Johnson Controls METASYS IFC-1010 Hardware Installation page 126

For connection of initiating devices and modules in this system, refer to
NFPA 72-1999
Figure 59 through Figure 63. This application is not suitable for separate
Auxiliary Fire
transmission of sprinkler supervisory or trouble conditions. For additional
Alarm Systems
ratings, refer to Circuit/Device Ratings and Connections Technical
Bulletin (LIT-448160).
Note: During system programming, NFPA menu option 72B must be
LIB-200
Earth Ground
Channel B-
Channel B+
Channel A-
Channel A+
+
Note: Wiring between the MBT-1 and the municipal box cannot exceed
126 Hardware Installation—Installing the IFC-1010/2020
All manuals and user guides at all-guides.com
chosen.
SLC Loop
Channel A off
Loop Interface
Board Number 1
8
7
6
5
4
3
2
1
24 VDC Common
P2
1 2 3 4 5 6
R27 P5
TB3
P4
P6
P3
MPS-24A
Figure 89: Auxiliary Fire Alarm System
1,000 meters (10,000 feet), must not cross any power lines, and
must not be in the vicinity of any high voltage.
Braided Shield/Drain Wire
To Next Device
on SLC
This M510CJ
must be programmed as:
Software Type GAS
Address: L1M97.
9
1
8
Alarm Polarity Shown!
2
7
White Wire
3
COM
6
NC
4 NO
MBT-1
5
Do Not Break Tabs!
Brown Wire
Red Wire
Black Wire
Connect wires to
two red terminals
on box.
(Contacts shown
in energized
position.)
A77-716B
Listed Power
Supervision Relay
Gamewell
Model M34-56
Local Energy
Municipal Box
