TASKING iSYSTEM Infineon DAP/DAPE II User Manual page 16

The following pinout is valid on the target side:
Signal
Signal Description
Direction
Ground
Not Connected
Not Connected
Not Connected
IO Target Reset Pin
IO Optional 2nd DAP data
IO Optional 3rd DAP data
O DAP Clock
Not Connected
Not Connected
Not Connected
Ground
Signal Direction is described from the BlueBox perspective.
* Permanently pulled-up.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware
failure.
Signal Pin Pin
GND A1 B12
NC A2 B11
NC A3 B10
NC A4 B9
nRESET A5 B8
DAP2 A6 B7
DAP3 A7 B6
DAP0 A8 B5
NC A9 B4
NC A10 B3
NC A11 B2
GND A12 B1
USB-C pinout
Signal Signal Description
NC Not Connected
NC Not Connected
NC Not Connected
NC Not Connected
DAP1 DAP Data
nTRST* JTAG
NC Not Connected
Vref Reference Voltage
NC Not Connected
NC Not Connected
NC Not Connected
GND Ground
Signal
Direction
I
I
