate For more details, refer to "Smart Tailgate with Auto Open (if equipped)" on page 4-41. To activate or deactivate the Smart Sliding Door with Auto Open. Smart Sliding Door For more details, refer to "Smart Sliding Door with Auto Open (if equipped)"...
Page 196 Features of your vehicle LCD display 6. Units * The information provided may differ depending on which systems are applicable to your vehicle. Items Explanation 僅 km/h or mph Speedometer Unit To select the Speedometer unit. 僅 Km/L, L/100Km Fuel Economy Unit To select the Fuel economy unit.
Page 197: Lcd Displays
Features of your vehicle LCD displays Type B (for 12.3") LCD displays LCD displays show the following infor- mation to drivers. 僅 Trip information 僅 LCD modes 僅 Warning messages Trip information (trip computer) The trip computer is a microcomputer- controlled driver information system that displays information related to driv- ing.
Page 198 Features of your vehicle LCD displays Fuel economy Accumulated driving information mode This display shows the accumulated trip Average Fuel Economy (1) distance, the average fuel efficiency, and the total driving time. Type A OMQ4040503R 僅 The average fuel economy is calcu- lated by the total driving distance and fuel consumption since the last aver- OKA4040150R...
Page 199 Features of your vehicle LCD displays Drive Info display 僅 If you press "OK" button for more than 1 second after the Driving Information This display shows the trip distance, the is displayed, the information will be average fuel efficiency, and the total reset.
Page 200: 僅 Driving Info Display
Features of your vehicle LCD displays Digital speedometer Service required This digital speedometer display shows If you do not have your vehicle serviced the speed of the vehicle. according to the already inputted ser- vice interval, "Service required" message is displayed for several seconds each time you set the ignition switch or ENGINE START/STOP Button to the ON position.
Page 201: 僅 Lcd Display Messages
Features of your vehicle LCD displays Type B LCD display messages Door, bonnet, tailgate, sunroof open OMQ4040160L This display shows the trip distance, average fuel economy, and driving time. This information is displayed for a few OKA4040110 seconds when you turn off the vehicle, 僅...
Page 202 Features of your vehicle LCD displays Lights mode Wiper mode Type A Type A OMQ4040135L OMQ4040136L Type B Type B OMQ4040161L OMQ4040162L This indicator displays which exterior This indicator displays which wiper light is selected using the lighting con- speed is selected using the wiper con- trol.
Page 203 Features of your vehicle LCD displays Low washer fluid NOTICE If the icy road warning appears whilst driving, you should drive more atten- tively and safely refraining from over- speeding, rapid acceleration, sudden braking or sharp turning, etc. Engine overheated 僅...
Page 204 僅 If the warning appears each time you not in the P (Park) or N (Neutral) posi- press the ENGINE START/STOP but- tion. ton, have the vehicle inspected by a professional workshop. Kia recom- mends to visit an authorised Kia dealer/service partner.
Page 205: Warning And Indicator Lights
僅 When there is a malfunction with the SRS. In this case, have the vehicle inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. Seat belt warning light This warning light informs the driver that the seat belt is not fas- tened.
Page 206 1. Drive carefully to the nearest safe by a professional workshop. Kia recom- location and stop your vehicle. mends to visit an authorised Kia dealer/ 2. With the engine stopped, check the service partner. brake fluid level immediately and add fluid as required (For more details, refer to "Brake fluid"...
Page 207 Kia dealer/service partner. In this case, have the vehicle checked by a professional workshop. Kia recom- mends to visit an authorised Kia dealer/ Electronic Brake Force Distribu- service partner as soon as possible. tion (EBD) system warning light...
Page 208 Features of your vehicle Warning and indicator lights Kia recommends to visit an authorised Electric Power Steering (EPS) Kia dealer/service partner. warning light Malfunction Indicator Lamp (MIL) This warning light appears: 僅 Once you set the ignition switch or ENGINE START/STOP Button to the ON position.
Page 209 Kia recommends to visit an enhanced engine protection system that authorised Kia dealer/service partner. limits the engine's power is activated.
Page 210 In this case, have the vehicle equipped) inspected by a professional workshop. To identify the details of the warning Kia recommends to visit an authorised look at the LCD display. Kia dealer/service partner. If the warning situation is solved, the * For more details, refer to "Tyre Pres-...
Page 211 (at this time the LCD warning message will be displayed), have the DPF system checked by a professional This warning light appears: workshop. Kia recommends to visit an 僅 Once you set the ignition switch or authorised Kia dealer/service partner. ENGINE START/STOP button to the CAUTION ON position.
Page 212 僅 When there is a malfunction with by a professional workshop. Kia recom- Petrol Particulate Filter (PPF) system. mends to visit an authorised Kia dealer/ service partner. 僅 When this warning light appears, it may turn off after driving the vehicle:...
Page 213 Collision-Avoidance Assist. In this case, have the vehicle inspected OFF indicator light by a professional workshop. Kia recom- mends to visit an authorised Kia dealer/ This indicator light appears: service partner. 僅 Once you set the ignition switch or...
Page 214 ON. In this case, have the vehicle inspected by a professional workshop. - At this time, you can start the Kia recommends to visit an authorised engine. Kia dealer/service partner. - The indicator light goes off after starting the engine.
Page 215 In this case, have the vehicle inspected * For more details, refer to "High Beam by a professional workshop. Kia recom- Assist (HBA) (if equipped)" on page 4- mends to visit an authorised Kia dealer/ 127. service partner. Light ON indicator light This indicator light appears: 僅...
Page 216 * For more details, refer to "Cruise Con- expected, so have the system trol (CC) (if equipped)" on page 6-125. inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. For more details, refer to "Pan-European eCall system (if equipped)" on page 7-...
Page 217: Rear View Monitor (Rvm) (If
Features of your vehicle Rear View Monitor (RVM) Rear View Monitor (RVM) (if Rear View Monitor settings equipped) OKA4041477L You can change Rear View Monitor 'Dis- OKA4041081R play Contents' or 'Display Settings' by Rear View Monitor is a parking safe function that shows the area behind the touching the setup icon ( ) on the...
Page 218 Features of your vehicle Rear View Monitor (RVM) Parking/View button Extended Rear View Monitor The rear view will maintain showing on the screen to help you when parking. Operating conditions Shift the gear from R (Reverse) to N (Neutral) or D (Drive), the rear view will appear on the screen.
Page 219: 僅 Rear View Monitor Malfunction And Limitations
Rear View Monitor Malfunction When Rear View Monitor is not working properly, or the screen flickers, or the camera image does not display nor- mally, have the function inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner.
Page 220: Surround View Monitor (Svm)
Features of your vehicle Surround View Monitor (SVM) (4) Wide-rear view camera Surround View Monitor (SVM) (if equipped) OKA4041085L Refer to the picture above for the OKA4041594L detailed location of the detecting sen- Surround View Monitor will assist in sors. parking using the cameras installed on the vehicle and displays images around Surround View Monitor settings...
Page 221 Features of your vehicle Surround View Monitor (SVM) 僅 Display Settings: To change the screen's brightness and contrast. NOTICE The settings menu on your vehicle may not be necessarily be available due to the selected options or regions. Surround View Monitor Auto On With the engine on, select 'Driver Assis- tance →...
Page 222 Features of your vehicle Surround View Monitor (SVM) Rear top view 僅 The horizontal guideline of the Rear View Parking Guidance shows the dis- tance of 0.5 m (1.6 ft.), 1 m (3.3 ft.) and 2.3 m (7.6 ft.) from the vehicle. Parking Distance Warning OKA4041597L 僅...
Page 223 Features of your vehicle Surround View Monitor (SVM) when the gear is in D (Drive) or N Operating conditions (Neutral) and vehicle speed is 僅 Shift the gear to R (Reverse), the below 10 km/h (6 mph). image will appear on the screen. 僅...
Page 224 Kia recom- Always keep the camera lens clean. mends to visit an authorised Kia dealer/ However, do not use chemical sol- service partner. vents such as strong detergents con-...
Page 225 Features of your vehicle Reverse Parking Distance Warning (PDW) Reverse Parking Distance Reverse Parking Distance Warn- ing settings Warning (PDW) (if equipped) Reverse Parking Distance Warning is a Warning Volume parking safe function that will warn the driver by detecting the distance between an obstacle or people, animal(s) within a certain distance with front/rear ultra- sonic sensors when the vehicle is mov-...
Page 226 If it still does not work effectiveness of the sensor. properly, have the function inspected by a professional workshop. Kia recom- mends to visit an authorised Kia dealer/ service partner.
Page 227: Reverse Parking Distance Warning (Pdw)
- Heavy rain or water spray is pres- inspected by a professional workshop. Kia recommends to visit an authorised - Water flows on the surface of the Kia dealer/service partner. sensor - Affected by another vehicle's sen-...
Page 228 Features of your vehicle Forward/Reverse Parking Distance Warning (PDW) Forward/Reverse Parking Dis- Forward/Reverse Parking Dis- tance Warning settings tance Warning (PDW) (if equipped) Warning Volume Forward/Reverse Parking Distance Warning will help warn the driver if an obstacle is detected within a certain dis- tance when the vehicle is moving for- ward or in reverse at low speeds.
Page 229 Features of your vehicle Forward/Reverse Parking Distance Warning (PDW) Forward/Reverse Parking Dis- Forward Parking Distance Warn- tance Warning operation 僅 Forward Parking Distance Warning Parking Safety button works in 3 ways following: - The gear is shifted from R (Reverse) to D (Drive) with Reverse Parking Distance Warning on - The gear is in D (Drive) and the Parking Safety button indicator...
Page 230 Features of your vehicle Forward/Reverse Parking Distance Warning (PDW) NOTICE Warning indicator Distance from When the vehicle's rearward speed is when driving for- Warning sound object ward below 10 km/h (6 mph), both the front and rear ultrasonic sensors will detect 60~120 cm Buzzer beeps inter- objects.
Page 231: Limitations
Parking Distance Warn- a professional workshop. Kia recom- ing. mends to visit an authorised Kia dealer/ 僅 Pay close attention when driving near service partner. objects, pedestrians, and especially 僅 The audible warning does not sound.
Page 232 - Water flows on the surface of the Reverse Parking Distance Warning sensor inspected by a professional workshop. - Affected by another vehicle's sen- Kia recommends to visit an authorised sors Kia dealer/service partner. - The sensor is covered with snow - Driving on uneven road, gravel...
Page 233: Lighting
Features of your vehicle Lighting Lighting Daytime Running Light (DRL) The Daytime Running Light (DRL) can This vehicle is equipped with a variety of make it easier for others to see the front lights to illuminate the interior and exte- of your vehicle during the day.
Page 234 Features of your vehicle Lighting Position & Tail lamp NOTICE The ignition switch or ENGINE START/ STOP button must be in the ON position to turn on the headlights. Auto light OKA4040095R When the light switch is in the position lamp position, the front position lamp and auxiliary lamp (if equipped), tail, license light will turn ON.
Page 235 Features of your vehicle Lighting light switch does not need to be on to Operating high beam use this flashing feature. Operating turn signals and lane change signals OKA4040096R To turn on the high beam headlamp: 僅 Push the lever away from you. The lever will return to its original OKA4040097R The ENGINE START/STOP button must...
Page 236 Features of your vehicle Lighting One-touch lane change function CAUTION To activate a one-touch lane change When in operation, the fog lights con- function, move the turn signal lever sume large amounts of vehicle electrical slightly and then release it. The lane power.
Page 237: 僅 High Beam Assist (Hba)
Features of your vehicle Lighting High Beam Assist (HBA) (if NOTICE equipped) Always keep the front view camera in good condition to maintain optimal per- formance of High Beam Assist. For more details on the precautions of the front view camera, refer to "Forward Collision-Avoidance Assist (FCA) (Front view camera only) (if equipped)"...
Page 238 We recommend will be on and the function will turn that the function be inspected by an off. authorised Kia dealer/service partner. - If the headlamp switch is placed from AUTO to another position Limitations of High Beam Assist...
Page 239: 僅 Headlight Levelling Adjustment Switch
Features of your vehicle Lighting 僅 There is a traffic light, reflecting sign, Headlight levelling adjustment flashing sign or mirror ahead. switch (if equipped) 僅 There is a temporary reflector or flash ahead (construction area). 僅 The road conditions are bad such as being wet, iced or covered with snow.
Page 240: Wipers And Washers
Features of your vehicle Wipers and washers D: Rear wiper/washer control Wipers and washers 僅 HI - Continuous wipe The wipers and washers remove foreign substances from the windscreen and 僅 LO - Intermittent wipe rear window, helping to maintain visibil- 僅...
Page 241 Features of your vehicle Wipers and washers 僅 Do not put pressure on the Auto control (if equipped) windscreen glass. CAUTION 僅 When washing the vehicle, set the wiper switch in the OFF (0) position to stop the auto wiper operation. The wiper may operate and be dam- aged if the switch is set in the AUTO mode whilst washing the vehicle.
Page 242: 僅 Operating Front Windscreen Washers
Features of your vehicle Wipers and washers Operating front windscreen CAUTION washers To prevent possible damage to the washer pump, do not operate the washer when the fluid reservoir is empty. WARNING Do not use the washer in freezing tem- peratures without first warming the windscreen with the defrosters;...
Page 243: 僅 Operating Rear Window Wiper And Washer Switch
Features of your vehicle Wipers and washers Operating rear window wiper and Auto rear wiper washer switch The rear wiper will operate whilst the vehicle is in reverse with the front wiper The rear window wiper and washer ON by selecting the function on the LCD switch is located at the end of the wiper display.
Page 244: Welcome System
Features of your vehicle Welcome system Welcome system (if equipped) NOTICE The welcome system is a function that In these conditions, the heated washer illuminates the surroundings or the inte- nozzle may not function properly: rior when the driver approaches or exits 僅...
Page 245: Interior Lights
Features of your vehicle Interior lights Headlamp escort function Interior lights The headlamps (and/or taillights) remain This vehicle is equipped with lights on for approximately 5 minutes after the throughout the vehicle to illuminate the ignition key is removed, or ENGINE interior.
Page 246 Features of your vehicle Interior lights - The map lamp and room lamp will Map lamp stay on for approximately 10 min- Type A utes if a door is opened with the ENGINE START/STOP button in the ACC or OFF position. - The map lamp and room lamp will stay on continuously if the door is opened with the ENGINE START/...
Page 247: 僅 Luggage Room Lamp
Features of your vehicle Interior lights Room lamp Luggage room lamp 僅 : The lamp will always turn on Type A when the tailgate is opened/closed. 僅 : The lamp is on when the tailgate is opened, and off when the tailgate is closed.
Page 248: 僅 Vanity Mirror Lamp
Features of your vehicle Interior lights Glove box lamp (if equipped) CAUTION The luggage room lamp comes on as long as the tailgate opens. To prevent unnecessary charging system drain, close the tailgate securely after using the luggage room. Vanity mirror lamp (if equipped) OKA4070076R The glove box lamp comes on when the glove box is opened.
Page 249: Climate Control System
4. Set the fan speed control to the desired speed. Air conditioning (A/C) All Kia air conditioning systems are filled Heating with R-134a/R-1234yf refrigerant. 1. Start the vehicle. Press the A/C but- 1. Set the mode to the position.
Page 250: 僅 Climate Control Air Filter
僅 Operating the air conditioning system mate control air filter replaced by a pro- in the recirculated air position pro- fessional workshop. Kia recommends to vides maximum cooling; however, visit an authorised Kia dealer/service continual operation in this mode may partner.
Page 251: 僅 Rear Climate Control Air Filter
僅 When the air flow rate suddenly decreases, have the system checked by a professional workshop. Kia rec- ommends to visit an authorised Kia dealer/service partner. Rear climate control air filter...
Page 252 Venting refrigerants found, have the system inspected by a directly to the atmosphere is harmful to professional workshop. Kia recommends individuals and environment. Failure to to visit an authorised Kia dealer/service heed these warnings can lead to serious partner. injuries. WARNING...
Page 253: Manual Climate Control System
Features of your vehicle Manual climate control system Manual climate control system (if equipped) The manual climate control system uses cooling and heating to help maintain a pleasant environment inside the vehicle. Front seat - type A OKA4040300 Front seat - type B OKA4040300L...
Page 254 Features of your vehicle Manual climate control system Rear seat OKA4040344 Front seat 1 Fan speed control knob 2 Air intake control button 3 Mode selection knob 4 Rear window defroster button 5 Front windscreen defroster button 6 Temperature control knob 7 Air conditioning (A/C) button 8 Rear climate control ON button 9 Rear climate control LOCK button...
Page 255: 僅 Heating And Air Conditioning
Features of your vehicle Manual climate control system Heating and air conditioning OKA4041494R 1. Start the engine. 2. Set the mode to the desired position. For improving the effectiveness of heating and cooling; 僅 Heating: 僅 Cooling: 3. Set the temperature control to the desired position. 4.
Page 256 Features of your vehicle Manual climate control system Mode selection Defrost-Level (A, D) The mode selection buttons control the Most of the air flow is directed to the direction of the air flow through the ven- windscreen with a small amount of air tilation system.
Page 257: 僅 Controlling Air Intake
Features of your vehicle Manual climate control system Type B Temperature control The temperature control knob allows you to control the temperature of the air flowing from the ventilation system. OKA4040311L To change the air intake control position. 1. Push the desired control button OKA4040310 To change the air temperature in the Recirculated air position...
Page 258: 僅 Controlling Fan Speed
Features of your vehicle Manual climate control system Controlling fan speed NOTICE The fan speed control knob allows you Prolonged operation of the heater in the to control the fan speed of the air flow- recirculated air position (without air con- ing from the ventilation system.
Page 259 Features of your vehicle Manual climate control system Type B From the rear seat 1. Set the rear climate control selection (REAR ON) button in the front climate control panel to the ON position. 2. Set the rear climate control selection (REAR LOCK) button in the front cli- mate control panel to the OFF posi- tion.
Page 260 Features of your vehicle Manual climate control system When the rear climate control selection From the rear seat (REAR ON) button in the front climate control panel is in the ON position and set the rear climate control selection (REAR LOCK) button in the front climate control panel to the OFF position and the rear mode is selected by pushing the rear mode selection button on the rear...
Page 261 Features of your vehicle Manual climate control system Rear fan speed control From the rear seat From the front seat OKA4040317 Set the rear climate control selection (REAR ON) button in the front climate OKA4040315 control panel to the ON position and set Set the rear climate control selection the rear climate control selection (REAR (REAR ON) button to the ON position...
Page 262: Automatic Climate Control System
Features of your vehicle Automatic climate control system Automatic climate control system (if equipped) The automatic climate control system uses cooling and heating to help maintain a pleasant environment inside the vehicle. Front seat OKA4040301R Rear seat OKA4040330...
