Mazak STX SC L PLUS CONTROL Training Manual page 41

oxygen air 3rd
1. 2. 3.
7.
1. O xygen solenoid (M 56)
2. A ir solenoid (M 57)
3. 3rd A ssist solenoid (M 58)
4. 3rd A ssist solenoid (M 54) H igh Pressure
5. Protection regulator
6. M anual R egulator
7. Progam m able R egulator
( no decimal point is used for the P value )
4.
5.
6.
41
