STX SC
"L PLUS CONTROL"
TRAINING
AND
APPLICATIONS
MANUAL
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STX SC L PLUS CONTROL and is the answer not in the manual?

Questions and answers

Summary of Contents for Mazak STX SC L PLUS CONTROL

  • Page 1 STX SC “L PLUS CONTROL” TRAINING APPLICATIONS MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS STX L PLUS STX START-UP PROCEDURE for L PLUS CONTROL ..........4 POWER OFF PROCEDURE ..................5 NOMENCLATURE ........................6 ROUTINE INSPECTION FOR STX SC MODELS ..............7 Chiller Unit ..........................9 Lubrication ..........................9 Focus Lens ..........................10 Vacuum Pump and Mechanical Booster Maintenance..........
  • Page 3 EFFECT OF FOCUS POINT ON CUTTING MILD STEEL WITH OXYGEN ......63 EFFECT OF FOCUS POINT WHEN CUTTING WITH INERT GAS ..........64 METHODS TO PREVENT BURNING OF CORNERS ..............65 STEEL PLATE CUTTING TECHNIQUES .................66 PROGRAM RESTART FUNCTION ..................68 CUTTING PLASTIC COATED METALS ...................70 SUPPORTING THIN MATERIALS ....................72 LOAD / UNLOAD CELL OPERATION/PROGRAMMING METHODS ......

  • Page 4: Stx Start-Up Procedure For L Plus Control

    STX START-UP PROCEDURE for L PLUS CONTROL 1> Turn on the air compressor. 2> Open the premix laser gas cylinder until the valve is seated in the open position. Primary Gauge: >142 psi. Secondary Gauge: 35 - 40 psi. 3> Open the assist gas cylinders until the valve is seated in the open position.

  • Page 5: Power Off Procedure

    POWER OFF PROCEDURE 1> Press the "LASER HIGH VOLT" OFF key ( 0 ). 2> Press the "LASER POWER" OFF key ( 0 ). When the indicator LED stops flashing continue to step no. 3. 3> Turn the "LASER" key switch to the OFF position. 4>...

  • Page 6: Nomenclature

    NOMENCLATURE The MAZAK LASER is composed of the following systems: A> Laser Resonator B> External Beam Delivery C> Operation Panel D> Work Table E> Processing Head (torch ) F> Laser Power Unit 1. Mechanical Booster 2. Vacuum Pump 3. Laser Gas Regulator 4.

  • Page 7: Routine Inspection For Stx Sc Models

    ROUTINE INSPECTION FOR STX SC MODELS IMPORTANT: The maintenance procedures outlined in this manual are a supplement to the MAZAK OPERATING & MAINTENANCE manual. Refer to the MAZAK manual in conjunction with this manual for all maintenance procedures. Remaining Pressure in the Gas Cylinder.
  • Page 8 Mechanical Booster Oil A> The mechanical booster is located in the bottom cabinet of the "LASER CONTROL UNIT". The oil level sight glass is located on the side of the mechanical booster. A window is located on the side of the "LASER CONTROL UNIT" to view the sight glass. B>...

  • Page 9: Chiller Unit

    Chiller Unit A> The chiller reservoir must be filled with distilled water, a corrosion inhibitor and a fungicide. A level gauge is located on the side of the chiller unit to indicate the fluid level. The reservoir holds approx. 40 gal. Recommended corrosion inhibitor: "ISOGUARD"...

  • Page 10: Focus Lens

    Focus Lens The focus lens should be cleaned once per week if the majority of materials cut are mild and stainless steel. If a large percentage of work is aluminum or non-metallic material, the lens may need to be cleaned daily.

  • Page 11: Mechanical Booster Oil Change

    Mechanical Booster Oil Change 1 > Run the booster for at least 10 min. so that the oil is warm and will drain easily. 2 > Turn off "Laser Power" and turn off / lock out main breaker. 3 > Open the "Air Admit plug "...

  • Page 12: Chiller Unit Maintenance

    Chiller Unit Maintenance Chiller Flushing Procedure 1 > Drain the contents of the chiller by attaching a hose to the drain port and opening the valve. 2 > Fill the chiller reservoir with tap water and the appropriate amount of flushing agent. Recommended Flush Agent: "CITRANOX"...

