"REPEAT" METHOD:
THIS METHOD REPEATS ALL OF THE LOAD/UNLOAD INSTRUCTIONS FOR EVERY SHEET CUT. IT
INVOLVES A LONGER MAIN PROGRAM WHICH WILL TAKE UP MORE MEMORY, HOWEVER, IF AN
ALARM IS GENERATED , THERE IS NO EDITING REQUIRED TO RESTART.
( SEE ALARM PROCEDURE )
"MAIN" PROGRAM
THE FOLLOWING EXAMPLE WILL CUT THREE ( 3 ) SHEETS:
O0010
N001M81; .......................................... LOAD 1ST SHEET
*N002M98P (part subprogram # ) ............ CUT 1ST SHEET
*N003M83; .......................................... LOAD/UNLOAD
N004M98P ( part subprogram # ) ............ CUT 2ND SHEET
N005M83; .......................................... LOAD/UNLOAD
N006M98P ( part subprogram # ) ............ CUT 3RD SHEET
N007M82; ..........................................UNLOAD LAST SHEET
N008M30;
(*) THESE LINES ARE REPEATED FOR AS MANY TIMES AS THERE ARE PARTS.
"PART" SUB-PROGRAM
( PART GEOMETRY )
G91G28Z0;
G28X0Y0;
G90;
M99;