Page 263 Features of your vehicle Automatic climate control system Front seat 1 Driver's temperature control button 2 Passenger's temperature control button 3 AUTO (automatic control) button 4 Climate control OFF button 5 Fan speed control button 6 Mode selection button 7 Front windscreen defroster button 8 Rear window defroster button 9 SYNC button 10 Air intake control button...
Page 264: 僅 Heating And Air Conditioning Automatically
Features of your vehicle Automatic climate control system NOTICE Operating the blower when the ignition switch or ENGINE START/STOP button is in the ON position could cause the bat- tery to discharge. Operate the blower when the engine is running. Heating and air conditioning automatically 1.
Page 265 Features of your vehicle Automatic climate control system NOTICE Never place anything over the sensor located on the instrument panel to ensure better control of the heating and cooling system. OKA4040411N...
Page 266 Features of your vehicle Automatic climate control system Heating and air conditioning manually The heating and cooling system can be controlled manually by pressing buttons other than the AUTO button. OKA4041307R In this case, the system works sequentially according to the order of buttons selected. 1.
Page 267 Features of your vehicle Automatic climate control system Mode selection Defrost-Level (A, D) The mode selection button controls the Most of the air flow is directed to the direction of the air flow through the ven- windscreen with a small amount of air tilation system.
Page 268 Features of your vehicle Automatic climate control system The passenger side temperature will Temperature control be set to the same temperature as the driver side temperature. 2. Move the driver side temperature control switch. The driver and passen- ger side temperature will be adjusted equally.
Page 269 Features of your vehicle Automatic climate control system Controlling air intake NOTICE This is used to select the outside (fresh) Prolonged operation of the heater in the air position or recirculated air position. recirculated air position (without air con- ditioning selected) may cause fogging of Type A/Type B the windscreen and side windows and the air within the passenger compart-...
Page 270 Features of your vehicle Automatic climate control system Controlling fan speed Turning off the front air climate control The fan speed can be set to the desired speed by operating the fan speed con- trol button. To change the fan speed: 僅...
Page 271 Features of your vehicle Automatic climate control system rear mode is selected by pushing the From the rear seat rear mode selection button on the rear 1. Set the rear climate control selection control panel as follows: (REAR ON) button in the front climate control panel to the ON position.
Page 272 Features of your vehicle Automatic climate control system From the rear seat From the rear seat OKA4040332 OKA4040331 To change the rear air temperature, Press the rear fan speed control button press the button ( ) for warmer air or on the rear control panel to the desired press the button ( ) for cooler air.
Page 273 Features of your vehicle Windscreen defrosting and defogging Windscreen defrosting and Defogging inside windscreen with manual climate control sys- defogging When the windscreen is covered with frost or moisture, the front view is blurred, you should remove the frost and moisture. WARNING Windscreen heating Do not use the...
Page 274 Features of your vehicle Windscreen defrosting and defogging 1. Set the fan speed to the highest Defrosting outside windscreen (extreme right) position. with automatic climate control 2. Set the temperature to the extreme hot position. 3. Select the position. 4. The outside (fresh) air and air condi- tioning will be selected automatically.
Page 275: System
Features of your vehicle Windscreen defrosting and defogging NOTICE 僅 When the air conditioning is turned on by Auto defogging system, if you try to turn off the air conditioning, the indicator will blink 3 times and the air conditioning will not be turned off. 僅...
Page 276 Features of your vehicle Windscreen defrosting and defogging Operating rear window defroster Defogging logic The defroster heats the window to To reduce the possibility of fogging up remove frost, fog and thin ice from the the inside of the windscreen, the air rear window, whilst the engine is on.
Page 277: Storage Compartment
Features of your vehicle Storage compartment Cancelling/returning automatic Storage compartment defogging logic on automatic cli- These compartments can be used to mate control system store small items required by the driver or passengers. Passenger's side open tray OKA4040347 1. Turn the ENGINE START/STOP button to the ON position.
Page 278: 僅 Centre Console Storage
Features of your vehicle Storage compartment Rotary storage box (if equipped) CAUTION 僅 To avoid possible theft, do not leave valuables in the storage compart- ment. 僅 Always keep the storage compart- ment covers closed whilst driving. Do not attempt to place so many items in the storage compartment that the storage compartment cover cannot close securely.
Page 279: Interior Features
Features of your vehicle Interior features Glove box Interior features There are various features inside the vehicle for the convenience of the occu- pants. Ambient light (if equipped) The ambient lights are applied to the and front door and sliding door. OKA4040417R To open the glove box: 僅...
Page 280 Interior features ment has heated, the lighter will pop out WARNING to the "ready" position. Ashtray use Kia recommends to use parts for 僅 Do not use the vehicle's ashtrays as replacement from an authorised Kia waste receptacles. dealer/service partner.
Page 281 Features of your vehicle Interior features 2nd/3rd row centre seats (11 seats) WARNING Hot liquids 僅 Do not place uncovered cups with hot liquid in the cup holder whilst the vehicle is in motion. If the hot liquid spills, you burn yourself. Such a burn to the driver could lead to loss of con- trol of the vehicle.
Page 282 Features of your vehicle Interior features Seat warmer (if equipped) Temperature control (Manual) The seat warmer is provided to warm 僅 Each time you push the levers or the front and rear seats during cold press the buttons the temperature weather.
Page 283: 僅 Air Ventilation Seat
Features of your vehicle Interior features 4. Intoxicated individuals NOTICE 5. Individuals taking medication that can With the seat warmer levers/buttons in cause drowsiness or sleepiness the ON position, the heating system in (sleeping pills, cold tablets, etc.) the seat turns off or on automatically depending on the seat temperature.
Page 284 Features of your vehicle Interior features using a mirror. Before returning the sun visor to the original position, be sure to press the OFF button ( ) to turn it off. (if equipped) The air ventilation seats defaults to the The ticket holder (5) is provided for OFF position whenever the ENGINE holding a tollgate ticket.
Page 285 Features of your vehicle Interior features Front seat special dedicated adapters if their charging methods don't fit the way the USB car charger works. Quick Charge 2.0 is available on the smart phone or the table PC equipped with fast charging capabilities.
Page 286 Features of your vehicle Interior features Power outlet (if equipped) WARNING The power outlet is designed to provide 僅 Use the power outlet only when the power for mobile telephones or other vehicle is on and remove the acces- devices designed to operate with vehicle sory plug after use.
Page 287: 僅 Wireless Smart Phone Charging System
Features of your vehicle Interior features Wireless smart phone charging Wireless smart phone charging system (if equipped) 1. Remove any object on the smart phone charging pad including the A wireless smart phone charging system smart key. If there is any foreign is located in front of the centre console.
Page 288 Features of your vehicle Interior features contact with the wireless charging NOTICE pad. For some manufacturers' smart phones, 僅 Items equipped with magnetic com- the system may not warn you even ponents such as credit card, tele- though the smart phone is left on the phone card, bankbook, any wireless charging unit.
Page 289 Features of your vehicle Interior features 僅 For certain cellular phones with their own protection, the wireless charging speed may decrease and the wireless charging may stop. Coat hook A Coat hook is next to the rear grab han- dle. ODEEV068209NR Side curtain (if equipped) 2nd row...
Page 290: 僅 Floor Mat Anchors
Features of your vehicle Interior features To use the side curtain: When using a floor mat on the front floor carpet, make sure it attaches to the floor 1. Lift the curtain by the knob (1). mat anchors in your vehicle. This keeps 2.
Page 291: 僅 Luggage Net Holder
If the net is not removed, it may come into contact with the seat, net, and storage items can be damaged. OKA4040508R If necessary, Kia recommends to contact an authorised Kia dealer/service partner. The luggage net is an optional part.
Page 292: Exterior Features
(if equipped) and roof rack and authorised Kia dealer/service partner or secure the load firmly. other qualified shop. 100 kg (220 lbs.)
Page 293 Features of your vehicle Exterior features 僅 Always drive slowly and turn corners carefully when carrying items on the roof rack. Severe wind updrafts, caused by passing vehicles or natural causes, can cause sudden upward pressure on items loaded on the roof rack.
Page 295 Infotainment system Infotainment system Audio system.................. 5-3 僅 Shark-fin Antenna.................... 5-3 僅 USB port ....................... 5-3 僅 How vehicle radio works................5-4 Audio (Without Touch Screen) ............ 5-7 僅 System overview ....................5-7 僅 System layout – control panel..............5-7 僅...
Page 296 Infotainment system Declaration of Conformity............5-29 僅 FCC Certification .................... 5-29 僅 CE...........................5-31 僅 NBTC ........................5-32 僅 TRA........................5-32...
Page 297: Infotainment System
Infotainment system Audio system Infotainment system USB port You can use the USB port to plug in an Audio system USB. NOTICE If you install an aftermarket HID head lamp, your vehicle's audio and electronic device may malfunction. * If your vehicle is equipped with info- tainment system, refer to a separately supplied manual for detailed informa- tion.
Page 298: 僅 How Vehicle Radio Works
Infotainment system Audio system How vehicle radio works AM reception FM reception ODEEV068217NR AM broadcasts can be received at greater distances than FM broadcasts. ODEEV068216NR This is because AM radio waves are AM and FM radio signals are broadcast transmitted at low frequencies. These from transmitter towers located around long distance, low frequency radio your city.
Page 299 Infotainment system Audio system This can lead to undesirable or unpleas- 僅 Station Swapping - As an FM signal ant listening conditions which might lead weakens, another more powerful sig- you to believe a problem exists with your nal near the same frequency may radio.
Page 300 Infotainment system Audio system Using a cellular phone or a two- way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio system. This does not mean that something is wrong with the audio equipment.
Page 301: Audio (Without Touch Screen)
Infotainment system Audio (Without Touch Screen) Audio (Without Touch Screen) (if equipped) System overview System layout – control panel 씾 (With Bluetooth Wireless Technology) * The system's actual appearance and layout may differ depending on the vehicle model and specification. 1.
Page 302 Infotainment system Audio (Without Touch Screen) 씾 (With Bluetooth Wireless Technology) * The system's actual appearance and layout may differ depending on the vehicle model and specification. 5. SEEK/TRACK button 僅 Change the station/track/file. 僅 Whilst listening to the radio, press and hold to search for a station. 僅...
Page 303: 僅 System Layout - Steering Wheel Remote Control
Infotainment system Audio (Without Touch Screen) 僅 Whilst listening to the radio, push System layout – steering wheel and hold to search for a station. remote control 僅 Whilst playing media, push and hold to rewind or fast forward (except for Bluetooth audio mode). 5.
Page 304 Infotainment system Audio (Without Touch Screen) 僅 Stop your vehicle first before using CAUTION your mobile phone. Using a mobile About operating the system phone whilst driving may lead to a 僅 Use the system with the engine run- traffic accident. If necessary, use the ning.
Page 305: 僅 Turning The System On Or Off
Infotainment system Audio (Without Touch Screen) NOTICE CAUTION 僅 If you experience any problems with You can turn on the system when the the system, contact your place of pur- key ignition switch is placed in the "ACC" chase or dealer. or "ON"...
Page 306: Radio
Infotainment system Radio Numberless items Radio Turn the [TUNE] knob to select the Turning on the radio desired item, and then press the knob. 1. On the control panel, press the [AUDIO] button. 2. When the mode selection window dis- plays, turn the [TUNE] knob to select the desired radio mode and then press the knob.
Page 307 Infotainment system Radio - Equaliser (Tone): Adjust the output Press the [MENU/CLOCK] button on level for each sound tone mode. the control panel to access the following menu options: - Speed dependent vol.: Set the vol- ume to be adjusted automatically 僅...
Page 308: 僅 Changing The Radio Mode
Infotainment system Radio 僅 Date/Time: You can change the date Scanning for available radio sta- and time that are shown on the sys- tions tem display. You can listen to each radio station for a - Set date: Set date to display on the few seconds to test the reception and system display.
Page 309: 僅 Listening To Saved Radio Stations
Infotainment system Media player Saving the current radio station Media player Whilst listening to the radio, press and Using the media player hold the desired number button on the You can play music stored in various control panel. media storage devices, such as USB 僅...
Page 310: 僅 Using The Usb Mode
Infotainment system Media player distorted noise or a system malfunc- 僅 Sound settings: You can change the tion. settings related to sounds, such as location where sound will be concen- 僅 When the equaliser function of the trated and the output level for each connected device and Equaliser range.
Page 311 Infotainment system Media player - Display (Power Off): Set to display Playing repeatedly the clock when the system power is On the control panel, press the [1 RPT] off. button. The repeat play mode changes 僅 Language: You can change the dis- each time you press it.
Page 312: Bluetooth
Infotainment system Bluetooth 僅 Do not connect and disconnect a USB Bluetooth connector repeatedly in a short time. Connecting Bluetooth devices Doing so may cause an error in the Bluetooth is a short-range wireless net- device or a system malfunction. working technology.
Page 313 Infotainment system Bluetooth 1. Deactivate Bluetooth and reactivate 3. Enter or confirm the passkey to con- it on the device. Then, reconnect firm the connection. the device. 僅 If the passkey input screen is dis- 2. Turn the device off and on. Then, played on the Bluetooth device reconnect it.
Page 314: 僅 Using A Bluetooth Audio Device
Infotainment system Bluetooth 僅 When a device is connected to the 2. Turn the [TUNE] knob to select your system via Bluetooth, the device's bat- currently connected device and then tery may discharge faster. press the knob. 3. Press the [1 RPT] button to select Yes. Connecting a paired device Deleting paired devices To use a Bluetooth device on your sys-...
Page 315 Infotainment system Bluetooth Press the [MENU/CLOCK] button on - Display (Power Off): Set to display the control panel to access the following the clock when the system power is a menu option. off. 僅 Sound settings: You can change the 僅...
Page 316: 僅 Using A Bluetooth Phone
Infotainment system Bluetooth 僅 Receiving an incoming call or making an accident. If necessary, use the an outgoing call whilst playing Blue- Bluetooth Handsfree feature to make tooth audio may result in audio inter- calls and keep the call as short as pos- ference.
Page 317 Infotainment system Bluetooth 僅 To select a phone number from 僅 Add new favorites: Add a frequently your favorites list, select Favorites. used phone number to favorites. 僅 To select a phone number from 僅 Delete items: Delete a selected favor- your call history, select Call history.
Page 318 Infotainment system Bluetooth Press the [MENU/CLOCK] button on 2. Turn the [TUNE] knob to select the the control panel to access the following desired group of alphanumeric char- menu options: acters, and then press the knob. 僅 Download: Download your call his- 3.
Page 319 Infotainment system Bluetooth 僅 Permission is required to download NOTICE contacts from the mobile phone. 僅 Depending on the mobile phone type, When you attempt to download data, call rejection may not be supported. you may need to permit the download 僅...
Page 320: System Status Icons
Infotainment system System status icons System status icons NOTICE Status icons appear at the top of the 僅 If the caller information is saved in screen to display the current system sta- your contacts list, the caller's name tus. and phone number will be displayed. Familiarise yourself with the status icons If the caller information is not saved in that appear when you perform certain...
Page 321: System Specifications
Infotainment system System specifications Signal strength System specifications Icon Description Signal strength of the mobile phone connected Supported audio formats via Bluetooth 僅 Audio file specification NOTICE - WAVeform audio format 僅 The battery level displayed on the - MPEG1/2/2.5 Audio Layer3 screen may differ from the battery - Windows Media Audio Ver 7.X/8.X level displayed on the connected...
Page 322 Infotainment system System specifications 僅 Maximum number of folders: 1,000 Supported USB storage devices 僅 Maximum number of files: 5,000 僅 Byte/Sector: 64 kbyte or less 僅 Format system: FAT12/16/32 (recom- NOTICE mended), exFAT/NTFS 僅 Files that are not in a supported for- NOTICE mat may not be recognised or played, or information about them, such as...
Page 323: Trademarks
Bluetooth SIG, Inc. and any use of interference to radio communications. such marks by Kia is under licence. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause...
Page 324 Infotainment system Declaration of Conformity ence received, including interference that may cause undesired operation. This equipment complies with FCC radi- ation exposure limits set forth for an uncontrolled environment.T This equipment should be installed and operated with minimum 20 cm between the radiator and your body.
Page 325 Infotainment system Declaration of Conformity...
Page 326 Infotainment system Declaration of Conformity NBTC OMAN-TRA D192564 TRA/TA-R/9182/20...
Page 327 Driving your vehicle Driving your vehicle Be sure the exhaust system does not leak.........6-6 Before driving ................6-6 Key positions..................6-8 僅 Illuminated ignition switch ................6-8 僅 Ignition switch position .................. 6-8 僅 Starting the engine..................6-9 ENGINE START/STOP button .............6-11 僅...
Page 328 Driving your vehicle 僅 Vehicle Stability Management (VSM) system ........6-44 僅 Brake Assistant System (BAS) ..............6-45 僅 Good braking practices................6-46 Drive mode integrated control system ........6-47 僅 Drive mode .......................6-47 Forward Collision-Avoidance Assist (FCA) (Front view camera only) ................6-50 僅...
Page 329 Driving your vehicle 僅 Safe Exit Warning operation ..............6-102 僅 Safe Exit Warning malfunction and limitations ......6-103 Safe Exit Assist (SEA) ..............6-105 僅 Safe Exit Assist settings................6-106 僅 Safe Exit Assist operation ................ 6-107 僅 Safe Exit Assist Malfunction and limitations ........6-108 Manual Speed Limit Assist (MSLA) ........
Page 330 Driving your vehicle Lane Following Assist (LFA) ............ 6-148 僅 Lane Following Assist settings ...............6-148 僅 Lane Following Assist operation............6-149 僅 Lane Following Assist malfunction and limitations......6-151 Highway Driving Assist (HDA)..........6-151 僅 Highway Driving Assist settings ............6-152 僅 Highway Driving Assist operation ............6-153 僅...
Page 331 Driving your vehicle Winter driving ................6-212 Vehicle weight ................6-216 僅 Base kerb weight..................6-216 僅 Vehicle kerb weight..................6-216 僅 Cargo weight....................6-216 僅 GAW (Gross axle weight)................6-216 僅 GAWR (Gross axle weight rating) ............6-216 僅 GVW (Gross vehicle weight)..............6-216 僅 GVWR (Gross vehicle weight rating) ...........6-216 僅...
Page 332: Driving Your Vehicle
僅 Check the condition of the tyres. checked as soon as possible by a profes- sional workshop. Kia recommends to 僅 Check under the vehicle for any sign visit an authorised Kia dealer/service of leaks.
Page 333 Driving your vehicle Before driving Before starting WARNING 僅 Close and lock all doors. Loose objects 僅 Position the seat so that all controls Securely store items in your vehicle. are easily reached. When you make a sudden stop or turn 僅...