  • Page 13: Lubrication Of Axes And Chip Conveyor

    When the quantity of oil in the reservoir reaches its lower limit, an alarm will occur and operation will be stopped until the level is brought within the acceptable range. See your MAZAK OPERATING AND MAINTENANCE manual for details about adding oil and cleaning the oil return pipe.

  • Page 14: Optic Cleaning Procedure

    ALWAYS wear the proper, clean clothing including finger cots or latex gloves. 8 > ALWAYS wash your hands after handling a focus lens. See your MAZAK OPERATING AND MAINTENANCE manual for further information. Optic cleaning procedure 1 > Lay the optic on several sheets of clean/dry lens paper.

  • Page 15: Dry Air Filter (Machine)

    Lens M ount V iton O -R ing T hick S pacer F ocus Lens T hin S pacer W ave W asher R etaining R ing Installing the Focus Lens 1 > Clean the lens mount with Methanol and a clean dry cloth. 2 >...

  • Page 16: Stx Sc Preventative Maintenance Schedule

    EVERY 2 CHANGE OIL MONTHS 20> DRY AIR FILTER (MACHINE) EVERY 2000 HRS. CHANGE FILTER 21> EXHAUST UNIT EVERY 2000 HRS. CLEAN UNIT 22> CHILLER WATER EVERY 6 FLUSH SYSTEM MONTHS SEE THE MAZAK OPERATING AND MAINTENANCE MANUAL FOR FURTHER INFORMATION...

  • Page 17: Stx/Sc: Procedure To Clear Maintenance Alarms

    In some cases the interval at which the alarms are displayed may be sooner than the item actually requires. When a maintenance item occurs, call Mazak with the current hour reading and confirm whether or not the alarm merits attention. The procedure below will reset maintenance alarms.

  • Page 18: Safety Notes For Set-Up Procedure

    Safety notes for set-up procedure 1. During the following procedures the laser is emitted from the torch. Since the operator is required to view the reflected beam at a close proximity, plastic safety glasses are mandatory. 2. Confirmation of the laser discharge in a ready state can be determined by the "cw" or "pulse" led on the operating panel.

  • Page 19: Stx Sc Set-Up Procedure

    STX Sc Set-Up Procedure FOCUSING PROCEDURE: Turn on the laser. Place a piece of 304 stainless steel plate ( at least 0.100" thick ) on the table and clamp. Position the torch over the plate using the "manual handle" mode until the torch is 2 - 3" in front of the work clamp.
  • Page 20 Note: Make sure that the handle is always turned in the same direction when moving in the "x" axis so that you do not back over a previously burnt spot. Turn the "z" axis up ( 1 ) turn of the handle. Open the shutter and turn the handle in the negative( down ) direction until you see a blue flame and stop / close the shutter key.
  • Page 21 Zero all axis in the "MANUAL ORIGIN" mode. > Press the "M" (MENU) key twice. > Press THE "ORIGIN" key. > Press "0", "INPUT", "0", "INPUT", "0", "INPUT" Press "RESET" AND RAISE THE "Z" AXIS. Screw the nozzle in until it stops. Place a piece of paper under the torch and lower the "z"...
  • Page 22 NOZZLE CENTERING: Raise the "z" axis and remove the stainless plate. In "MANUAL LASER" input the following: "PEAK POWER" INPUT "FREQUENCY" INPUT "DUTY" INPUT "PRESSURE" INPUT Press "NORMAL PULSE" Press "OXYGEN" Press "INPUT" Place a piece of tape over the end of the nozzle and lower the "Z" axis so that the nozzle is at the approximately cutting height using the "HANDLE MODE".

  • Page 23: Procedure For Replacing The Nozzle Tip

    Procedure for Replacing The Nozzle Tip TURN THE "STYLUS UP SELECT" SWITCH TO THE "INVALID" POSITION WHICH WILL LOWER THE STYLUS FOOT. REMOVE THE NOZZLE TIP. SCREW ON THE NEW NOZZLE TIP MAKING SURE THAT IT IS TIGHT. TURN THE "STYLUS UP" SWITCH TO THE "1" POSITION. POSITION THE TORCH OVER A CLAMPED PIECE OF MATERIAL AT LEAST 0.100"...
  • Page 24 PRESS "OXYGEN" PRESS "INPUT" LOWER THE "Z" AXIS TO THE APPROXIMATE CUTTING HEIGHT AND QUICKLY OPEN/CLOSE THE SHUTTER KEY. RAISE THE "Z" AXIS AND ADJUST THE NOZZLE CENTERING USING THE KNURLED SCREWS AT THE BASE OF THE TORCH. REPEAT STEPS 14 - 15 UNTIL THE BEAM IS CENTERED IN THE NOZZLE. PRESS "RESET".

