Flex™ IO Isolated Universal Input Module
3-4
Name the module
Enter IP address of ENBT
Select the module's slot number
Select the module's revision
level
Select electronic keying level
Click OK
User's Manual Pub. 0300231-03 Rev. A
Click OK
3.
Configure the local Ethernet bridge module.

3.3.2 Add a Remote Ethernet Flex Adapter

After you have added the local Ethernet communication module, you must add remote
Ethernet communication modules. A remote Ethernet module is a module that resides in a
separate chassis from the controller.
Select the local Ethernet
bridge module