Page 334: Key Positions
Driving your vehicle Key positions Key positions (if equipped) LOCK (1) The ignition key can be removed only in Your vehicle is equipped with four differ- the LOCK position. ent ignition positions. Illuminated ignition switch (if ACC (Accessory) (2) equipped) The electrical accessories are operative.
Page 335: 僅 Starting The Engine
Driving your vehicle Key positions WARNING NOTICE Key holder Kick down mechanism (if equipped) Do not attach small purses, multiple If your vehicle is equipped with a kick keys, or any other heavy accessories to down mechanism in the accelerator the driver's key chain used to start the pedal, it prevents you from driving at full vehicle.
Page 336 Driving your vehicle Key positions Starting the diesel engine Starting and stopping the engine for turbocharger intercooler To start the diesel engine when the engine is cold, it has to be pre-heated 1. Do not race or accelerate the engine before starting the engine and then immediately after starting.
Page 337: Engine Start/Stop Button
Try locking the steering wheel again. If the problem is not solved, have the system checked by a professional workshop. Kia recom- mends to visit a professional workshop. Kia recommends to visit an authorised OKA4050100R Kia dealer/service partner.
Page 338 Driving your vehicle ENGINE START/STOP button CAUTION Press the ENGINE START/STOP button In an emergency situation whilst the whilst it is in the ACC position without vehicle is in motion, you are able to turn depressing the brake pedal. the engine off and to the ACC position The warning lights can be checked by pressing the ENGINE START/STOP before the engine is started.
Page 339: 僅 Starting The Engine
Driving your vehicle ENGINE START/STOP button movement may occur if these precau- be easier to depress. This is not a mal- tions are not taken. function but a normal condition. 僅 Never reach for the ENGINE START/ STOP button or any other controls Starting the engine with smart through the steering wheel whilst the vehicle is in motion.
Page 340 Driving your vehicle ENGINE START/STOP button NOTICE CAUTION 僅 If the battery is weak or the smart key 僅 Do not press the ENGINE START/ does not work correctly, you can start STOP button for more than 10 sec- the engine by pressing the ENGINE onds except when the stop lamp fuse START/STOP button with the smart is blown.
Page 341 Driving your vehicle ENGINE START/STOP button Glow indicator light Starting and stopping the engine for turbocharger intercooler 1. Do not race or accelerate the engine immediately after starting. 3. Press the ENGINE START/STOP but- If the engine is cold, idle for several ton whilst depressing the brake pedal.
Page 342: Automatic Transmission (Shift Lever)
Driving your vehicle Automatic transmission (Shift Lever) For smooth operation, depress the brake Automatic transmission (Shift pedal when shifting from N (Neutral) to Lever) (if equipped) a forward or reverse gear. WARNING Automatic transmission 僅 Always check the surrounding areas near your vehicle for people, espe- cially children, before shifting a vehi- cle into D (Drive) or R (Reverse).
Page 343 Driving your vehicle Automatic transmission (Shift Lever) motion, except as explained in "Rocking Transmission ranges the vehicle" on page 6-209. The indicator in the instrument cluster displays the shift lever position when the ignition switch or ENGINE START/STOP N (Neutral) button is in the ON position.
Page 344 Driving your vehicle Automatic transmission (Shift Lever) D (Drive) 僅 Up (+): Push the lever forward once to shift up one gear. This is the normal forward driving posi- 僅 Down (-): Pull the lever backwards tion. The transmission will automatically once to shift down one gear.
Page 345: 僅 Shift Lock System
Driving your vehicle Automatic transmission (Shift Lever) Paddle shifter (if equipped) With the shift lever in the manual mode The paddle shift function is available when the shift lever is in the D (Drive) Pull the [+] or [-] paddle shifter once to position or the manual mode.
Page 346: 僅 Good Driving Practices
Kia recommends to visit an 僅 Optimum vehicle performance and authorised Kia dealer/service partner. economy is obtained by smoothly depressing and releasing the acceler- ator pedal.
Page 347 Driving your vehicle Automatic transmission (Shift Lever) WARNING WARNING 僅 When driving uphill or downhill, If your vehicle becomes stuck in snow, always shift to D (Drive) for driving mud, sand, etc., then you may attempt forward or shift to R (Reverse) for to rock the vehicle free by moving it for- driving backwards, and check the ward and backward.
Page 348: Automatic Transmission (Dial Sbw)
Driving your vehicle Automatic transmission (Dial SBW) For your safety, always depress the Automatic transmission (Dial brake pedal whilst shifting to another SBW) (if equipped) gear. The automatic transmission has 8 for- Transmission position ward speeds and one reverse speed. The individual speeds are selected auto- matically, depending on the balance between the fuel economy and the...
Page 349 Driving your vehicle Automatic transmission (Dial SBW) When the vehicle is over a certain speed, N (Neutral) the gear does not shift to P (Park) when The wheels and gear are not engaged. the P button is pressed. To shift to N (Neutral), turn the dial SBW to the [N] position whilst depressing the WARNING brake pedal.
Page 350 Driving your vehicle Automatic transmission (Dial SBW) 1. Deactivate the AUTO HOLD and 3. Shift the gear to the N (Neutral) posi- release the parking brake when the tion. If you want to keep the N position ENGINE START/STOP button is ON. after the engine is off, disconnect the battery from vehicle or refer to "Stay 2.
Page 351: 僅 Shift Lock System
Jump start your vehicle (refer to "Jump- whilst driving. starting" on page 7-5) or contact an 僅 When the vehicle speed decreases authorised Kia dealer/service partner. below 7 km/h (4 mph). LCD display messages NOTICE If a message appears on the LCD dis-...
Page 352 Driving your vehicle Automatic transmission (Dial SBW) Shifting conditions not met Shift to P after stopping OKA4051628R OMQ4051011L The message appears on the LCD dis- The message appears on the LCD dis- play in the following conditions: play when the gear is shifted to P (Park) whilst the vehicle is moving.
Page 353 The message is displayed when there is SBW. a problem with function engaging P (Park) position. Immediately have the vehicle inspected by an authorised Kia dealer/service part- Immediately have the vehicle inspected by an authorised Kia dealer/service part- ner. Rotary gear shifter dial stuck...
Page 354: 僅 Good Driving Practices
Driving your vehicle Automatic transmission (Dial SBW) Good driving practices WARNING 僅 Never move the shift dial from P 僅 When driving uphill or downhill, (Park) or N (Neutral) to any other always shift to D (Drive) for driving position with the accelerator pedal forward or shift to R (Reverse) for depressed.
Page 355: Brake System
Driving your vehicle Brake system Brake system WARNING Your vehicle has power-assisted brakes, If your vehicle becomes stuck in snow, parking brake, and various braking sys- mud, sand, etc., then you may attempt tems for safe driving. to rock the vehicle free by moving it for- ward and backward.
Page 356 Kia If service brakes fail to operate whilst the recommends to visit an authorised Kia vehicle is in motion, you can make an dealer/service partner. emergency stop with the parking brake.
Page 357 Driving your vehicle Brake system Always replace the front or rear brake The vent area of the outer vent-type pads as pairs. brake disc is exposed to the outside to improve the cooling performance of the CAUTION brake when driving.The exposed vent Replace brake pads area may become rusty but it will not affect the braking performance, and...
Page 358 Driving your vehicle Brake system Releasing the parking brake with WARNING EPB switch Risk of accident and injury due to chil- dren left unattended in the vehicle. If you leave children unaccompanied in the vehicle, they may be able to set the vehicle in motion, for example by: 僅...
Page 359 ENGINE START/STOP If the parking brake warning light is still button is turned off. on even though the EPB has been released, have the system checked by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner.
Page 360 Driving your vehicle Brake system 僅 A click or electric brake motor whine EPB warning sound may be heard whilst operating The EPB will display a warning message or releasing the EPB. These conditions with sound under certain conditions. are normal and indicate that the EPB 僅...
Page 361 Electronic Sta- by a professional workshop as soon as bility Control (ESC) signal, a warning will possible. Kia recommends to visit an sound and a message will appear. authorised Kia dealer/service partner. The EPB malfunction indicator may...
Page 362 EPB is used for emer- bonnet must be closed. gency braking, have your vehicle checked by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. When the EPB is not released...
Page 363 Driving your vehicle Brake system green indicating the AUTO HOLD is 僅 To cancel the Auto Hold operation engaged. The vehicle will remain at a when the vehicle is at a standstill, standstill even if you release the brake press the Auto Hold switch whilst pedal.
Page 364 僅 If the AUTO HOLD indicator lights up yellow, the Auto Hold is not working properly. Take your vehicle to a pro- fessional workshop and have the sys- tem checked. Kia recommends to visit an authorised Kia dealer/service part- ner. WARNING...
Page 365: 僅 Anti-Lock Brake System (Abs)
Driving your vehicle Brake system If you do not apply the brake pedal Anti-lock Brake System (ABS) when you release the Auto Hold by The Anti-lock Brake System (ABS) pre- pressing the [AUTO HOLD] switch, a vents the wheels from locking. So the warning will sound and a message will vehicle remains stable and can still be appear.
Page 366 ABS. Contact a professional begins to move after the vehicle is workshop as soon as possible. Kia rec- started. These conditions are normal ommends to visit an authorised Kia and indicate that the Anti-lock Brake dealer/service partner.
Page 367 Driving your vehicle Brake system ESC will not prevent accidents. Excessive NOTICE speed in turns, abrupt manoeuvres and A click sound may be heard in the vehi- hydroplaning on wet surfaces can still cle compartment when the vehicle result in serious accidents. begins to move after the vehicle is Only a safe and attentive driver can pre- started.
Page 368 Driving your vehicle Brake system ESC operation off ESC off state 2 This vehicle has 2 kinds of ESC off states. If the vehicle stops when ESC is off, ESC remains off. Upon restarting the vehicle, the ESC will automatically turn on again.
Page 369: 僅 Electronic Stability Control (Esc)
Driving your vehicle Brake system The ESC OFF indicator light comes on Multi-Collision Brake (MCB) (if when the ESC is turned off with the but- equipped) ton. Multi-Collision Brake controls the brake automatically in the event of an accident WARNING where the air bag deploys to reduce the Electronic Stability Control risk of additional accidents that may...
Page 370: 僅 Hill-Start Assist Control (Hac)
Driving your vehicle Brake system 僅 Ten seconds have passed since the pedal until you are ready to accelerate brake has been controlled automati- forward. cally by Multi-Collision Brake system. Vehicle Stability Management WARNING (VSM) system 僅 Multi-Collision Brake decreases vehi- The Vehicle Stability Management (VSM) cle speed after a collision and reduces provides further enhancements to vehi-...
Page 371: Driving Your Vehicle
僅 When the brake pedal is depressed fessional workshop and have the system strongly over a certain level. checked. Kia recommends to visit an authorised Kia dealer/service partner. 僅 When the friction of the road surface is above a certain level.
Page 372: 僅 Good Braking Practices
If so and call a professional workshop there is a risk that the parking brake for assistance. Kia recommends to may freeze, apply it only temporarily visit an authorised Kia dealer/service whilst you put the dial SBW in P and partner.
Page 373: Drive Mode Integrated Control System
Driving your vehicle Drive mode integrated control system Drive mode integrated control 僅 ECO mode : system ECO mode helps improve fuel effi- ciency for eco-friendly driving. Drive mode 僅 NORMAL mode : The drive mode may be selected accord- NORMAL mode provides smooth driv- ing to the driver's preference or road ing and comfortable riding.
Page 374 Driving your vehicle Drive mode integrated control system When ECO mode is activated: SMART mode 僅 The acceleration response may be SMART mode selects the slightly reduced as the accelerator proper driving mode pedal is depressed moderately. among ECO, NORMAL, and SPORT by judging the driver's driving habits (i.e.
Page 375 Driving your vehicle Drive mode integrated control system 僅 The driving mode automatically Various driving situations, which changes to SMART SPORT mode only you may encounter in SMART in harsh driving situations. In most of mode the normal driving situations, the driv- 僅...
Page 376 僅 If the detecting sensors have been replaced or repaired, have the vehicle inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. 僅 Never install any accessories or stick- ers on the front windscreen, or tint the front windscreen.
Page 377 Collision-Avoidance Assist is ON, have To select the Warning time 'Normal' or the vehicle inspected by a professional 'Late'. workshop. Kia recommends to visit an 僅 Normal: Use under normal driving authorised Kia dealer/service partner. conditions. If it feels too sensitive, set WARNING the warning timing to 'Late'.
Page 378 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Front view camera only) Volume to 'High', 'Medium' or 'Low' for Collision warning Forward Collision-Avoidance Assist. If you change the Warning Volume, the warning volume of other Driver Assis- tance systems may change. CAUTION 僅...
Page 379 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Front view camera only) assisted with strong braking power by 僅 With 'Active Assist' or 'Warning Only' the function to help prevent collision selected, when ESC is turned off by with the vehicle, pedestrian or cyclist pressing and holding the ESC OFF ahead.
Page 380 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Front view camera only) 僅 If any other function's warning mes- NOTICE sage is displayed or audible warning 僅 In a situation where collision is immi- is generated, Forward Collision-Avoid- nent, braking may be assisted by For- ance Assist warning message may not ward Collision-Avoidance Assist when be displayed and audible warning...
Page 381 僅 Street light or light from an oncoming inspected by a professional workshop. vehicle is reflected on the wet road Kia recommends to visit an authorised surface, such as a puddle on the road Kia dealer/service partner. 僅 An object is placed on the dashboard 僅...
Page 382 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Front view camera only) 僅 The surrounding is very dark, such as 僅 The vehicle in front is suddenly in a tunnel, etc. blocked by a obstacle 僅 The brightness changes suddenly, for 僅...
Page 383 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Front view camera only) The illustration above shows the image 僅 When driving in the following places the front view camera and front radar - Driving through steam, smoke or will detect as a vehicle, pedestrian and shadow cyclist.
Page 384 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Front view camera only) result in no warning, braking assist WARNING when necessary. 僅 Driving on a curved road When driving on a curved road, you must maintain a safe braking dis- tance, and if necessary, steer the vehi- cle and depress the brake pedal to reduce your driving speed in order to maintain a safe distance.
Page 385: Forward Collision-Avoidance Assist (Fca) (Front View Camera Only)
Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Front view camera only) Forward Collision-Avoidance Assist may detect a vehicle, pedestrian or cyclist in the next lane or outside the lane when driving on a curved road. If this occurs, Forward Collision-Avoid- ance Assist may unnecessarily warn the driver and control the brake.
Page 386 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Front view camera only) 僅 Changing lanes OMQ4H052602 [A]: Your vehicle, [B]: Lane changing OMQ4H052601 [A]: Your vehicle, [B]: Lane changing vehicle, vehicle [C]: Same lane vehicle When a vehicle moves into your lane When a vehicle [B] in front of you from an adjacent lane, it cannot be merges out of the lane, Forward Colli-...
Page 387: 僅 Forward Collision-Avoidance Assist Settings
Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Sensor fusion) If the vehicle in front of you has cargo Forward Collision-Avoidance that extends rearward from the cab, Assist (FCA) (Sensor fusion) (if or when the vehicle in front of you has equipped) higher ground clearance, additional special attention is required.
Page 388 Have the vehicle inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. 僅 The genuine Kia front radar sensor covers are parts with quality and per- formance ensured. If arbitrarily apply- OKA4052022N ing paint on or changing the cover,...
Page 389 ) remains ON when Forward Assist settings Collision-Avoidance Assist is ON, have Forward Safety the vehicle inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. WARNING When the engine is restarted, Forward Collision-Avoidance Assist will always turn on.
Page 390 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Sensor fusion) Volume to 'High', 'Medium' or 'Low' for Warning Timing Forward Collision-Avoidance Assist. If you change the Warning Volume, the warning volume of other Driver Assis- tance systems may change. CAUTION 僅 The setting of the Warning Timing and Warning Volume applies to all functions of Forward Collision-Avoid- ance Assist.
Page 391 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Sensor fusion) Emergency Braking will be activated in Collision warning following conditions and your vehicle speed. 僅 For vehicle: 10~85 km/h (6~53 mph) 僅 For pedestrians and cyclists in front, it works when the speed of your vehicle is approximately 10~65 km/h (6~40 mph).
Page 392 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Sensor fusion) Junction Turning function Emergency braking Warning and control The basic function for Junction Turning function is warned and controlled by the following level. 僅 Collision Warning 僅 Emergency Braking 僅 Stopping vehicle and ending brake control Collision warning OKA4050125L...
Page 393 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Sensor fusion) For your safety, the driver should reduce driving speed or to stop the depress the brake pedal immediately vehicle. and check the surroundings. 僅 Never deliberately operate Forward 僅 Brake control will end after the vehicle Collision-Avoidance Assist on people, is stopped by emergency braking for objects, etc.
Page 394: 僅 Forward Collision-Avoidance Assist Malfunction And Limitations
Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Sensor fusion) Forward Collision-Avoidance WARNING Assist malfunction and limitations 僅 Even if there is a problem with For- Forward Collision-Avoidance ward Collision-Avoidance Assist, the vehicle's basic braking performance Assist malfunction will operate normally. 僅...
Page 395 僅 An object is placed on the dashboard workshop. Kia recommends to visit an 僅 Your vehicle is being towed authorised Kia dealer/service partner. 僅 The surrounding is very bright WARNING 僅...
Page 396 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Sensor fusion) 僅 The brightness outside is low, and the 僅 The cyclist in front is on a bicycle headlamps are not on or are not made of material that does not reflect bright on the front radar 僅...
Page 397 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Sensor fusion) The illustration above shows the image 僅 When driving in the following places the front view camera and front radar - Driving through steam, smoke or will detect as a vehicle, pedestrian and shadow cyclist.
Page 398 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Sensor fusion) result in no warning, braking assist WARNING when necessary. 僅 Driving on a curved road When driving on a curved road, you must maintain a safe braking dis- tance, and if necessary, steer the vehi- cle and depress the brake pedal to reduce your driving speed in order to maintain a safe distance.
Page 399 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Sensor fusion) Forward Collision-Avoidance Assist may detect a vehicle, pedestrian or cyclist in the next lane or outside the lane when driving on a curved road. If this occurs, Forward Collision-Avoid- ance Assist may unnecessarily warn the driver and control the brake.
Page 400 Driving your vehicle Forward Collision-Avoidance Assist (FCA) (Sensor fusion) 僅 Changing lanes OMQ4H052611 [A]: Your vehicle, [B]: Lane changing OMQ4H052610 [A]: Your vehicle, [B]: Lane changing vehicle, vehicle [C]: Same lane vehicle When a vehicle moves into your lane When a vehicle in front of you merges from an adjacent lane, it cannot be out of the lane, Forward Collision- detected by the sensor until it is in the...
