Flex™ IO Isolated RTD/Thermocouple Module
Name the module
Enter IP address of ENBT
Select the module's slot number
Select the module's revision
level
Select electronic keying level
Click OK
User's Manual Pub. 0300242‐01 Rev. A
3. Configure the local Ethernet bridge module.

3.3.2 Add a Remote Ethernet Flex Adapter

After you have added the local Ethernet communication module, you must add remote
Ethernet communication modules. A remote Ethernet module is a module that resides in a
separate chassis from the controller.
If you plan to use the Flex Control Net adapter, you will need to install
!
the 1794sc-IRT8I EDS file before scheduling the network. The latest
EDS files can be found at (www.spectrumcontrols.com).
Attention
1. Select a New Module for the I/O Configuration.