  • Page 25: Procedure For Adjustment Of The Weidmuller Non-Contact Sensor

    PROCEDURE FOR ADJUSTMENT OF THE WEIDMULLER NON-CONTACT SENSOR 1> PERFORM THE STANDARD SET-UP PROCEDURE SUBSTITUTING THIS PROCEDURE FOR THE "PROFILER ADJUSTMENT".( REMOVE NOZZLE FOR FOCUSING, CERAMIC ON ) 2> PRESS THE "NON-CONTACT NEGLECT" SWITCH SO THAT THE LED ON THE BUTTON IS LED ON: NON-CONTACT SENSOR LED OFF:...
  • Page 26 NOTES ON THE WEIDMULLER NON-CONTACT SENSOR 1> ALWAYS MAKE SURE THAT THE "NON-CONTACT NEGLECT" SWITCH IS IN THE CORRECT POSITION FOR THE TYPE OF SENSOR USED. A CRASH WILL OCCUR IF THIS IS OVERLOOKED IN EITHER THE CONTACT OR NON-CONTACT MODE. 2>...

  • Page 27: Cut Mode Programming

    CUT MODE PROGRAMMING L32 Data Format: > Each line of information is defined as a "BLOCK" > Each "BLOCK" consists of "WORDS" (G-codes/M-codes) > A maximum of 4 G-codes and 1 M-code are allowed per block > Each block of information is terminated by the "EOB" character (;) >...
  • Page 28 G00: Positioning (rapid feed) Format: G00X__ Y__; The G00 command allows the axes to be positioned to the point where cutting will take place. The code is expressed with an X, Y and/or Z value which corresponds to a coordinate position. EXAMPLE: In the diagram below, the lower left corner of the part has been established as the reference point.
  • Page 29 4.0 - Y 0 - G01Y4.0; G01X3.5; G01X6.0Y2.0; G01Y0.0; G01X0.0; G90 (absolute) , G91 (incremental) > There are two modes of programming: In the G90 mode all axis movement is performed using the reference point (G92) as the start point regardless of the current position.
  • Page 30 EXAMPLE: 3.0 - 2.0 - Y 0 - ABSOLUTE INCREMENTAL G90; G91; G01Y2.0; G01Y2.0 X1.0; X1.0; Y3.0; Y1.0; X2.0; X1.0; Y2.0; Y-1.0; X3.0; X1.0; Y0.0; Y-2.0; X0.0; X-3.0; G02/G03: Circular Interpolation There are two methods of circular interpolation: Format; G02(G03) X__ Y__ I__ J__ ( G02 = clockwise rotation) G02(G03) X__ Y__ R__ ( G03 = counterclockwise rotation)
  • Page 31 - If the X and Y point is not specified or they are the same as the start point, a 360 degree circle will be made around the center point specified by the I and J values. EXAMPLE: G01Y1.0; G01Y-1.0; G01X1.0;...
  • Page 32 G90G92X0Y0; G90G92X0Y0; M98P____; M98P____; G01Y3.0; G01Y3.0; G02X1.0R2.0; G02X1.0R-2.0; G01Y0.; G01Y0.; G01X0.; G01X0.; M98P____; M98P____; M30; M30; Automatic corner rounding / chamfering: Format: G01X__ Y__ #R__; G01X__ Y__ #C__; The control will except a #R__ or #C__ statement at the end of a G01 command which will automatically produce a corner with a radius or chamfer.
  • Page 33 G04: Dwell Format: G04X__; The G04 command causes a pause in operation for the amount of time specified by the X or P value. X = seconds P = milliseconds EXAMPLE: G04X1.5; This command will produce a dwell of 1.5 sec. and could be used to allow pierce completion, purging of assist gas etc.
  • Page 34 NOTE: Always perform this operation as follows: G91G28Z0.0; Incrementally raise the Z axis so that it is clear of any tipped parts. G28X0.0Y0.0; Once the Z axis is clear, the X and Y can be moved. G41 / G42: Cutter Radius Compensation Because the laser beam has a discernible diameter it will create a "kerf"...
  • Page 35 D = cutter compensation number R = cutter compensation amount G51: Scaling Mode The G51 command will enlarge or reduce the size of a part. Format: G51X__ Y__ P__; - The X and Y values determine where the scaling center point is located. - The P value determines the scaling factor.
  • Page 36 G 52 reference point G 92 reference point G53: Commands in Machine Coordinate System The G53 command can be used to position the axes using the machine zero as a reference point rather than the G92 or other reference points. G54 - G59: Work Coordinate System The G54 - G59 commands can be used to position the axes using a reference point stored as a parameter.
  • Page 37 L32 Control: Feedrate is adjusted automatically. L32B Control: Parameter # 19 "Auto Corner Feedrate Speed", ( value = micromillimeters ) G64: Continuous Cutting Mode The G64 command is used to cancel the G61 and G62 commands. G65: Custom Macro Call The G65 command is used to call a custom macro subprogram and set all variables necessary for its operation.
  • Page 38 The G82 command is used to set the variables which control the laser. Format: G82P__ Q__ R__ M__ F__; P = Power (watts, 1 - maximum rating) 1500W 1000W 500W G 82P1500Q 100R 100M 69; 250W ( continuous w ave / cw ) TIM E G 82P1000Q 100R 50M 69;...
  • Page 39 G81: Power Ramping ( Adaptive Control ) Format: G81P__ Q__ R__ M__ F__; The G81 command can be used to change the cut condition at corners or areas of intricate geometry so that burning or rounding does not occur. EXAMPLE: R am ping O ff R am ping D istance R am ping O n...
  • Page 40 standard set-up for N TX standard set-up for STX 0.04" 0.04" 0.04" gap / focus on surface 0.04" gap / focus 0.02" above surface G 87P15 G 87P0 G 87P-5 0.100" 0.02" 0.04" CAUTION: The minimum value for the G87 command is: G87P-7; This setting will leave an 0.012"...
  • Page 41 ( no decimal point is used for the P value ) oxygen 1. O xygen solenoid (M 56) 2. A ir solenoid (M 57) 3. 3rd A ssist solenoid (M 58) 4. 3rd A ssist solenoid (M 54) H igh Pressure 5.