Page 401: Lane Keeping Assist (Lka) (If
Driving your vehicle Lane Keeping Assist (LKA) or when the vehicle in front of you has Lane Keeping Assist (LKA) (if higher ground clearance, additional equipped) special attention is required. Forward Lane Keeping Assist is designed to help Collision-Avoidance Assist may not be detect lane markings (or road edges) able to detect the cargo extending whilst driving over a certain speed.
Page 402: 僅 Lane Keeping Assist Settings
Driving your vehicle Lane Keeping Assist (LKA) Lane Keeping Assist settings Turning On/Off (Lane Safety but- ton) Lane Safety [Except Europe/Australia/Russia] OKA4050546N OKA4051024R With the engine on, select or deselect With the vehicle in the ON position, 'Driver Assistance → Lane Safety' from press the Lane Safety button located on the Settings menu to set whether or not the instrument panel to turn on Lane...
Page 403 Driving your vehicle Lane Keeping Assist (LKA) Turning On/Off (Lane Driving Warning Volume Assist button) [For Europe/Australia/Russia] OMQ4041606 With the engine on, select 'Driver Assis- tance → Warning Volume from the Set- OMQ4051135 tings menu to change the Warning With the vehicle in the ON position, Volume to 'High', 'Medium' or 'Low' for press and hold the Lane Driving Assist Lane Keeping Assist.
Page 404 Driving your vehicle Lane Keeping Assist (LKA) Right Hands-off warning OKA4050127 OMQ4051155L Lane Keeping Assist will warn and con- If the driver takes their hands off the trol the vehicle with Lane Departure steering wheel for several seconds, the Warning and Lane Keeping Assist. warning message will appear on the cluster, and an audible warning will Lane Departure Warning...
Page 405: 僅 Lane Keeping Assist Malfunction And Limitations
OKA4050128 appear and the yellow ( ) indicator Lane detected light will appear on the cluster. If this occurs, have the function inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. OKA4050169...
Page 406 Driving your vehicle Lane Keeping Assist (LKA) Limitations of Lane Keeping 僅 There is a boundary structure in the roadway, such as a tollgate, sidewalk, Assist kerb, etc. Lane Keeping Assist may not operate 僅 The vehicle is driving to the bus lane, normally or may operate unexpectedly or driving at the left or right side of under the following circumstances:...
Page 407: Blind-Spot Collision Warning (Bcw)
Driving your vehicle Blind-Spot Collision Warning (BCW) 僅 If any other function's warning mes- Blind-Spot Collision Warning sage is displayed or audible warning (BCW) (if equipped) is generated, Lane Keeping Assist Blind-Spot Collision Warning is designed warning message may not be dis- to help detect and monitor approaching played and audible warning may not vehicles in the driver's blind spot area...
Page 408 Kia recommends to visit an authorised CAUTION Kia dealer/service partner. Warning timing may vary depending on 僅 The genuine Kia rear bumpers which the speed of the vehicle approaching at the Rear corner radar sensors are high speed. mounted are parts with quality and performance ensured.
Page 409 Driving your vehicle Blind-Spot Collision Warning (BCW) Blind-Spot Collision Warning set- Collision Warning off, the outside rear- view mirror will blink for 3 seconds. It tings means the function is operated. Blind-Spot Safety When the engine is restarted with Blind- Spot Collision Warning off, the 'Blind- Spot Safety System is Off' message will appear on the cluster.
Page 410 Driving your vehicle Blind-Spot Collision Warning (BCW) Warning Volume Blind-Spot Collision Warning operation Warning Blind-Spot Collision Warning will warn and control as following operation. 僅 Vehicle detection 僅 Collision warning Vehicle detection OMQ4041606 With the engine on, select 'Driver Assis- tance →...
Page 411 ) will appear. Have Blind-Spot signal will not operate. Collision Warning be inspected by a pro- fessional workshop. Kia recommends to NOTICE visit an authorised Kia dealer/service partner. 僅 If the driver's seat is on the left side, the collision warning may occur when you turn left.
Page 412 Have Blind-Spot Collision Warning be 僅 Even though the warning message inspected by a professional workshop. does not appear on the cluster, Blind- Kia recommends to visit an authorised Spot Collision Warning may not prop- Kia dealer/service partner. erly operate.
Page 413 Driving your vehicle Blind-Spot Collision Warning (BCW) entry barriers, street lamps, signs, 僅 A big vehicle such as a bus or truck is tunnels, walls, etc. (including double detected structures) 僅 A moving obstacle such as a pedes- 僅 Driving through a narrow road where trian, animal, shopping cart or a baby trees or grass are overgrown stroller is detected...
Page 414 Driving your vehicle Blind-Spot Collision Warning (BCW) Blind-Spot Collision Warning may not Blind-Spot Collision Warning may not operate properly when driving on a operate properly when driving on a curved road. Blind-Spot Collision sloped road. Blind-Spot Collision Warning may detect a vehicle in the Warning may not detect the vehicle in same lane.
Page 415: Blind-Spot Collision-Avoidance Assist (Bca)
Driving your vehicle Blind-Spot Collision-Avoidance Assist (BCA) Blind-Spot Collision-Avoid- WARNING ance Assist (BCA) (if 僅 When you are towing a trailer or equipped) another vehicle, make sure that you turn off Blind-Spot Collision Warning. Blind-Spot Collision-Avoidance Assist is Control safety may be reduced. designed to help detect and monitor approaching vehicles in the driver's blind 僅...
Page 416 Driving your vehicle Blind-Spot Collision-Avoidance Assist (BCA) OMQ4H052613 OMQ4H052615 Blind-Spot Collision-Avoidance Assist When you are driving forward, if the helps detect and informs the driver that function judges that there is a collision a vehicle is approaching at high speed risk with an approaching vehicle in the from the blind spot area.
Page 417 Kia recommends to visit an authorised Kia dealer/service partner. 僅 The genuine Kia rear bumpers which the Rear corner radar sensors are mounted are parts with quality and OMQ4AH050349 performance ensured.
Page 418 Driving your vehicle Blind-Spot Collision-Avoidance Assist (BCA) 僅 If 'Active Assist' is selected, the func- Warning Timing tion will warn the driver with a warn- ing message, an audible warning, and braking assist will be applied depend- ing on the collision risk levels. 僅...
Page 419 Driving your vehicle Blind-Spot Collision-Avoidance Assist (BCA) Warning Volume Blind-Spot Collision-Avoidance Assist operation Warning and control Blind-Spot Collision-Avoidance Assist will warn and control as following opera- tion. 僅 Vehicle detection 僅 Collision warning 僅 Collision-Avoidance Assist Vehicle detection OMQ4041606 With the engine on, select 'Driver Assis- tance →...
Page 420 Driving your vehicle Blind-Spot Collision-Avoidance Assist (BCA) 僅 When the turn signal is turned off or Collision-Avoidance Assist (whilst you move away from the lane, the col- driving) lision warning will be cancelled and the function will return to vehicle detection state.
Page 421 Driving your vehicle Blind-Spot Collision-Avoidance Assist (BCA) - Forward Collision-Avoidance Assist Stopping vehicle and ending is operating brake control 僅 After Blind-Spot Collision-Avoidance Assist operation or changing lane, you must drive to the centre of the lane. The function will not operate if the vehicle is not driven in the centre of the lane.
Page 422: 僅 Blind-Spot Collision-Avoidance Assist Malfunction And Limitations
Blind-Spot Collision-Avoidance Assist be vehicle. Do not depend on Blind-Spot inspected by a professional workshop. Collision-Avoidance Assist. Pay atten- Kia recommends to visit an authorised tion around the vehicle and drive Kia dealer/service partner. safety. 僅 Never test Blind-Spot Collision-Avoid- ance Assist on people, objects.
Page 423 Driving your vehicle Blind-Spot Collision-Avoidance Assist (BCA) mends to visit an authorised Kia dealer/ master warning light ( ) will appear. service partner. Have Blind-Spot Collision-Avoidance WARNING Assist be inspected by a professional workshop. Kia recommends to visit an 僅 Even though the warning message authorised Kia dealer/service partner.
Page 424 Driving your vehicle Blind-Spot Collision-Avoidance Assist (BCA) components (i.e. possibly due to sub- When the following objects are detected: way construction). 僅 A motorcycle or bicycle is detected 僅 There is a fixed object near the vehi- 僅 A vehicle such as a flat trailer is cle, such as sound barriers, guardrails, detected double guardrails, central dividers,...
Page 425 Driving your vehicle Blind-Spot Collision-Avoidance Assist (BCA) 僅 Driving where the road is merging/ WARNING dividing 僅 Driving on a curved road OMQ4H052618 OMQ4H052616 Blind-Spot Collision-Avoidance Assist Blind-Spot Collision-Avoidance Assist may not operate properly when driv- may not operate properly when driv- ing where the road merges or divides.
Page 426 Driving your vehicle Blind-Spot Collision-Avoidance Assist (BCA) Always pay attention to road and driv- WARNING ing conditions whilst driving on a 僅 When you are towing a trailer or sloped road. another vehicle, make sure that you 僅 Driving where the heights of the lanes turn off Blind-Spot Collision-Avoid- are different ance Assist.
Page 427: Safe Exit Warning (Sew) (If
Driving your vehicle Safe Exit Warning (SEW) The rear corner radars are sensors Safe Exit Warning (SEW) (if located inside the rear bumper to detect equipped) the side and rear areas. Always keep the rear bumper clean for proper operation of Safe Exit Warning.
Page 428 Driving your vehicle Safe Exit Warning (SEW) 僅 When an approaching vehicle from Warning Volume the rear is detected, the 'Watch (out) for traffic' warning message will appear on the cluster, and an audible warning will sound. 僅 Safe Exit Warning will warn the driver when your vehicle speed is below 3 km/h (2 mph), and the speed of the approaching vehicle from the rear is...
Page 429: 僅 Safe Exit Warning Malfunction And Limitations
Assist. There may be limited. Have the vehicle inspected by a a problem with Blind-Spot Collision professional workshop. Kia recommends Warning or Blind-Spot Collision- to visit an authorised Kia dealer/service Avoidance Assist when: partner. - Blind-Spot Collision Warning or Blind-Spot Collision-Avoidance...
Page 430 Driving your vehicle Safe Exit Warning (SEW) WARNING NOTICE 僅 Even though the warning message For more details on the precautions of does not appear on the cluster, Safe the rear corner radars, refer to "Blind- Exit Warning may not properly oper- Spot Collision Warning (BCW) (if ate.
Page 431: Safe Exit Assist (Sea) (If
Driving your vehicle Safe Exit Assist (SEA) Safe Exit Assist (SEA) (if equipped) OKA4040028 1 Left power sliding door control button 2 Right power sliding door control but- OKA4041021 After the vehicle stops, when an approaching vehicle from the rear area In addition, this driving safety system is detected as soon as a driver or a pas- keeps the door closed even though the...
Page 432 Driving your vehicle Safe Exit Assist (SEA) Assist' from the Settings menu to turn on Detecting sensor Safe Exit Assist and deselect to turn off Rear corner radar the function. WARNING The driver should always be aware of unexpected and sudden situations from occurring.
Page 433 Driving your vehicle Safe Exit Assist (SEA) Safe Exit Assist operation NOTICE Warning and control If you manually open the sliding door by pulling the inside or outside door handle, the door will open regardless of the Safe Collision warning when exiting Exit Assist.
Page 434: 僅 Safe Exit Assist Malfunction And Limitations
Driving your vehicle Safe Exit Assist (SEA) 僅 Safe Exit Assist does not operate if to visit an authorised Kia dealer/service there is a problem with Blind-Spot partner. Collision-Avoidance Assist. There may be a problem with Blind-Spot Colli- Safe Exit Assist disabled...
Page 435: Manual Speed Limit Assist (Msla)
Driving your vehicle Manual Speed Limit Assist (MSLA) Manual Speed Limit Assist WARNING (MSLA) (if equipped) 僅 Even though the warning message does not appear on the cluster, Safe Exit Assist may not properly operate. 僅 Safe Exit Assist may not properly operate in an area (e.g., open terrain), where any substance are not detected right after the engine is turned on, or...
Page 436: 僅 Manual Speed Limit Assist Operation
Driving your vehicle Manual Speed Limit Assist (MSLA) The speed limit indicator ( light will appear on the cluster. 2. Push the + switch up or - switch down, and release it at the desired speed. Move the + switch up or - switch down and hold it.
Page 437 Driving your vehicle Manual Speed Limit Assist (MSLA) Resuming Manual Speed Limit WARNING Assist Take the following precautions when using Manual Speed Limit Assist: 僅 Always set the vehicle speed to the speed limit in your country. 僅 Keep Manual Speed Limit Assist off when the system is not in use, to avoid inadvertently setting a speed.
Page 438: Intelligent Speed Limit Assist (Isla)
Driving your vehicle Intelligent Speed Limit Assist (ISLA) Intelligent Speed Limit Assist Intelligent Speed Limit Assist set- tings (ISLA) (if equipped) Intelligent Speed Limit Assist uses infor- Speed limit mation from the detected road sign and navigation system to inform the driver of the speed limit and additional road signs of the current road.
Page 439: 僅 Intelligent Speed Limit Assist Operation
Driving your vehicle Intelligent Speed Limit Assist (ISLA) Speed limit offset NOTICE With the vehicle on, when 'Driver Assis- Intelligent Speed Limit Assist warning tance → Speed Limit → Speed Limit Off- and control are described based on the set' is selected, the Speed Limit Offset Offset set to '0'.
Page 440 Driving your vehicle Intelligent Speed Limit Assist (ISLA) Changing set speed NOTICE 僅 If speed limit information of the road cannot be recognised, '---' sign will be displayed. Please refer to "Limitations of Intelligent Speed Limit Assist" if the road signs are difficult to recognise. 僅...
Page 441: 僅 Intelligent Speed Limit Assist Malfunction And Limitations
If this occurs, the speed unit used in your country, have the vehicle inspected by a profes- Intelligent Speed Limit Assist may not sional workshop. Kia recommends to operate properly. visit an authorised Kia dealer/service partner.
Page 442 僅 The vehicle encounters illuminating sional workshop. Kia recommends to road signs visit an authorised Kia dealer/service 僅 Intelligent Speed Limit Assist incor- partner.
Page 443: Driver Attention Warning (Daw)
Driving your vehicle Driver Attention Warning (DAW) 僅 There is an error in the navigation Driver Attention Warning map information or GPS information (DAW) (if equipped) 僅 The driver is not driving along the navigation guide route Basic function 僅 Driving on a newly opened road Driver Attention Warning will help deter- WARNING mine the driver's attention level by ana-...
Page 444: 僅 Driver Attention Warning Operation
Driving your vehicle Driver Attention Warning (DAW) Leading Vehicle Departure Alert CAUTION Always keep the front view camera in good condition to maintain optimal per- formance of Driver Attention Warning. For more details on the precautions of the front view camera, refer to "Forward Collision-Avoidance Assist (FCA) (Front view camera only) (if equipped)"...
Page 445 Driving your vehicle Driver Attention Warning (DAW) Attentive driving NOTICE If you change the Warning Timing, the warning time of other Driver Assistance systems may change. Driver Attention Warning opera- tion Basic function Display and warning The basic functions of the Driver Atten- tion Warning include: OMQ4050114L 僅...
Page 446 Driving your vehicle Driver Attention Warning (DAW) Taking a break NOTICE 僅 For more details on setting the instru- ment cluster, refer to "User settings mode" on page 4-82. 僅 Driver Attention Warning will reset the last break time to 00:00 in the follow- ing situations: - The engine is turned off - The driver unfastens the seat belt...
Page 447 Driving your vehicle Driver Attention Warning (DAW) 僅 The driver should hold the responsi- mends to visit an authorised Kia dealer/ bility to safely drive and control the service partner. vehicle. Limitations of Driver Attention Warning CAUTION Driver Attention Warning may not work 僅...
Page 448 Driving your vehicle Driver Attention Warning (DAW) If a vehicle cuts in front of your vehi- 僅 When a pedestrian or bicycle is cle, Leading Departure Alert may not between you and the vehicle ahead operate properly. 僅 When the vehicle ahead sharply steers OKA4050042 If there is a pedestrian(s) or bicycle(s)
Page 449: Blind-Spot View Monitor (Bvm)
Driving your vehicle Blind-Spot View Monitor (BVM) 僅 When driving at a tollgate or intersec- Blind-Spot View Monitor tion, etc. (BVM) (if equipped) Left side OMQ4H052627 If you pass a tollgate or intersection with lots of vehicles or you drive where lanes are merged or divided OKA4051527L frequently, Leading Vehicle Departure...
Page 450 Driving your vehicle Blind-Spot View Monitor (BVM) Detecting sensor Blind-Spot View Monitor opera- tion Wide-side view camera Turn signal switch OKA4052045N OKA4040097 (camera located at bottom of the mirror) Blind-Spot View Monitor will turn on and Refer to the picture above for the off when the turn signal is turned on and detailed location of the detecting sen- off.
Page 451: Cruise Control (Cc) (If
Kia recommends to visit an authorised Kia dealer/service partner. WARNING 僅 If the camera lens is covered with for- eign material, Blind-Spot View Moni- tor may not operate normally.
Page 452 Driving your vehicle Cruise Control (CC) Vehicle speed will maintain the set To decrease set speed speed even when the accelerator pedal is not depressed. NOTICE On a steep sloped road, the vehicle may slightly slow down or speed up whilst driving uphill or downhill.
Page 453 NOTICE If Cruise Control pauses during a situa- tion that is not mentioned, have the vehicle be inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. OKA4040555N Press the Driving Assist button to turn Cruise Control off. The Cruise ) indicator will go off.
Page 454: Smart Cruise Control (Scc) (If
Driving your vehicle Smart Cruise Control (SCC) Smart Cruise Control (SCC) (if WARNING equipped) Take the following precautions when using Cruise Control: Basic function 僅 Always set the vehicle speed under the speed limit in your country. Smart Cruise Control is designed to detect the vehicle ahead and help main- 僅...
Page 455: 僅 Smart Cruise Control Settings
Driving your vehicle Smart Cruise Control (SCC) Front radar Smart Cruise Control settings To turn on Smart Cruise Control OKA4052022N The front view camera and front radar OKA4040555N are used as a detecting sensor to detect Press the Driving Assist button to turn the vehicles in front.
Page 456 Driving your vehicle Smart Cruise Control (SCC) To set vehicle distance To increase set speed OKA4040559N OKA4040558N Each time the button is pressed, the Push the + switch up and release it vehicle distance changes as follows: immediately. The set speed will increase by 1 km/h (1 mph) each time the switch is operated in this manner.
