2.3. System Specifications
Product Type
Product Name
Cell Technology
System Voltage
Battery System Capacity(kWh)
Battery System Voltage(Vdc)
Battery Module Type
Battery Module Capacity(Ah)
Battery System Quantity(pcs)
Battery Module Capacity(kWh)
Battery Charge Upper-Voltage(Vdc)
Battery Module Discharge Lower-Voltage(Vdc)
Control Modue Type
Battery System Charge Current(Nominal)
Battery System Charge Current(Max)
Battery System Discharge Current(Nominal)
Battery System Discharge Current(Max)
Efficiency(@0.5C-rate)
Depth of Discharge
Communication
Short circuit rating/Duration
Protection Class
Cooling Type
Operation Temperature(℃)
Storage Temperature(℃)
Humidity
Operation Cycle Life
Operation Life(Years)
Product Certificate
Transfer Certificate
Battery Module Dimension(W*D*H mm)
Control Module Dimension(W*D*H mm)
Rack Dimension(W*D*H mm)
Weight(kg)
PowerCube-H1-48/zzzV
(zzz=240~864,in step of 48)
LFP Lithium Ion Energy Storage System
LiFePQ4
<1000V
2.4 × n(where n = 5~18)
48 × n (where n = 5~18)
H48050
50Ah
n (where n = 5~18)
2.4
54 × n (where n = 5~18)
43.5 × n (where n = 5~18)
SC1000-100S-V2
25
50
25
50
96%
95%
Modbus RTU/CAN/LAN
<3000 2ms
IP20
Nature
0~50℃
-20~60℃
5~95%
5,000
15+
IEC62619,IEC63056,RED,CE LVD,VDE2510-50,IEC62040-1
UN38.3
H48050
442× 390× 100
SC1000-100S-V2
442× 390× 132
Rack1:
600×505×2130
(where n = 5~15) , and
Rack2:
600×505×2130
(where n = 16~18)
Rack1:
77kg+ 24kg×n
(where n = 5~15)
Rack2:
68kg+ 24kg×n
(where n = 16~18)
6 / 42
PowerCube-H2-48/zzzV
(zzz=240~864,in step of 48)
3.552 × n (where n = 5~18)
H48074
74Ah
3.552
37
74
37
74
96%
95%
H48074
442×390× 132
Rack1:
600×505×2130
(where n = 5~12), and
Rack2:
600×505×2130
(where n =13~18)
Rack1:
77kg+ 32kg×n
(where n = 5~15)
Rack2:
68kg+ 32kg×n
(where n = 16~18)
