3.4.2. DC Power Cable

Power Cable + (Battery
A1 Module and Control
Module Serial Connection)
Power Cable - (Battery
A2 Module and Control
Module Serial Connection)
Power Cable (Between
A3
the Battery Modules)
A4 External Power Cable +
A5 External Power Cable -

3.4.3. Communication Cable

Battery Cascade
B1
Communication Cable (0.18m)
External Battery CAN
B2
Communication Cable (direct)
Orange/0.16m/4AWG/2
Orange Surlok Terminal
160
Black/2m/4AWG/2
Black Surlok Terminal
2000
Orange/0.18m/4AWG/1 Orange &
1 Black Surlok Terminal
180
Power Cable/Orange/2m/
4AWG/SURLOK Terminal/50-8 ring
terminal (BMS 'D+' to PCS)
2000
Power Cable/Black/2m/
4AWG/SURLOK Terminal/50-8 ring
terminal (BMS 'D-' to PCS)
2000
Black/0.18m/8 Core Super 5th
Class Twisted-pair Wire/RJ45
180
Black/3.5m/Super 5th Class
Twisted-pair Wire/2 RJ45 terminal
3500
21 / 42
1pcs/control
module
1pcs/control
module
1pcs/control
module
1pcs/control
module
1pcs/control
module
1pcs/battery
module
1pcs/control
module