Page 457 Driving your vehicle Smart Cruise Control (SCC) Push the - switch down and release it push the ( ) switch, vehicle speed immediately. The set speed will decrease will resume to the preset speed. by 1 km/h (1 mph) each time the switch WARNING is operated in this manner.
Page 458 Driving your vehicle Smart Cruise Control (SCC) 僅 Your vehicle speed is within the oper- NOTICE ating speed range 僅 For more details on Drive Mode, refer - When there is no vehicle in front: to "Drive mode integrated control sys- 10~180 km/h (5~110 mph) tem"...
Page 459 Driving your vehicle Smart Cruise Control (SCC) 2 Set speed is displayed. WARNING 3 Whether there is a vehicle ahead and 僅 When the turn signal lever is pulled the selected target distance are dis- towards the driver whilst there is a played.
Page 460 Driving your vehicle Smart Cruise Control (SCC) To temporarily accelerate Smart Cruise Control temporarily cancelled OMQ4PH052376L If you want to speed up temporarily OMQ4050134R when Smart Cruise Control is on, Smart Cruise Control will be temporarily depress the accelerator pedal. Whilst the cancelled automatically when: speed is increasing, the set speed, dis- 僅...
Page 461 Driving your vehicle Smart Cruise Control (SCC) pedal to reduce your driving speed in In addition, after the vehicle has stopped order to maintain a safe distance. and a certain time have passed, a warn- ing message like above will appear on the cluster.
Page 462 Driving your vehicle Smart Cruise Control (SCC) 僅 The accelerator pedal is depressed WARNING right after Smart Cruise Control is Always pay attention to vehicles or turned on objects that may suddenly appear in front of you, and if necessary, depress WARNING the brake pedal to reduce your driving speed in order to maintain a safe dis-...
Page 463 Have the be generated. vehicle inspected by a professional workshop. Kia recommends to visit an 僅 You may not hear the warning sound authorised Kia dealer/service partner. of Smart Cruise Control if the sur- rounding is noisy.
Page 464 Driving your vehicle Smart Cruise Control (SCC) Smart Cruise Control disabled Limitations of Smart Cruise Con- trol Smart Cruise Control may not operate normally under the following circum- stances: 僅 The detecting sensor or the surround- ings are contaminated or damaged 僅...
Page 465 Driving your vehicle Smart Cruise Control (SCC) 僅 The rear of the front vehicle is small or 僅 Your vehicle is moving unstable or does not look normal (i.e. tilted, over- vibrating excessively turned, etc.) 僅 Your vehicle height is low or high due 僅...
Page 466 Driving your vehicle Smart Cruise Control (SCC) 僅 Driving on a curved road your driving speed in order to main- tain a safe distance. 僅 Driving on an inclined road OMQ4H052608 On curved roads, Smart Cruise Con- trol may not detect a vehicle in the OMQ4H052609 same lane, and may accelerate to the During uphill or downhill driving, the...
Page 467 Driving your vehicle Smart Cruise Control (SCC) [A]: Your vehicle - Vehicles with small rear profile, such as trailers [B]: Lane changing vehicle - Narrow vehicles, such as motorcy- When a vehicle moves into your lane cles or bicycles from an adjacent lane, it cannot be detected by the sensor until it is in the - Special vehicles sensor's detection range.
Page 468: Navigation-Based Smart Cruise Control (Nscc)
Driving your vehicle Navigation-based Smart Cruise Control (NSCC) Always pay attention to road and driv- Navigation-based Smart ing conditions whilst driving. Cruise Control (NSCC) (if equipped) Navigation-based Smart Cruise Control will help automatically adjust vehicle speed when driving on highways (or motorways) by using road information from the navigation function whilst Smart Cruise Control is operating.
Page 469 Driving your vehicle Navigation-based Smart Cruise Control (NSCC) Highway Curve Zone Auto Slow- Navigation-based Smart Cruise down Control operation If vehicle speed is high, Highway Curve Operating conditions Zone Auto Slowdown function will tem- Navigation-based Smart Cruise Control porarily decelerate your vehicle or limit is ready to operate if all of the following acceleration to help you drive safely on a conditions are satisfied:...
Page 470 Driving your vehicle Navigation-based Smart Cruise Control (NSCC) 僅 Navigation-based Smart Cruise Con- Navigation-based Smart Cruise trol is not able to slow down your Control operating vehicle to a safe speed. NOTICE Highway Curve Zone Auto Slowdown and Set Speed Auto Change function uses the same ( ) symbol.
Page 471: 僅 Limitations Of Navigation-Based Smart Cruise Control
Driving your vehicle Navigation-based Smart Cruise Control (NSCC) state by driving on a road other than NOTICE the highway (or motorway) main road, The images or colours may be displayed Highway Set Speed Auto Change differently depending on the specifica- function will operate again when you tions of the instrument panel or theme.
Page 472 Driving your vehicle Navigation-based Smart Cruise Control (NSCC) 僅 The navigation is being restarted whilst driving 僅 The speed limit of some sections changes according to the road situa- tions 僅 Driving on a road under construction 僅 Driving on a road that is controlled 僅...
Page 473: Driving Your Vehicle
Driving your vehicle Navigation-based Smart Cruise Control (NSCC) on the curve information on the main 僅 The vehicle will accelerate if the driver road. depresses the accelerator pedal whilst Navigation-based Smart Cruise Con- 僅 Even if you depart from the main trol is operating, and the function will road, Highway Curve Zone Auto Slow- not decelerate the vehicle.
Page 474: Lane Following Assist (Lfa) (If
Driving your vehicle Lane Following Assist (LFA) Lane Following Assist (LFA) (if Lane Following Assist settings equipped) Turning Lane Following Assist Lane Following Assist is designed to help On/Off detect lane markings and/or vehicles on the road, and assists the driver's steering to help keep the vehicle between lanes.
Page 475 Driving your vehicle Lane Following Assist (LFA) If you change the Warning Volume, the Hands-off warning warning volume of other Driver Assis- tance systems may change. NOTICE If the engine is restarted, Warning Vol- ume will maintain the last setting. Lane Following Assist operation Warning and control Lane Following Assist...
Page 476 Driving your vehicle Lane Following Assist (LFA) Lane undetected WARNING 僅 The steering wheel may not be assisted if the steering wheel is held very tight or the steering wheel is steered over a certain degree. 僅 Lane Following Assist does not oper- ate at all times.
Page 477: Highway Driving Assist (Hda)
) will appear on the cluster. If this way). occurs, have the vehicle inspected by a professional workshop. Kia recommends Detecting sensor to visit an authorised Kia dealer/service Front view camera partner. Limitations of Lane Following Assist For more details on function limitations, refer to "Lane Keeping Assist (LKA) (if...
Page 478 僅 If there is a problem with the func- tions, the settings cannot be changed. Have the vehicle inspected by a pro- fessional workshop. Kia recommends to visit an authorised Kia dealer/ser- OKA4052022N vice partner. Refer to the picture above for the 僅...
Page 479 Driving your vehicle Highway Driving Assist (HDA) 僅 Highway Driving Assist indicator Highway Driving Assist operation - Green ( ): Operating state Basic function - White ( ): Standby state Highway Driving Assist display 2 Set speed is displayed. and control 3 Lane Following Assist indicator dis- You can see the status of the Highway played.
Page 480 Driving your vehicle Highway Driving Assist (HDA) 僅 First stage: Warning message Restarting after stopping 僅 Second stage: Warning message (red steering wheel) and audible warning OMQ4050288L When Highway Driving Assist is operat- ing, your vehicle will stop if the vehicle OMQ4051219R ahead of you stops.
Page 481 Have the vehi- tently operate or turn off depending cle inspected by a professional work- on road conditions (navigation infor- shop. Kia recommends to visit an mation) and surroundings. authorised Kia dealer/service partner. 僅 Lane Following Assist function may be...
Page 482 Driving your vehicle Highway Driving Assist (HDA) conditions. Always have your hands 僅 The road is temporarily controlled due on the steering wheel whilst driving. to construction, etc. 僅 For your safety, please read the 僅 There is no structure, such as a owner's manual before using the medium strip, guardrails, etc., on the Highway Driving Assist.
Page 483 Driving your vehicle Rear Cross-Traffic Collision-Avoidance Warning (RCCW) Rear Cross-Traffic Collision- Detecting sensor Avoidance Warning (RCCW) Rear corner radar (if equipped) Rear Cross-Traffic Collision-Avoidance Warning is designed to help detect vehi- cles approaching from blind spot area whilst your vehicle is reversing, and warn the driver that a collision is immi- nent with a warning message and an audible warning.
Page 484 Driving your vehicle Rear Cross-Traffic Collision-Avoidance Warning (RCCW) Avoidance Warning and deselect to turn Warning Volume off the function. WARNING When the engine is restarted, Rear Cross-Traffic Collision-Avoidance Warn- ing will automatically turn on. However, if 'Off' is selected after the engine is restarted, the driver should always be aware of the surroundings and drive safely.
Page 485 Driving your vehicle Rear Cross-Traffic Collision-Avoidance Warning (RCCW) on the infotainment system screen. (if Rear Cross-Traffic Collision- equipped) Avoidance Warning operation 僅 Rear Cross-Traffic Collision-Avoid- Warning ance Warning will operate when all Rear Cross-Traffic Collision-Avoidance the following conditions are satisfied: Warning will warn and control the vehi- - The gear is shifted to R (Reverse) cle depending on collision level...
Page 486 Rear Cross-Traffic Collision-Avoidance Warning (RCCW) situations or cannot avoid all colli- a professional workshop. Kia recom- sions. mends to visit an authorised Kia dealer/ service partner. 僅 The driver should hold the responsi- bility to control the vehicle. Do not solely depend on Rear Cross-Traffic Collision-Avoidance Warning.
Page 487 "Blind-Spot after it is removed, have the vehicle Collision Warning (BCW) (if equipped)" inspected by a professional workshop. on page 6-81. Kia recommends to visit an authorised Kia dealer/service partner. WARNING WARNING 僅 Driving near a vehicle or structure 僅...
Page 488 Driving your vehicle Rear Cross-Traffic Collision-Avoidance Warning (RCCW) Always check your surroundings Rear Cross-Traffic Collision-Avoid- whilst backing up. ance Warning may be limited when backing up diagonally, and may not 僅 When the vehicle is in a complex detect the vehicle approaching from parking environment the blind spot area.
Page 489 Driving your vehicle Rear Cross-Traffic Collision-Avoidance Warning (RCCW) backwards into a parking space. If this WARNING occurs, Rear Cross-Traffic Collision- 僅 Pulling into the parking space where Avoidance Warning may unnecessar- there is a structure ily warn the driver. Always check your surroundings whilst backing up.
Page 490: Rear Cross-Traffic Collision-Avoidance Warning (Rccw)
Driving your vehicle Rear Cross-Traffic Collision-Avoidance Assist (RCCA) Rear Cross-Traffic Collision- Detecting sensor Avoidance Assist (RCCA) (if Rear corner radar equipped) Rear Cross-Traffic Collision-Avoidance Assist is designed to help detect vehicles approaching from blind spot area whilst your vehicle is reversing, and warn the driver that a collision is imminent with a warning message and an audible warn- ing.
Page 491 Driving your vehicle Rear Cross-Traffic Collision-Avoidance Assist (RCCA) Avoidance Assist and deselect to turn off Warning Volume the function. WARNING When the engine is restarted, Rear Cross-Traffic Collision-Avoidance Assist will automatically turn on. You can turn off the system by unchecking it in the settings menu, but always drive with caution as the system will not help you in this case.
Page 492 Driving your vehicle Rear Cross-Traffic Collision-Avoidance Assist (RCCA) will sound. If the Rear View Monitor is Rear Cross-Traffic Collision- operating, a warning will also appear Avoidance Assist operation on the infotainment system screen. (if Warning and control equipped) Rear Cross-Traffic Collision-Avoidance 僅...
Page 493 Driving your vehicle Rear Cross-Traffic Collision-Avoidance Assist (RCCA) WARNING Brake control will end at blind spot area when: 僅 The approaching vehicle is out of the detecting range 僅 The approaching vehicle passes behind your vehicle 僅 The approaching vehicle does not drive toward your vehicle 僅...
Page 494 Driving your vehicle Rear Cross-Traffic Collision-Avoidance Assist (RCCA) - During emergency braking, braking excessively depresses the accelerator control by the function will auto- pedal. matically cancel when the driver 僅 The driver should hold the responsi- excessively depresses the brake bility to control the vehicle.
Page 495: 僅 Rear Cross-Traffic Collision-Avoidance Assist Malfunction And Limitations
) will appear Rear Cross-Traffic Collision- on the cluster. Have the vehicle Avoidance Assist malfunction inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. Rear Cross-Traffic Collision- Avoidance Assist disabled OMQ4050290R When Rear Cross-Traffic Collision-...
Page 496 僅 Driving on a slippery surface due to Kia recommends to visit an authorised snow, water puddle, ice, etc. Kia dealer/service partner. 僅 The tyre pressure is low or a tyre is...
Page 497 Driving your vehicle Rear Cross-Traffic Collision-Avoidance Assist (RCCA) 僅 When the vehicle is in a complex backing up diagonally, and may not parking environment detect the vehicle approaching from the blind spot area. If this occurs, the function may not warn the driver or control the brakes when necessary.
Page 498 Driving your vehicle Rear Cross-Traffic Collision-Avoidance Assist (RCCA) 僅 When the vehicle is parked backward WARNING 僅 Pulling into the parking space where there is a structure OMQ4H052640 Rear Cross-Traffic Collision-Avoid- ance Assist may detect vehicles pass- OMQ4H052639 ing by behind you when parking [A]: Structure, [B]: Wall backwards into a parking space.
Page 499: Reverse Parking Collision-Avoidance Assist (Pca)
Driving your vehicle Reverse Parking Collision-Avoidance Assist (PCA) Reverse Parking Collision- Reverse Parking Collision-Avoid- ance Assist settings Avoidance Assist (PCA) (if equipped) Parking Safety Reverse Parking Collision-Avoidance Assist will can warn the driver or assist with braking to help reduce the possibil- ity of collision with a pedestrian or an object when backing up.
Page 500 Driving your vehicle Reverse Parking Collision-Avoidance Assist (PCA) Reverse Parking Collision-Avoidance Warning Timing Assist. If you change the Warning Volume, the warning volume of other Driver Assis- tance systems may change. CAUTION 僅 The setting of the Warning Timing and Warning Volume applies to all functions of Reverse Parking Colli- sion-Avoidance Assist.
Page 501 Driving your vehicle Reverse Parking Collision-Avoidance Assist (PCA) When Reverse Parking Collision- Avoid- 僅 Brake control will end when: ance Assist activates, a line appears - The gear is shifted to P (Park) or D behind the vehicle image in the instru- (Drive).
Page 502 Have the vehicle inspected by a profes- performance and Reverse Parking Colli- sional workshop. Kia recommends to sion-Avoidance Assist may not operate visit an authorised Kia dealer/service normally. Always keep the rear bumper partner.
Page 503 Driving your vehicle Reverse Parking Collision-Avoidance Assist (PCA) Wide-rear view camera Limitations of Reverse Parking Collision-Avoidance Assist Reverse Parking Collision-Avoidance Assist may not assist braking or warn the driver even if there are pedestrians or objects under the following circum- stances: 僅...
Page 504 Driving your vehicle Reverse Parking Collision-Avoidance Assist (PCA) 僅 The pedestrian is not standing upright 僅 Your vehicle height is low or high due to heavy loads, abnormal tyre pres- 僅 The pedestrian is either very short or sure, etc. very tall for Reverse Parking Collision- Avoidance Assist to detect 僅...
Page 505 Driving your vehicle Reverse Parking Collision-Avoidance Assist (PCA) under certain conditions. If vehicle sion-Avoidance Assist warning speed is above 4 km/h (2 mph), sounds. Reverse Parking Collision- Avoidance 僅 Turn off Reverse Parking Collision- Assist will provide collision avoidance Avoidance Assist when towing a assist only when pedestrians are trailer.
Page 506: Remote Smart Parking Assist (Rspa)
Have the vehicle inspected by a Function Description professional workshop. Kia recom- Remotely moving forward or backward mends to visit an authorised Kia dealer/service partner. NOTICE Remote Opera- tion Reverse Parking Collision-Avoidance Assist can detect a pedestrian or an object when: 僅...
Page 507 僅 If the detecting sensor have been replaced or repaired, we recommend that you have your vehicle inspected OKA4041515 by an authorised Kia dealer/service partner. Rear side ultrasonic sensors 僅 Remote Smart Parking Assist may malfunction if the vehicle bumper height or ultrasonic sensor installation has been modified or damaged.
Page 508: 僅 Remote Smart Parking Assist Operation
Driving your vehicle Remote Smart Parking Assist (RSPA) 僅 Do not spray the ultrasonic sensors or its surrounding area directly with a high pressure washer. Remote Smart Parking Assist set- tings Warning Volume OMQ4041606 With the vehicle on, select 'Driver Assis- tance →...
Page 509 Driving your vehicle Remote Smart Parking Assist (RSPA) Remote Smart Parking Assist operation Remote Smart Parking button Parking/View button, Parking Safety button Smart key OKA4041607R OKA4051631R Location Name Symbol Description 僅 Press and hold the Parking/View button to turn on Remote Smart Park- ing Assist.
Page 510 Driving your vehicle Remote Smart Parking Assist (RSPA) Remote Operation Method (2): Using the function with vehicle on Operating order Remote Operation operates in the fol- lowing order: 1. Getting ready to remotely move for- ward and backward 2. Remotely moving forward and back- ward 1.
Page 511 Driving your vehicle Remote Smart Parking Assist (RSPA) 僅 Method (2) can be used after the vehi- infotainment system screen and the cle has been driven above 5 km/h (3 vehicle will remain on. mph). In addition, when the Remote Start 僅...
Page 512 Driving your vehicle Remote Smart Parking Assist (RSPA) 僅 For moving remotely backward, both Remote Smart Parking Assist method (1) and (2) aligns the steering operation status wheel first, and then will only move the vehicle straight. Hazard warning Operation Status Smart key LED light 僅...
Page 513 Driving your vehicle Remote Smart Parking Assist (RSPA) 僅 Get on the vehicle with the smart key. The function will cancel in the fol- Remote Operation function will turn lowing conditions when: off. At this time, the vehicle will remain 僅...
Page 514 If the message appears, stop using the function, and we recom- mend that the function be inspected by an authorised Kia dealer/service partner. OKA4051607L When 'Parking Assist Conditions Not Met' message appears, when Parking/...
Page 515 Driving your vehicle Remote Smart Parking Assist (RSPA) 僅 There is an obstacle such as a person, View ( ) button has been pressed animal or object (trash can, bicycle, and held, Remote Smart Parking Assist motorcycle, shopping cart, narrow pil- is in standby.