  • Page 42: M - Codes

    M - CODES: M - CODES are miscellaneous functions of the NC machine. One M - Code can be specified per block. If more than one M-Code is specified on a particular block, the last code will be valid. M00: Program Stop When an M00 command is read during program execution, all operations are stopped until the "CYCLE START"...
  • Page 43 The M22 command activates the high voltage power supplies and turns on the laser according to the parameters specified by the G82 code. M23: Laser Discharge Off The M23 command cancels the parameters specified by the G82 code and returns the laser to its normal "simmer"...
  • Page 44 M54: 3rd Assist Gas ( High Pressure ) The M54 command is used to call the 3rd assist gas for which the pressure is adjusted by the manual regulator located below the operation panel. M55: 3rd Assist Gas ( Low Pressure ) The M55 command is used to call the 3rd assist gas for which the pressure is adjusted by parameter #13 ( NTX ).
  • Page 45 M77 and M78: Spare M-Code M81: Loading Cycle Start ( option ) The M81 command allows machines equipped with the LOAD / UNLOAD feature to initiate loading sequence programmably. M82: Unloading Cycle Start ( option ) The M82 command allows machines equipped with the LOAD / UNLOAD feature to initiate the unloading sequence programmably.

  • Page 46: Laser On Subprograms

    LASER ON SUBPROGRAMS STANDARD PIERCE: G82P____Q___R__M__;..........Piercing conditions G88P__M__; .............. Piercing assist gas pressure and type G87P0; ................ Piercing focal point adjustment M32; ................Profiler ON M20; ................Shutter open M22; ................Discharge ON G04X___; ..............Dwell for pierce completion G82P____Q___R___M__F_.;...

  • Page 47: Laser Off Subprograms

    LASER OFF SUBPROGRAMS VERSION # 1: STANDARD METHOD (internal cut-outs) M23; ............Discharge OFF M09; ............Assist gas OFF M31; ............Profiler OFF G91G00Z2.0; ......... Incemental raising of "Z" axis G90; ............Return to absolute mode ( if necessary ) M99;...

