Johnson Controls METASYS IFC-1010 Hardware Installation page 90

SLC Loop
Channel A
RA400Z
MPS-24A/E, TB3 Terminal 1 (+) and 2 (-)
APS-6R, TB2 Terminal 1 (+) and 2 (-)
Figure 63: Employing Four Wire Smoke Detectors (Style D IDC)
90 Hardware Installation—Installing the IFC-1010/2020
All manuals and user guides at all-guides.com
Software
Type SCON
9
M500MJ
1
8
2
7
6
Software
Type PWRC
9
M5X0CJ
1
8
2
7
3
COM 6
NC
4 NO
5
Break tabs.
The M510CJ resets power
to the detectors. It is not
needed for power supplies
using resettable smoke power.
The RA400Z
annunciates the reset
of smoke detector
power. It is optional.
Power-limited
UL Listed 24 VDC
Power Supply for
Fire Protective Signaling
or
Terminal 3 (+) and 4 (-)
UL Listed
Power
Supervision
Relay
Red
Black
IDC (+)
IDC (-)
24 VDC (+)
Common (-)
UL Listed 24 VDC
Four- Wire Detectors
IDC (+)
IDC (-)
24 VDC (+)
Common (-)
N29