Page 516 Driving your vehicle Remote Smart Parking Assist (RSPA) 僅 Objects which tend to absorb sensor 僅 Parking on uneven road frequency, such as clothes, spongy material or snow Remote Smart Parking Assist may not operate normally under the following circumstances: 僅...
Page 517 Driving your vehicle Remote Smart Parking Assist (RSPA) 僅 Parking near a pillar 僅 Parking diagonal OKA4051213 OKA4051206 Remote Smart Parking Assist perfor- Remote Smart Parking Assist does not mance may reduce or collision with an provide diagonal parking. Even if your obstacle may occur when there is a vehicle was able to enter the parking narrow object, circular pillar, square...
Page 518 We there are no pedestrians, animals, or recommend that the vehicle be objects around your vehicle. inspected by an authorised Kia 僅 Depending on brake operation, the dealer/service partner. stop lights may come on whilst the 僅...
Page 519: Declaration Of Conformity
Driving your vehicle Declaration of conformity Declaration of conformity (if equipped) The radio frequency components (Front Radar) (Type A) complies: For Europe and countries subject to CE certification OCK060094TW For Australia OMQ4PH051413L For Taiwan OCK060062L OMQ4PH051411L CCAI19LP0490T6...
Page 520 Driving your vehicle Declaration of conformity For Serbia For Ukraine OMQ4PH051415L ODL3059228L For Oman OCK060066L For UAE OKA4050558L For Moldova OMQ4PH051418L OCK060065L...
Page 521 Driving your vehicle Declaration of conformity For Brazil For Jordan OMQ4PH051419L For Singapore OMQ4PH051422L For Mexico OMQ4PH051420L For Russia OKA4050562L For Israel ODL3059224L For Malaysia OMQ4PH051423L OMQ4PH051421L...
Page 522 Driving your vehicle Declaration of conformity The radio frequency components For Taiwan (Front Radar) (Type B) complies: For Europe and countries subject to CE certification OSK3052442L OJA060067L OSK3052443L For Australia OSK3052440L OCK060062L...
Page 523 Driving your vehicle Declaration of conformity For Thailand For Moldova OSK3052457L For Serbia OCK060065L For Ukraine OSK3052444L For Morocco OSK3052445L OSK3052446L For Oman OSK3052447L OCK060066L...
Page 524 Driving your vehicle Declaration of conformity For Uzbekistan For Singapore ODL3059239L OKA4052659L For UAE For Russia OSK3052448L For Ghana OSK3052449L For Brazil ODL3059224L For Benin OSK3052455L For Malaysia OKA4052560L OSK3052439L...
Page 525 Driving your vehicle Declaration of conformity For Israel For Philippines OKA4052660L For Jordan OSK3052456L For Paraguay OSK3052452L The radio frequency components (Rear Corner Radar) (Type A) complies: For Ukraine OSK3052453L For Mexico OMQ4PH051399L OSK3052450L For Argentina OMQ4061053L OSK3052451L...
Page 526 Driving your vehicle Declaration of conformity For Ghana For Malaysia OMQ4PH051400L For Republic of South Africa OMQ4PH051405L OMQ4PH051401L For Singapore For Serbia OMQ4PH051406L For Europe and countries subject to CE certification OMQ4PH051403L For Paraguay OMQ4PH051407L OMQ4PH051404L...
Page 527 Driving your vehicle Declaration of conformity For Thailand OMQ4061055L For Taiwan OMQ4PH051408L For Israel OMQ4PH051409L For Brazil OMQ4PH052419L OMQ4PH052460L...
Page 528 Driving your vehicle Declaration of conformity For UAE For United Kingdom OMQ4051452L For Australia OMQ4061058L For Jordan OMQ4061057L OMQ4051453L For Mexico For Indonesia OMQ4PH052461L For Pakistan OMQ4A061072 For Morocco OMQ4PH051453L OMQ4PH052462L...
Page 529 Driving your vehicle Declaration of conformity For Oman The radio frequency components (Rear Corner Radar) (Type B) complies: For Japan OMQ4PH052463L For Nigeria OKA4052667L For Ghana OKA4052668L For Singapore OMQ4PH052464L For Zambia OKA4052669L For UAE OKA4052664L For Senegal OKA4052670L OKA4052665L...
Page 530 Driving your vehicle Declaration of conformity For Europe and CE certified coun- For Zambia tries OKA4052674L For Paraguay OKA4052671L For Thailand OKA4052675L For Oman OKA4052672L OKA4052676L For Morocco For Republic of South Africa OKA4052673L OKA4052677L...
Page 531 Driving your vehicle Declaration of conformity For Senegal For Serbia OKA4052678L For Jordan OKA4052679L OKA4052682L For Australia For Nigeria OKA4052680L For United Kingdom OKA4052683L For Malaysia OKA4052681L OKA4052684L...
Page 532 Driving your vehicle Declaration of conformity For Pakistan For Taiwan OKA4052685L For Israel OKA4052686L For Mexico OKA4052689L OKA4052687L For Indonesia 83300/SDPPI/2022 10976 OKA4052688L...
Page 533: Economical Operation
Therefore, have the vehicle inspected by correctly. Improper alignment can a professional workshop. Kia recom- result from hitting kerbs or driving too mends to visit an authorised Kia dealer/ fast over irregular surfaces. Poor service partner. alignment causes faster tyre wear and may also result in other problems as well as greater fuel consumption.
Page 534: Special Driving Conditions
Driving your vehicle Special driving conditions Special driving conditions WARNING If driving conditions deteriorate due to Engine off during motion poor weather or road conditions, you Never turn the engine off to coast down should pay even more attention than hills or anytime the vehicle is in motion.
Page 535 Driving your vehicle Special driving conditions slung sports vehicles are designed to WARNING perform satisfactorily in off-road condi- Your vehicle is equipped with tyres tions. Due to this risk, driver and passen- designed to provide safe ride and han- gers are strongly recommended to dling capability.
Page 536 Driving your vehicle Special driving conditions Driving at night CAUTION Spinning tyres Do not spin the wheels, especially at speeds more than 56 km/h (35 mph). Spinning the wheels at high speeds when the vehicle is stationary could overheat and damage tyres, and the rotating wheels may fly away and injure bystanders.
Page 537 Driving your vehicle Special driving conditions Driving in the rain Hydroplaning If the road is wet enough and you are going fast enough, your vehicle may have little or no contact with the road surface and actually ride on the water. The best advice is SLOW DOWN when the road is wet.
Page 538 Driving your vehicle Winter driving sures will result in overheating and pos- Winter driving sible failure of the tyres. Severe weather conditions in the winter Avoid using worn or damaged tyres result in greater wear and other prob- which may result in reduced traction or lems.
Page 539 Driving your vehicle Winter driving fabric-type Snow tyres If you mount snow tyres on your vehicle, make sure they are radial tyres of the same size and load range as the original tyres. Mount snow tyres on all four wheels to balance your vehicle's han- dling in all weather conditions.
Page 540 SAE class "S" page 9-6. If you aren't sure what weight certified. oil you should use, Kia recommends to 僅 Always check chain installation for consult an authorised Kia dealer/service proper mounting after driving approx- partner.
Page 541 Window washer anti-freeze is cables, window scraper, gloves, ground available from an authorised Kia dealer/ cloth, coveralls, blanket, etc. service partner and most auto parts out- lets. Do not use engine coolant or other...
Page 542 Driving your vehicle Vehicle weight Vehicle weight GVWR (Gross vehicle weight rat- ing) This section will guide you in the proper loading of your vehicle, to keep your This is the maximum allowable weight of loaded vehicle weight within its design the fully loaded vehicle (including all rating capability.
Page 543 Driving your vehicle Vehicle weight Tyre label - type A And, if you do have a heavy load, you should spread it out. Your warranty does not cover parts or components that fail because of over- loading. CAUTION Do not load your vehicle any heavier than the GVWR or the maximum front and rear GAWR.
Page 544 Before towing, make sure the total trailer towing trailers, cars, or other types of weight, gross combination weight, gross vehicles or apparatus may differ. Kia vehicle weight, gross axle weight and recommends to ask an authorised Kia trailer tongue load are all within the lim- dealer/service partner.
Page 545 僅 Kia trailer hitch accessory is available Hitches at an authorised Kia dealer/service It's important to have the correct hitch partner.
Page 546 Driving your vehicle Trailer towing Trailer brakes are working. This lets you check your electrical connection at the same time. If your trailer is equipped with a braking During your trip, check occasionally to system, make sure it conforms to your be sure that the load is secure, and that country's regulations and that it is prop- the lights and trailer brakes are still...
Page 547 You may pro- ness. ceed once the engine has cooled suf- Kia recommends to visit an authorised ficiently. Kia dealer/service partner. 僅 You must decide the driving speed WARNING...
Page 548 Driving your vehicle Trailer towing 僅 Shift into gear; and WARNING 僅 Release the parking brake. Parking on a hill 2. Slowly remove your foot from the Parking your vehicle on a hill with a brake pedal. trailer attached could cause serious 3.
Page 549 Failure to heed this caution may result in serious engine or transmission damage. 僅 When towing a trailer, Kia recom- mends that you consult an authorised Kia dealer/service partner on addi- tional requirements such as a towing kit, etc.
Page 550 Driving your vehicle Trailer towing Engine Item Smartstream G3.5 (Petrol) Smartstream D2.2 (Diesel) Without brake System 750 kg (1,653 lbs.) Maximum trailer weight* With brake System 2,000 kg (4,409 lbs.) Maximum permissible static vertical load on the 200 kg (441 lbs.) coupling device Recommended distance from rear wheel centre 1,205 mm (47.4 inch)
Page 551 Driving your vehicle Trailer towing they aren't, you may be able to correct them simply by moving some items around in the trailer. WARNING Trailer 僅 Never load a trailer with more weight in the rear than in the front. The front should be loaded with approximately 60% of the total trailer load;...
Page 553 What to do in an emergency What to do in an emergency Road warning................. 7-3 僅 Hazard warning flasher................. 7-3 In case of an emergency whilst driving........7-3 僅 If the vehicle stalls whilst driving............... 7-3 僅 If the engine stalls at a crossroad or crossing........7-3 僅...
Page 554 What to do in an emergency 僅 Checking the tyre inflation pressure ............. 7-29 Towing................... 7-31 僅 Towing service ....................7-31 僅 Removable towing hook ................7-32 僅 Emergency towing..................7-33 Emergency commodity ...............7-35 僅 Fire extinguisher.....................7-35 僅 First aid kit......................7-35 僅...
Page 555: What To Do In An Emergency
4. Try to start the vehicle again. If your overtaking, or passing your vehicle. vehicle will not start, contact a profes- sional workshop or seek other quali- fied assistance. Kia recommends to contact an authorised Kia dealer/ser- vice partner. If the engine stalls at a crossroad or crossing 僅...
Page 556: If The Engine Will Not Start
What to do in an emergency If the engine will not start 4. When the vehicle is stopped, turn on If the engine will not start your emergency hazard flashers, set When the engine doesn't start, first the parking brake and put the trans- check to see how much fuel there is and mission in P.
Page 557: Emergency Starting
4. If the engine still does not start, call a professional workshop or seek other qualified assistance. Kia recommends to call an authorised Kia dealer/ser- vice partner. OKA4060004L Jump-starting can be dangerous if done incorrectly. Therefore, to avoid harm to...
Page 558 Jump-starting vehicle checked by a professional work- 1. Make sure the booster battery is 12- shop. Kia recommends to visit an volt and that its negative terminal is authorised Kia dealer/service partner. grounded.
Page 559: If The Engine Overheats
What to do in an emergency If the engine overheats If the engine overheats NOTICE If your temperature gauge indicates Battery cables overheating, you experience a loss of Do not connect the jumper cable from power, or hear a loud pinging or knock- the negative terminal of the booster bat- ing, the engine will probably be too hot.
Page 560 Whilst the engine is running, should be checked as soon as possi- keep hair, hands and clothing ble by a professional workshop. Kia away from moving parts, such as recommends to visit an authorised Kia the fan and drive belts, to pre- dealer/service partner.
Page 561: Tyre Pressure Monitoring System (Tpms)
What to do in an emergency Tyre Pressure Monitoring System (TPMS) 僅 You can change the tyre pressure unit Tyre Pressure Monitoring Sys- in the user settings mode on the clus- tem (TPMS) (if equipped) ter. - psi, kpa, bar (Refer to "User settings mode"...
Page 562: 僅 Low Tyre Pressure Telltale
Kia recommends to visit an authorised Kia dealer/service partner. tances. You should stop and check your tyres as soon as possible. Inflate the 1.
Page 563: 僅 Tyre Pressure Monitoring System (Tpms) Malfunction Indicator
It does not mean your the cause of the problem. Kia recom- TPMS is malfunctioning because the mends to visit an authorised Kia dealer/ decreased temperature leads to a service partner.
Page 564: 僅 Changing A Tyre With Tpms
(from sitting stationary for at least 3 a professional workshop. Kia recom- hours and driven less than 1 mile (1.6 mends to visit an authorised Kia dealer/ km) during that 3 hour period). service partner. Allow the tyre to cool before measuring CAUTION the inflation pressure.
Page 565: If You Have A Flat Tyre (With Spare Tyre)
TPMS sensor. For your safety, use Jacking instructions parts for replacement from a profes- The jack is provided for emergency tyre sional workshop. Kia recommends to changing only. visit an authorised Kia dealer/service partner. To prevent the jack from "rattling" whilst the vehicle is in motion, store it properly.
Page 566: 僅 Removing And Storing The Spare Tyre
What to do in an emergency If you have a flat tyre (with spare tyre) Removing and storing the spare WARNING tyre Changing tyres 僅 Never attempt vehicle repairs in the traffic lanes of a public road or high- way. 僅...
Page 567 What to do in an emergency If you have a flat tyre (with spare tyre) Turn the wrench counterclockwise 2. Place the wheel under the vehicle and until the spare tyre reaches the install the retainer (1) through the ground. wheel centre.
Page 568 What to do in an emergency If you have a flat tyre (with spare tyre) OKA4060049L OKA4060051L 4. Tighten the fixing belt securely. 4. Tighten the fixing belt securely. NOTICE In the 3rd row seats folded flat 1. Place the flat tyre with its outer part facing upwards in the middle of the 3rd row seats.
Page 569 What to do in an emergency If you have a flat tyre (with spare tyre) Changing tyres WARNING Changing a tyre 僅 To prevent vehicle movement whilst changing a tyre, always set the park- ing brake fully, and always block the wheel diagonally opposite the wheel being changed.
Page 570 What to do in an emergency If you have a flat tyre (with spare tyre) OKA4061039L OKA4061043L 7. Place the jack at the front (1) or rear 9. Loosen the wheel nuts and remove (2) jacking position closest to the tyre them with your fingers.
Page 571 If in doubt, consult a professional work- dle. Go around the wheel tightening shop. Kia recommends to consult an every other nut until they are all tight. authorised Kia dealer/service partner. Then double-check each nut for tight- ness.
Page 572: 僅 Important - Use Of Compact Spare Tyre
What to do in an emergency If you have a flat tyre (with spare tyre) WARNING CAUTION Inadequate spare tyre pressure Check the inflation pressure after install- ing the spare tyre. Adjust it to the speci- Check the inflation pressures as soon as fied pressure, as necessary.
Page 573 What to do in an emergency If you have a flat tyre (with spare tyre) 僅 Do not use the temporary compact tyre on any other vehicle because this tyre has been designed especially for your vehicle. 僅 The temporary compact tyre tread life is shorter than a regular tyre.
Page 574 What to do in an emergency If you have a flat tyre (with spare tyre) Jack label Type A OHYK060001 Type B OHYK060005 Type C OHYK064002 * The actual Jack label in the vehicle may differ from the illustration. For more detailed specifica- tions, refer to the label attached to the jack.
Page 575 What to do in an emergency If you have a flat tyre (with spare tyre) EC Declaration of Conformity for Jack OMQ4060044L...
Page 576: If You Have A Flat Tyre (With Tyre Mobility Kit)
We recommend that you with larger punctures or damage to the have your vehicle inspected by an sidewall, cannot be sealed completely. authorised Kia dealer/service partner. Air pressure loss in the tyre may adversely affect tyre performance.
Page 577 What to do in an emergency If you have a flat tyre (with tyre mobility kit) For this reason, you should avoid abrupt steering or other driving manoeuvres, especially if the vehicle is heavily loaded or if a trailer is in use. The Tyre Mobility Kit is not designed or intended as a permanent tyre repair method and is to be used for one tyre...
Page 578: 僅 Components Of The Tyre Mobility Kit
What to do in an emergency If you have a flat tyre (with tyre mobility kit) Components of the Tyre Mobility Kit OKA4060047L 1 Speed-restriction label 2 Sealant bottle 3 Filling hose from compressor to wheel 4 Connectors and cable for the power outlet direct connection 5 Holder for the sealant bottle 6 Compressor 7 ON/OFF switch...
Page 579: 僅 Using The Tyre Mobility Kit
What to do in an emergency If you have a flat tyre (with tyre mobility kit) 1. Shake the sealant bottle. WARNING Expired sealant Do not use the Tyre sealant after the sealant has expired (i.e. past the expira- tion date on the sealant container). This can increase the risk of tyre failure.
Page 580 What to do in an emergency If you have a flat tyre (with tyre mobility kit) 4. Unscrew the valve cap from the valve (refer to "Tyres and wheels" on page of the defective tyre and screw the fill- 9-5). The inflation pressure of the tyre ing hose of the compressor onto the after filling is unimportant and will be tyre valve.
Page 581: 僅 Distributing The Sealant
Kia recommends 僅 To reduce the inflation pressure: to visit an authorised Kia dealer/service Turn the valve on the compressor. partner. CAUTION Do not use the tyre sealant when only...
Page 582 What to do in an emergency If you have a flat tyre (with tyre mobility kit) Notes on the safe use of the Tyre WARNING Mobility Kit Do not let the compressor run for more 僅 Park your car at the side of the road than 10 minutes, otherwise the device so that you can work with the TMK will overheat and may be damaged.
Page 583: Towing
Liquid residue from recommend having it done by an the sealant should be disposed of by authorised Kia dealer or a commercial your vehicle or tyre dealer or in accor- tow-truck service. Proper lifting and tow-...
Page 584: 僅 Removable Towing Hook
What to do in an emergency Towing Removable towing hook (if equipped) 1. Open the tailgate, and remove the towing hook from the tool case. OKA4060017N OKA4060016N CAUTION OKA4070081L 僅 Do not tow the vehicle backwards 2. Remove the hole cover pressing the with the front wheels on the ground upper part of the cover on the front as this may cause damage to the...
