b. Place the connector without the shield of the 10-pin 1.27mm ribbon cable PARALLEL to
the Target.
c. Carefully push the 10-pin 1.27mm ribbon cable connector on the Target Debug
Connector.
Optionally, a longer ribbon cable can be ordered under the ordering code IA10PIN10P-AP-
CUST. The length must be specified at the order.
iSYSTEM gives no assurance for BlueBox operation with this cable. The cable is meant
to be used only for boundary cases where the BlueBox can't be connected to the target
through the standard debug adapter, e.g., due to the physical obstacles of the target
system. Operating the BlueBox at lower debug frequency scan speeds and not using the
trace functionality at all, might be still an acceptable compromise. It's up to the user to
test and qualify the BlueBox operation using a custom-length ribbon cable and to
determine working winIDEA settings for the system.
d. (optional) In case of DAPE connector repeat step 2. and 3. with the second cable.
6. Power ON the hardware in the following order:
a. BlueBox
b. Target
How to connect iSYSTEM Hardware (video)
isystem.com/connect-hardware
