"ON LINE" PROGRAMMING METHODS FOR LOAD/UNLOAD CELL

"L" FUNCTION METHOD:
THIS METHOD TAKES ADVANTAGE OF THE ABILITY TO PERFORM A SUB-PROGRAM CALL A
SPECIFIED NUMBER OF TIMES ( I.E. M98P____L #OF CALLS ). IT ALLOWS A MORE CONDENSED
FORMAT WHICH USES LESS PROGRAM MEMORY. THE SAME "MAIN" AND "LOADER" PROGRAMS
CAN BE USED FOR EACH JOB BY EDITING THE VARIABLES DESCRIBED BELOW FOR THE SPECIFIC
PART. IN THE EVENT OF A MACHINE ALARM IT WOULD BE NECESSARY TO SKIP TO THE POINT IN
THE "PART" SUB-PROGRAM WHERE CUTTING LEFT OFF AND FINISH THE SHEET ON THE TABLE,
REMOVING IT WITH THE LOADER IN THE "MANUAL" MODE. THEN EDIT LINE # 2 OF THE "MAIN"
PROGRAM TO SPECIFY THE REMAINING NUMBER OF SHEETS, AND RUN IN THE "ON LINE" MODE.
( SEE ALARM PROCEDURE )
"MAIN" PROGRAM
O0010
N001M81; .................................................
*N002M98P11L (# of sheets -1);
*N003M98P (part sub-program #); ...................
N004M82; ..................................................
N005M30;
"LOADER" SUB-PROGRAM
O0011
*N001M98P (part sub-program # ); ..........
N002M83; ........................................... LOAD/UNLOAD
N003M99;
"PART" SUB-PROGRAM
(PART GEOMETRY )
G91G28Z0;
G28X0Y0;
G90;
M99;
NOTE: ( * ) DENOTES LINES WITH INFORMATION WHICH WOULD VARY FOR DIFFERENT
PARTS.
( THIS PROGRAM IS RUN )
..................
"PART" SUB-PROGRAM # TO BE CUT
1ST SHEET IS LOADED
CUT L# OF SHEETS
CUT LAST SHEET
FINAL UNLOAD OF LAST SHEET CUT