Page 585 僅 Before emergency towing, check if you to have it done by an authorised the hook is not broken or damaged. Kia dealer or a commercial tow truck 僅 Fasten the towing cable or chain service. securely to the hook.
Page 586 僅 Use a towing strap less than 5 m (16 towing. We recommend that you con- feet) long. Attach a white or red cloth tact an authorised Kia dealer or a (about 30 cm (12 inches) wide) in the commercial tow truck service for middle of the strap for easy visibility.
Page 587: Emergency Commodity
What to do in an emergency Emergency commodity 僅 To avoid serious damage to the auto- Emergency commodity (if matic transmission, limit the vehicle equipped) speed to 15 km/h (10 mph) and drive There are some emergency commodi- less than 1.5 km (1 mile) when towing. ties in the vehicle to help you respond to CAUTION the emergency situation.
Page 588: Pan-European Ecall System
What to do in an emergency Pan-European eCall system Pan-European eCall system (if Once the data which is stored in the Pan-European eCall system is delivered equipped) to the rescue centre to assist the driver and passengers with proper rescue operations, the data will be deleted after rescue operation is completed.
Page 589: 僅 Information On Data Processing
What to do in an emergency Pan-European eCall system ities: refer to this section. The 112-based Types of data and its recipients eCall service is a public service of gen- The 112-based eCall in-vehicle system eral interest and is accessible free of may collect and process only the follow- charge.
Page 590 What to do in an emergency Pan-European eCall system 3. Directive 95/46/EC is repealed by Modalities for exercising data Regulation (EU) 2016/679 of the Euro- subject's rights pean Parliament and of the Council of The data subject (the vehicle's owner) 27 April 2016 on the protection of nat- has a right of access to data and as ural persons with regard to the pro-...
Page 591 What to do in an emergency Pan-European eCall system SOS button: the driver/passenger makes automatically transmits the accident an emergency call to the single duty dis- data to the Public Safety Answering patch service by pressing the button. Point (PSAP) when a traffic accident is detected.
Page 592 Please, have the Pan-European eCall other participants of road traffic; system checked at an authorised Kia 2. Press the SOS button, when pressing dealership immediately. Otherwise cor- the button SOS registration of the...
Page 593 What to do in an emergency ERA-GLONASS Emergency Call Arbitrary Removal or Modification ERA-GLONASS Emergency The Pan-European eCall system calls Call (if equipped) emergency services for assistance. Thus, any arbitrary removal or changes to the Pan- European eCall system settings may affect your driving safety.
Page 594: Era-Glonass Emergency Call
What to do in an emergency ERA-GLONASS Emergency Call the data will be deleted after rescue the official dealership of Kia. The mode operation is completed. "SOS TEST" can be activated strictly by the specialist of the authorised dealer/ Operator of the system ERA-GLONASS service partner of Kia.
Page 595 What to do in an emergency ERA-GLONASS Emergency Call duty dispatch service for proper rescu- 3. Emergency services ing operations in event of car accident. For proper emergency services and sup- port the ERA-GLONASS system auto- matically transmits the accident data to the single duty dispatch service when a traffic accident is detected.
Page 596 ERA-GLONASS system. Please, OKA4060045L have the ERA-GLONASS system Elements of the system ERA-GLONASS, checked at an authorised Kia dealer/ser- installed in passenger compartment: vice partner immediately. Otherwise cor- 1 Microphone rect operation of the ERA-GLONASS...
Page 597 What to do in an emergency ERA-GLONASS Emergency Call accordance with the following manual (on applying user interface for launching test mode). You can start the ERA-GLONASS test mode by pressing the SOS TEST button. The test mode starts with a voice guid- ance to check working ability of the ERA-GLONASS device.
Page 599: Maintenance
Maintenance Maintenance Engine compartment..............8-5 Maintenance services..............8-6 僅 Owner's responsibility..................8-6 僅 Owner maintenance precautions ............. 8-6 僅 Engine compartment precautions (Diesel engine)......8-7 Owner maintenance ..............8-8 僅 Owner maintenance schedule ..............8-8 Scheduled maintenance service ..........8-10 僅 Scheduled maintenance service precaution........8-10 Explanation of scheduled maintenance items......
Page 600 Maintenance Engine oil (Petrol engine) ............8-19 僅 Checking the engine oil level..............8-19 僅 Changing the engine oil and filter............8-20 Engine oil (Diesel engine) ............8-21 僅 Checking the engine oil level..............8-21 僅 Changing the engine oil and filter............8-22 Engine coolant ................
Page 601 Maintenance Tyres and wheels ................ 8-38 僅 Tyre care ......................8-38 僅 Recommended cold tyre inflation pressures........8-38 僅 Checking tyre inflation pressure .............8-39 僅 Tyre rotation....................8-40 僅 Wheel alignment and tyre balance ............8-41 僅 Tyre replacement................... 8-41 僅 Wheel replacement ..................8-42 僅...
Page 602 Maintenance 僅 Replacing high mounted stop lamp (LED type) .......8-67 僅 Replacing license plate lamp (Bulb type)........... 8-68 僅 Replacing map lamp (Bulb type) ............8-68 僅 Replacing map lamp (LED type) ............8-68 僅 Replacing room lamp (Bulb type)............8-69 僅...
Page 603: Engine Compartment
Maintenance Engine compartment Maintenance Engine compartment Smartstream G3.5 GDi/MPI (Petrol) OKA4071002R Smartstream D2.2 (Diesel) OKA4071001R * The actual engine room in the vehicle may differ from the illustration. 1 Engine coolant reservoir 9 Positive battery terminal 2 Brake fluid reservoir 3 Air cleaner 4 Engine oil filler cap 5 Engine oil dipstick...
Page 604: Maintenance Services
You need this information to establish serviced by a professional workshop. your compliance with the servicing and Kia recommends to visit an authorised maintenance requirements of your vehi- Kia dealer/service partner. cle warranties.
Page 605 (fuel lines and fuel injection devices), room whilst the engine is running. contact a professional workshop. Kia - Do not touch the injector, injector recommends to visit an authorised Kia wirings, and the engine computer dealer/service partner. whilst the engine is running.
Page 606: Owner Maintenance
Maintenance Owner maintenance 僅 When you remove the interior trim Owner maintenance cover with a flat bed (-) driver, be The following lists are vehicle checks careful not to damage the cover. and inspections that should be per- 僅 Be careful when you replace and formed at the frequencies indicated to clean bulbs to avoid burns or electri- help ensure safe, dependable operation...
Page 607 Maintenance Owner maintenance Whilst operating your vehicle: At least twice a year (i.e., every Spring and Fall): 僅 Note any changes in the sound of the exhaust or any smell of exhaust 僅 Check the radiator, heater and air fumes in the vehicle. conditioning hoses for leaks or dam- age.
Page 608: Scheduled Maintenance Service
Maintenance Scheduled maintenance service If your vehicle is operated in any of the Scheduled maintenance ser- prior listed conditions, you should vice inspect, replace or refill more frequently, Scheduled maintenance service using the severe usage maintenance precaution schedule instead of the normal usage maintenance schedule.
Page 609 Spark plug other items. Kia recommends that you use unleaded petrol which has an octane rating of RON (Research Octane Number) 95/AKI (Anti Knock Index) 91 or higher (for Europe) or Octane Rating of RON (Research Octane Number) 91/AKI (Anti-Knock Index) 87 or higher (except Europe).
Page 610 Maintenance Scheduled maintenance service I: Inspect and if necessary, adjust, correct, clean or replace. R: Replace or change. Number of months or driving distance, whichever comes first Months 24 36 48 60 72 Miles×1,000 10 20 30 40 50 60 Km×1,000 15 30 45 60 75 90 105 120 Except Middle East, Iran, India,...
Page 611 Maintenance Scheduled maintenance service Number of months or driving distance, whichever comes first Months 24 36 48 60 72 Miles×1,000 10 20 30 40 50 60 Km×1,000 30 45 60 75 90 105 120 Except Middle East, Iran, India, Morocco, Algeria, Tunisia, Libya, Add every 15,000 km (10,000 miles) or 12 Egypt, Sudan, Central &...
Page 612 - If there are some important safety matters like fuel flow restriction, surging, loss of power, hard starting problem etc, replace the fuel filter immediately regard- less of maintenance schedule and consult an authorised Kia dealer/service part- ner for details.
Page 613 Maintenance Scheduled maintenance service Maintenance under severe usage conditions - except Europe (Includ- ing Russia) I: Inspect and if necessary, adjust, correct, clean or replace. R: Replace or change. Mainte- Maintenance item nance Maintenance intervals Driving condition operation Except Middle East, Iran, India, Morocco, Algeria, Tunisia, Libya, Egypt, Every 7,500 km (5,000...
Page 614: Explanation Of Scheduled Maintenance Items
After installing a new filter, run the engine for several minutes, and check for leaks at the connections. Have the fuel filter replaced by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner.
Page 615: 僅 Fuel Filter (Petrol Engine)
Explanation of scheduled maintenance items Fuel filter (Petrol engine) Vapour hose (Petrol engine) and fuel filler cap Kia petrol vehicles are equipped with a lifetime fuel filter that integrated with The vapour hose and fuel filler cap the fuel tank. Regular maintenance or...
Page 616: 僅 Automatic Transmission (At) Fluid
For more information on checking the be checked under normal usage condi- pads or lining wear limit, we recommend tions. Have the automatic transmission to refer to the Kia web site. fluid changed by a professional work- (www.Kia-hotline.com) shop according to the maintenance Suspension mounting bolts schedule.
Page 617: 僅 Air Conditioning Refrigerant
Maintenance Engine oil (Petrol engine) Air conditioning refrigerant Engine oil (Petrol engine) Check the air conditioning lines and con- Checking the engine oil level nections for leakage and damage. Engine oil is used for lubricating, cooling, Checking fluid levels and operating various hydraulic compo- nents in the engine.
Page 618: 僅 Changing The Engine Oil And Filter
Have the engine oil and filter replaced hose when checking or adding the by a professional workshop. Kia recom- engine oil as it may be hot enough to mends to visit an authorised Kia dealer/ burn you. service partner. 僅 If the maintenance schedule to...
Page 619: Engine Oil (Diesel Engine)
Maintenance Engine oil (Diesel engine) Engine oil (Diesel engine) NOTICE Checking the engine oil level For Smartstream D2.2 engine When the oil pressure is low due to Engine oil is used for lubricating, cooling, insufficient engine oil, the Engine Oil and operating various hydraulic compo- Pressure ( ) warning light will...
Page 620: 僅 Changing The Engine Oil And Filter
Be very careful not to touch the radiator by a professional workshop. Kia recom- hose when checking or adding the mends to visit an authorised Kia dealer/ engine oil as it may be hot enough to service partner. burn you.
Page 621: Engine Coolant
Maintenance Engine coolant Engine coolant WARNING The high-pressure cooling system has a Used engine oil may cause irritation or reservoir filled with year round anti- cancer of the skin if left in contact with freeze coolant. The reservoir is filled at the skin for prolonged periods of time.
Page 622 Maintenance Engine coolant When you are sure all the pressure has workshop. Kia recommends to visit an been released, press down on the cap, authorised Kia dealer/service partner. using a thick towel, and continue turning NOTICE counterclockwise to remove it.
Page 623: 僅 Changing The Coolant
僅 When adding coolant, use only deion- Have the coolant replaced by a profes- ized water or soft water for your vehi- sional workshop. Kia recommends to cle and never mix hard water in the visit an authorised Kia dealer/service coolant filled at the factory.
Page 624: Brake Fluid
The fluid level should be tem inspected by a professional work- between MAX and MIN marks on the shop. Kia recommends to visit an side of the reservoir. authorised Kia dealer/service partner. WARNING...
Page 625: Washer Fluid
Maintenance Washer fluid 僅 Windscreen washer fluid is poisonous Washer fluid to humans and animals. Do not drink Checking the washer fluid level and avoid contacting windscreen The reservoir is translucent so that you washer fluid. Serious injury or death can check the level with a quick visual could occur.
Page 626: Fuel Filter (Diesel Engine)
ON position. If this warning light appears, take your car to a professional work- shop and have drain the water and check the system. Kia rec- ommends to visit an authorised Kia dealer/service partner. OMQ4070009 You can clean the filter when inspecting CAUTION the air cleaner compartment.
Page 627 僅 Use only Kia Genuine Parts or those of an equivalent standard part. If not, it may lead to air flow sensor dam- ages. Kia recommends to visit an authorised Kia dealer/service partner.
Page 628: Climate Control Air Filter
Maintenance Climate control air filter 3. Remove the climate control air filter Climate control air filter cover by pulling out both sides of the Filter inspection cover. The climate control air filter should be replaced according to the maintenance schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and...
Page 629: 僅 Rear Climate Control Air Filter
Maintenance Climate control air filter 3. Remove the rear climate control air fil- ter (3). OKA4070066 OKA4070011 Rear climate control air filter 4. Replace the climate control air filter. 1. Open luggage and remove the stor- age cover(1) on the right side. ODEEV098011NR 5.
Page 630: Wiper Blades
Maintenance Wiper blades Wiper blades Blade replacement When the wipers no longer clean ade- Blade inspection quately, the blades may be worn or cracked, and require replacement. CAUTION To prevent damage to the wiper arms or other components, do not attempt to move the wipers manually.
Page 631 Maintenance Wiper blades 4. Install the blade assembly in the Type A reverse order of removal. 1. Raise the wiper arm and turn the wiper blade assembly to expose the plastic locking clip. ODEEV098015NR Type B ODEEV098013NR 1. Raise the wiper arm. CAUTION 2.
Page 632: 僅 Replacing Rear Wiper Blade
Maintenance Wiper blades 3. Install the new blade assembly. OKA4070013 ODEEV098017NR 3. Lift up the wiper blade, and pull the 4. Return the wiper arm on the blade to remove it. windscreen. 5. Turn the ignition switch or ENGINE START/STOP button to the ON posi- tion and wiper arms will return to the normal operating position.
Page 633: Battery
To prevent damage to the wiper arms or other components, have the wiper blade replaced by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. OKA4070014R CAUTION 僅 Keep the battery securely mounted.
Page 634: 僅 Battery Capacity Label
* The actual battery label in the vehicle environment and human may differ from the illustration. health. Dispose the battery 1 CMF80L-DIN: The Kia model name of according to your local law(s) or regula- battery tion.
Page 635 AGM battery serviced by a profes- the vehicle is being used, recharge it sional workshop. Kia recommends to at 20-30A for two hours. visit an authorised Kia dealer/service partner.
Page 636: Tyres And Wheels
Maintenance Tyres and wheels Reset items Tyres and wheels Items should be reset after the battery Tyre care has been discharged or the battery has For proper maintenance, safety, and been disconnected. maximum fuel economy, you must 僅 Auto up/down window always maintain recommended tyre 僅...
Page 637: 僅 Checking Tyre Inflation Pressure
Kia recommends to visit an 僅 Never overload your vehicle. Be care- authorised Kia dealer/service partner. ful not to overload a vehicle luggage 僅...
Page 638 Replace tyres that are worn, show Disc brake pads should be inspected for uneven wear, or are damaged. wear whenever tyres are rotated. 僅 Remember to check the pressure of your spare tyre. Kia recommends that you check the spare every time you...
Page 639 If the problem is not solved, con- Tyre replacement tact a professional workshop. Kia If the tyre is worn evenly, a tread wear recommends to visit an authorised Kia Indicator will appear as a solid band dealer/service partner. across the tread.
Page 640 僅 Wheels that do not meet Kia's specifi- speedometer and odometer calibration, cations may fit poorly and result in headlight aim and bumper height.
Page 641: 僅 Tyre Sidewall Labeling
If you find a tyre is worn unevenly, mation when selecting replacement have a professional workshop check the tyres for your vehicle. The following wheel alignment. Kia recommends to explains what the letters and numbers in visit an authorised Kia dealer/service the tyre size designation mean.
Page 642 Maintenance Tyres and wheels Tyre speed ratings WARNING The chart below lists many of the differ- Tyre age ent speed ratings currently being used Tyres degrade over time, even when for passenger car tyres. The speed rat- they are not being used. Regardless of ing is part of the tyre size designation on the remaining tread, we recommend the sidewall of the tyre.
Page 643 Maintenance Tyres and wheels tyre that has the same load rating as the marked C may have poor traction per- factory installed tyre. formance. Temperature -A, B & C 7. Uniform tyre quality grading The temperature grades are A (the high- Quality grades can be found where est), B, and C, representing the tyre's applicable on the tyre sidewall between...
Page 644: Fuses
Always replace a blown fuse with one of the same rating. If the replacement fuse blows, this indi- cates an electrical problem. Avoid using the system involved and immediately consult a professional workshop. Kia ODEEV098077NR recommends to consult an authorised Multi fuse Kia dealer/service partner.
Page 645: 僅 Inner Panel Fuse Replacement
If fuses, relays ment. and terminals fastened with bolts or nuts are blown, consult a professional workshop. Kia recommends to consult an authorised Kia dealer/service part- ner. 僅 Do not input any other objects except fuses or relays into fuse/relay termi- nals such as a driver or wiring.
Page 646: 僅 Engine Compartment Fuse Replacement
After checking the fuse panel in the (D.R.L) do not work and the fuses are engine compartment, securely install the OK, consult a professional workshop. Kia fuse panel cover through the audible recommends to consult an authorised clicking sound.
Page 647 (BFT type), which is located inside the positive battery termi- nal (+) cap. Since the main fuse is designed more intricately than other parts, visit a professional workshop. Kia recommends to visit the nearest authorised Kia dealer/service partner. CAUTION Visually inspect the battery cap for secure closing.
Page 648 Maintenance Fuses Fuse/relay panel description Driver's side fuse panel Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehi- cle.
Page 649 Maintenance Fuses ICU Junction Block Fuse Name Symbol Fuse rating Circuit Protected SUNROOF1 Front Sunroof Motor AMP (Amplifier) (BOSE) 2nd Seat LH Air Ventilation Control Module, 2nd Seat Warmer Control REAR LH REAR LH S/HEAT Module Driver IMS (Integrated memory system) Control Module, Driver Power DRIVER P/SEAT Seat Switch Rear Power Window Switch LH, Rear Safety Power Window Module LH...
Page 650 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected Luggage USB Charger LH, Luggage USB Charger Unit, Driver Seat USB USB CHARGER Jack, Passenger Seat USB Jack CHARGER IBU (Integrated Body Control Unit), Surround View Monitor, Front View Camera, Crash Pad Switch, Electric Parking Brake Switch, Front Upper MODULE3 7.5A MODULE...
Page 651 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected BRAKE BRAKE 7.5A IBU (Integrated Body Control Unit), Stop Lamp Switch SWITCH SWITCH 7.5A EPS (Electric Power Steering) Unit MULTI MULTI MEDIA2 [Without BOSE AMP (Amplifier)] A/V & Navigation Head Unit MEDIA...
Page 652 Maintenance Fuses Engine compartment fuse panel OKA4070021L OKA4070022L...
Page 653 Maintenance Fuses Engine Room Junction Block Fuse Name Symbol Fuse rating Circuit Protected MULTI FUSE (TYPE A) COOLING FAN Cooling Fan Motor W/S HEATED GLASS1 Windscreen Heated Glass1 Relay ICU Junction Block (Fuse - SUNROOF1, AMP, FRONT S/HEAT, PASSEN- GER P/WINDOW, REAR LH P/SEAT) W/S HEATED GLASS2 Windscreen Heated Glass2 Relay ICU Junction Block (Fuse - REAR LH S/HEAT, DRIVER P/SEAT, DRIVER P/...
Page 654 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected DCU4 [Smartstream D2.2] Dosing Control Module REAR BLOWER Rear Blower Relay PTC HEATER2 [Smartstream D2.2] PTC Heater2 Relay HEATER REAR HEATED Rear Heated Relay RR LH DOOR LOCK RR LH PCB Block (Rear Door LH Lock/Unlock Relay) TCU2 TCM (Transmission Control Module) TRAILER1...
Page 655 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected [With SBW (Shift By Wire)] SCU (System Control Unit), Electronic ATM E-SHIFTER2 E-SHIFTER (Automatic Transmission) Shift Lever Switch FUEL FUEL PUMP Fuel Pump Relay PUMP PCB Block Fuse Name Symbol Fuse rating Circuit Protected IG2 Relay, Engine Room Junction Block (Start1 Relay) IG1 Relay, ACC Relay...
Page 656 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected TCU3 TCM (Transmission Control Module) [Smartstream D2.2] A/C Compressor Relay, Cooling Fan Motor, Stop Lamp Switch, Electronic Thermostat, Oil Level Sensor SENSOR4 [Smartstream G3.5] A/C Compressor Relay, Cooling Fan Motor, Oxygen Sensor #1/#2/#4, Purge Control Solenoid Valve, Variable Oil Pump Sole- noid, Variable Intake Solenoid Valve, Oil Control Valve #1/#2/#3/#4 [Smartstream D2.2] Electronic VGT Actuator, PTC Breather, Oil Pump...
Page 657: Light Bulbs
If there is a problem, have the with one of the same wattage rating. system serviced by a professional work- Otherwise, it may cause extensive wiring shop. Kia recommends to visit an damage and possible fire. authorised Kia dealer/service partner. CAUTION...
Page 658: 僅 Light Bulb Position (Front)
Maintenance Light bulbs a professional workshop. Kia recom- demand several technical solutions (ex. mends to visit an authorised Kia dealer/ automatic change system, adhesive service partner. sheet, down aiming). This headlamps are designed not to dazzle opposite drivers. NOTICE So, you need not change your head- 僅...
Page 659 Maintenance Light bulbs Head lamp – Type B Light bulb position (Rear) Rear combination lamp - Type A OKA4070025 Fog lamp OKA4070027 Rear combination lamp - Type B OKA4070026L 1 Headlamp (Low) (LED type) OKA4070028 2 Headlamp (High) (LED type) Back up lamp/Turn signal lamp 3 Front turn signal lamp (Bulb type) 4 Day time running lamp (LED type)/...
Page 660: 僅 Light Bulb Position (Rear)
If the head lamp LED (1,2) and daytime 1 Tail lamp (Bulb type) running lamp LED (3) does not operate, 2 Stop lamp (Bulb type) have your vehicle checked by a profes- sional workshop. Kia recommends to 3 Tail lamp (LED type)
Page 661: 僅 Replacing Front Turn Signal Lamp (Bulb Type)
Kia recommends to visit an authorised Kia dealer/service partner. 3. Remove the bulb from the socket by pressing it in and rotating it counter-...
Page 662: 僅 Replacing Side Repeater Lamp (Led Type)
Kia recommends to visit an authorised Kia dealer/service partner. The LED lamp cannot be replaced as a single unit because it is an integrated unit.
Page 663: 僅 Replacing Rear Turn Signal Lamp (Bulb Type)
Maintenance Light bulbs Replacing rear turn signal lamp (Bulb type) 1. Open the tailgate. 2. Open the service cover. 3. Loosen the light assembly retaining screws with a cross-tip screw driver. 4. Remove the rear combination lamp assembly from the body of the vehi- cle.
Page 664: 僅 Replacing Stop And Tail Lamp (Led Type)
5. Remove the bulb from the socket by direction the vehicle will move for safety. pressing it in and rotating it counter- Kia recommends to visit an authorised clockwise until the tabs on the bulb Kia dealer/service partner. align with the slots in the socket. Pull The LED lamp cannot be replaced as a the bulb out of the socket.
Page 665: 僅 Replacing Rear Fog Lamp (Bulb Type)
If the high mounted stop lamp (LED) (1) does not operate, have your vehicle checked by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. The LED lamp cannot be replaced as a single unit because it is an integrated unit.
Page 666: 僅 Replacing License Plate Lamp (Bulb Type)
If the map lamp (LED) (1) does not oper- ate, have your vehicle checked by a pro- fessional workshop. Kia recommends to visit an authorised Kia dealer/service partner. The LED lamp cannot be replaced as a single unit because it is an integrated unit.
Page 667: 僅 Replacing Room Lamp (Bulb Type)
If the Side repeater lamp (LED) (1) does not operate, have your vehicle checked by a professional workshop. OKA4070060 Kia recommends to visit an authorised WARNING Kia dealer/service partner. Prior to working on the Interior lamps, The LED lamp cannot be replaced as a ensure that the "OFF"...
Page 668: 僅 Replacing Personal Lamp (Led Type)
Be careful not to dirty or damage the operate, have your vehicle checked by a lens, lens tab, and plastic housings. professional workshop. Kia recommends to visit an authorised Replacing glove box lamp (Bulb Kia dealer/service partner. type) The LED lamp cannot be replaced as a single unit because it is an integrated unit.
Page 669: 僅 Replacing Luggage Lamp (Bulb Type)
Maintenance Light bulbs Replacing luggage lamp (LED CAUTION type) Be careful not to dirty or damage the lens, lens tab, and plastic housings. Replacing luggage lamp (Bulb type) OMQ4040464 If the luggage lamp bulb/LED does not operate, we recommend that the system be checked by a professional workshop.
Page 670: Appearance Care
Maintenance Appearance care similar deposits can damage your vehi- Appearance care cle's finish if not removed immediately. Exterior care Even prompt washing with plain water may not completely remove all these Exterior general caution deposits. A mild soap, safe for use on painted surfaces, may be used.
Page 671 Maintenance Appearance care 僅 Do not spray the camera, sensors or Removing oil, tar, and similar materials its surrounding area directly with a with a spot remover will usually strip the high pressure washer. Shock applied wax from the finish. Be sure to re-wax from high pressure water may cause these areas even if the rest of the vehicle the device to not operate normally.
Page 672 Maintenance Appearance care of wax or chrome preservative and Aluminium wheel maintenance rub to a high luster. The aluminium wheels are coated with a 僅 During winter weather or in coastal clear protective finish. areas, cover the bright metal parts 僅...
Page 673 Maintenance Appearance care unprotected metal exposed to corro- Keep your vehicle clean sion. The best way to prevent corrosion is to keep your vehicle clean and free of cor- High-corrosion areas rosive materials. Attention to the under- side of the vehicle is particularly If you live in an area where your vehicle important.
Page 674 Maintenance Appearance care unless it is well ventilated so moisture is CAUTION dispersed. Never allow water or other liquids to come in contact with electrical/electronic Keep paint and trim in good con- components inside the vehicle as this dition may damage them. Scratches or chips in the finish should be covered with "touch-up"...
Page 675 Maintenance Appearance care 僅 Cosmetic products (sunscreen, foun- Cleaning the upholstery and inte- dation, etc.) rior trim - Apply cleansing cream on a cloth and wipe the contaminated point. Car interior surfaces Wipe off the cream with a wet cloth Remove dust and loose dirt from interior and remove water with a dry cloth.
Page 676: Emission Control System
Kia recommends to visit an authorised Kia dealer/service partner. Caution for the Inspection and Main- tenance Test (With Electronic Stability Control (ESC) system) 僅...
Page 677 Maintenance Emission control system 1. Crankcase emission control 3. Exhaust emission control sys- system The positive crankcase ventilation sys- The Exhaust Emission Control System is tem is employed to prevent air pollution a highly effective system which controls caused by blow-by gases being emitted exhaust emissions whilst maintaining from the crankcase.
Page 678 All inspections and adjust- WARNING ments must be made by a profes- sional workshop. Kia recommends to Fire visit an authorised Kia dealer/service 僅 A hot exhaust system can ignite flam- centre.
Page 679: 僅 Lean Nox Trap
If the PPF warning light stays on or DPF system. Kia recommends to visit an "Check exhaust system" warning mes- authorised Kia dealer/service partner. If sage appears even after driving at rec-...
Page 680 Maintenance Emission control system Low urea solution warning mes- WARNING sage (if equipped) 僅 It may be a criminal offence to use a vehicle that does not consume any urea solution. 僅 Use of, and refilling of, a required urea solution of the correct specifications is mandatory for the vehicle to comply with the certificate of conformity...
Page 681 Maintenance Emission control system Otherwise, the vehicle can't be restarted once the engine is turned off by the ENGINE START/STOP button. Based on the driving pattern, environmental con- dition and road profile, the deducted remaining mileage may differ from the actual travel distance.
Page 682 Otherwise, the vehicle can't be restarted once the engine is turned off. In this case, have your vehicle inspected by a professional workshop. Kia recommends to contact an authorised Kia dealer/service partner.
Page 683 If vehicle starting is not possible regardless of urea solution level, have your vehicle inspected by a professional workshop. Kia recom- mends to contact an authorised Kia dealer/service partner.
Page 684 Maintenance Emission control system 4. Turn the urea solution tank cap in a Adding urea solution (if clockwise direction to securely close it. equipped) Refer to "Recommended lubricants and To refill urea solution with a refill capacities" on page 9-6. hose To refill urea solution with a refill bottle...
Page 685 Maintenance Emission control system Adding urea solution: Every approxi- make sure that the urea solution sys- mately 5,600 km (The urea solution con- tem is completely turned OFF. sumption is dependent on the road 僅 A urea solution of poor quality or any profile, driving pattern and environmen- unauthorised liquids may damage the tal condition)
Page 686 When the bottle of urea solution con- vehicle inspected by a professional tainer is opened, pungent smelling workshop. Kia recommends to contact fumes may escape. an authorised Kia dealer/service part- ner.
Page 687 僅 In case the vehicle was parked at very After adding incorrect urea solution, low ambient temperature (below -11 please visit the nearby authorised Kia degree Celsius) for a long time, the dealer/ service partner as early as urea solution will be frozen in the urea possible.
Page 689: Specifications & Consumer Information
Specifications & Consumer information Specifications & Consumer information Dimensions ..................9-2 Engine ..................... 9-2 Gross vehicle weight ..............9-3 Luggage volume ................9-3 Air conditioning system..............9-3 Bulb wattage ..................9-4 Tyres and wheels ................9-5 Recommended lubricants and capacities ........9-6 僅 Recommended SAE viscosity number............ 9-7 Vehicle Identification Number (VIN)...........9-8 Vehicle certification label.............9-8 Tyre specification and pressure label.........9-9...
Page 690 Specifications & Consumer information Dimensions Specifications & Consumer information Dimensions 7, 8, 11 seats Item mm (inches) Overall length 5,155 (203) Overall width 1,995 (78.5) Without Roof rack 1,740 (68.5) With Roof rack 1,775 (69.9) Overall height Without Roof rack (For Russia) 1,750 (68.9) With Roof rack (For Russia) 1,785 (70.3)
Page 691: Gross Vehicle Weight
[L (cu ft)] MAX. 2,905 (102.6) 2,827 (99.8) 2,689 (95.0) Air conditioning system Please contact a professional workshop for more details. Kia recommends to contact an authorised Kia dealer/service partner. Item Weight of volume (g) Classification 850 ± 25 R-134a Refrigerant 770 ±...
Page 692: Bulb Wattage
Specifications & Consumer information Bulb wattage Bulb wattage * : if equipped Light bulb Bulb type Wattage (Watt) High beam Low beam Type A * Position and daytime running lamps Turn signal lamps PY21W LL Front fog lamps* Front High beam Low beam Type B * Position and daytime running lamps...
Page 693 Specifications & Consumer information Tyres and wheels Tyres and wheels * 1. Load Index * 2. Speed Symbol * 3. If equipped Inflation pressure [bar (psi, kPa)] Load Speed Wheel lug nut Wheel capacity capacity Normal load Maximum load Item Tyre size torque kgf・m size...
Page 694 Smartstream D2.2 (Refer to Recommended SAE viscosity number) Petrol Smartstream G3.5 GDi/MPI SK ATF SP4M-1, MICHANG ATF Automatic transmis- SP4M-1, S-OIL ATF SP4M-1, Kia sion (AT) fluid Diesel Smartstream D2.2 Genuine ATF SP4M-1 Smartstream G3.5 GDi/MPI Petrol Mixture of antifreeze and distilled Smartstream G3.5 GDi/MPI (Trailer Package)
Page 695 Specifications & Consumer information Recommended lubricants and capacities Recommended SAE viscosity number Temperature Range for SAE Viscosity Numbers °C Temperature °F Smartstream G3.5 GDi/MPI (Except Middle East, Libya, Algeria, Iran, Morocco, Sudan, Tunisia, Egypt, India) Smartstream G3.5 GDi/MPI (For Middle East, Libya, Algeria, Iran, Morocco, Sudan, Tunisia, Egypt, India) Smartstream D2.2 An engine oil displaying this American Petroleum Institute (API) Certification...
Page 696: Vehicle Identification Number (Vin)
Specifications & Consumer information Vehicle Identification Number (VIN) VIN label (if equipped) Vehicle Identification Number (VIN) The Vehicle Identification Number (VIN) is the number used in registering your vehicle and in all legal matters pertain- ing to its ownership, etc. For 11 seats/For 7, 8 seats (Middle East) OKA4051528 The VIN is also on a plate attached to the...
Page 697: Tyre Specification And Pressure Label
Specifications & Consumer information Tyre specification and pressure label Tyre specification and pres- Engine number sure label The engine number is stamped on the engine block as shown in the drawing. Smartstream G3.5 GDi/MPI (Petrol) OKA4080004R The tyres supplied on your new vehicle ODN8019022 are chosen to provide the best perfor- Smartstream D2.2 (Diesel)
Page 698: Air Conditioner Compressor Label
Specifications & Consumer information Air conditioner compressor label Air conditioner compressor Fuel label (if equipped) label Petrol engine The fuel label is attached on the fuel filler door. OSP2I089010 A compressor label informs you the type of compressor your vehicle is equipped OTM048455L with such as model, supplier part num- 僅...
Page 699: Declaration Of Conformity
The radio frequency components of the vehicle comply with requirements and other relevant provisions of Directive 1995/5/EC. Further information including the manu- facturer's declaration of conformity is available on Kia website as follows; http://www.Kia-hotline.com OTM048456L Type B OKA4082006L 僅 A. Fuel: Diesel 僅...
Page 701: Abbreviation
Abbreviation Abbreviation...
Page 702 Abbreviation Abbreviation Forward Collision-Avoidance Assist Anti-lock Brake System Hill-start Assist Control Brake Assistant System High Beam Assist Blind-Spot Collision-Avoidance Assist Highway Driving Assist Blind-Spot Collision Warning HMSL High Mounted Stop Lamp Blind-Spot View Monitor ISLA Intelligent Speed Limit Assist Cruise Control LATCH Lower Anchors and Tether for Chil- dren...
Page 703 Abbreviation Reverse Parking Distance Warning Vehicle Stability Management RCCA Rear Cross-Traffic Collision-Avoid- ance Assist RCCW Rear Cross-Traffic Collision Warning Rear View Monitor Shift-By-Wire Smart Cruise Control Safe Exit Assist Supplemental Restraint System SRSCM SRS Control Module Surround View Monitor Turn By Turn Traction Control System Tyre Identification Number TPMS...
Page 705 Index Index...
Page 706 automatic transmission shift Index indicator in manual shift mode 4-78 automatic transmission (shift lever) 6-16 air bag 3-68 air bag collision sensors 3-81 air bag warning labels 3-88 curtain air bag 3-79 battery 8-35 driver’s and passenger’s front air battery saver function 4-123 3-75 be sure the exhaust system does...
Page 707 climate control system driving info display 4-139 4-90 air conditioning refrigerant label 4-141 checking the amount of air conditioner refrigerant and compressor economical operation lubricant 4-142 6-207 climate control air filter 4-140 electric chromic mirror (ECM) 4-66 rear climate control air filter 4-141 electronic parking brake (EPB) 6-31...
Page 708 forward collision-avoidance assist (FCA) (front view camera only) 6-50 immobiliser system forward collision-avoidance 4-14 indicator lights assist (FCA) (sensor fusion) 4-103 6-61 infotainment system forward/reverse parking audio system distance warning (PDW) 4-118 audio (without touch screen) front seat adjustment for bluetooth 5-18 manual seat...
Page 709 replacing rear turn signal lamp (bulb type) 8-65 replacing room lamp (bulb type) 8-69 key positions replacing side repeater lamp ignition switch position (LED type) 8-64 illuminated ignition switch replacing stop and tail lamp starting the engine (bulb type) 8-64 keys replacing stop and tail lamp battery replacement...
Page 710 outside rear view mirror 4-66 rear cross-traffic collision- multi-collision brake (MCB) 6-43 avoidance warning (RCCW) 6-157 rear occupant alert (ROA) system 4-21 rear seat adjustment (11 seats) 3-17 Navigation-based Smart Cruise rear seat adjustment Control (NSCC) 6-142 (7, 8 seats) 3-23 rear seat adjustment (Relaxion seat)
Page 711 suspension mounting bolts 8-18 SRS care 3-86 vapour hose (for petrol engine) and steering wheel 4-62 fuel filler cap 8-17 electric power steering (EPS) 4-62 scheduled maintenance service 8-10 heated steering wheel 4-64 seat horn 4-65 armrest 3-41 tilt & telescopic steering wheel 4-63 feature of seat leather 3-10...
Page 712 trip information (trip computer) windscreen defrosting and accumulated driving information defogging 4-163 mode 4-88 defogging logic 4-166 digital speedometer 4-90 defroster 4-165 drive info display 4-89 winter driving 6-212 fuel economy 4-88 wiper blades 8-32 trip modes 4-87 wipers and washers 4-130 tyres and wheels 8-38...

Save PDF