  • Page 48: Normal Operations

    "hard overtravel" alarm will occur when a limit switch is reached. To clear a "hard overtravel" the "overtravel release" key must be used in conjunction with the "JOG" and "RESET" keys (see the alarm section of this manual or the "MAZAK OPERATING and MAINTENANCE" manual. 4>...
  • Page 49 1.0 kg/cm2 = 14.2 psi. 16> Whenever an alarm occurs, check the "ALARM" screen to see if there is more than one alarm. Do this before pressing "RESET". If you must call MAZAK, write down the alarm no. and description for every alarm present.

  • Page 50: Cut Condition Troubleshooting Outline

    Cut Condition Troubleshooting Outline PROGRAM PARAMETERS ( ARE THE FOLLOWING SET CORRECTLY ? ) POWER ( P ) FREQUENCY ( Q ) DUTY ( R ) PULSE TYPE ( M67, M68 OR M69 depending on availability ) FEEDRATE ASSIST GAS TYPE ( M56, M57 OR M58 IF PROGRAMMABLE ) ( IS THE PROPER GAS CONNECTED TO THE GAS - IN PORT ) ASSIST GAS PRESSURE ( DOES THE PRESSURE PROGRAMMED MATCH THE ACTUAL PRESSURE AS...
  • Page 51 HAS THE FOCUS LENS BEEN CONTAMINATED BY WATER OR OIL ? ( IF THE LENS HAS BEEN EXPOSED TO WATER OR OIL FROM ANY SOURCE, INCLUDING CLEANING AGENTS, THE COATING MAY BE DAMAGED EVEN THOUGH IT APPEARS OK. ) IS THE MATERIAL COMPOSITION AND SURFACE QUALITY ADEQUATE ? IS THE MATERIAL TEMPERATURE TOO HIGH DUE TO CUTTING IN CLOSE PROXIMITY TO A PREVIOUSLY CUT HOLE ? ARE THE CUT CONDITIONS SUITABLE FOR THE PARTICULAR GEOMETRY ?

  • Page 52: Getting The Most Consistent Cut

    Getting the Most Consistent Cut When test cutting a new part or new material, the preferred method is to cut a small circle or square before cutting the part. If a difficult geometry is present in the part, such as a material thickness hole or a small notch, simulate the cut in a test square to find the best cut condition.
  • Page 53 limit of the window for assist gas pressure. Now lower the assist gas pressure until the lower limit of good cutting is found. If the cutting window was found to lie between 2.0kgs and 5.0kgs, set the pressure to 3.5kgs which is the middle of the window in this case.

  • Page 54: Cutting Applications

    CUTTING APPLICATIONS PIERCING SYMPTOM: BLOW-OUT OCCURS DURING PIERCING DEFINITION OF BLOW-OUT: A shower of sparks are emitted upwards from the point of piercing. IS THE NOZZLE DAM AGED, REPAIR OR REPLACE B LOCKED B Y SPLATTER OR THE NOZZLE. THE B EAM CENTERING OFF? DOES THE B LOW OUT OCCUR INCREASE THE B EFORE THE DW ELL TIM E HAS...
  • Page 55 SET THE CUTTING PARAMETERS NO/? SET TO A PROVEN SPECIFICATION TO THE CLOSEST AVAILABLE EITHER USED IN THE PAST OR CUTTING CONDITION. TAKEN FROM MAZAK CUTTING - CHECK OVERRIDES DATA CHARTS? IF BLOWOUT STILL OCCURS IS THE SET UP CORRECT? NO/?
  • Page 56 SET THE CUTTING PARAMETERS SET TO A PROVEN SPECIFICATION TO THE CLOSEST AVAILABLE EITHER USED IN THE PAST OR CUTTING CONDITION. TAKEN FROM MAZAK CUTTING DATA CHARTS? IF DROSS STILL OCCURS IS THE SET UP CORRECT? NO/? SET UP FOR THE CLOSEST - FOCUS AVAILABLE CUTTING CONDITION.
  • Page 57 SET THE CUTTING PARAMETERS NO/? SET TO A PROVEN SPECIFICATION TO THE CLOSEST AVAILABLE EITHER USED IN THE PAST OR CUTTING CONDITION. TAKEN FROM MAZAK CUTTING DATA CHARTS? IF SELF BURNING STILL OCCURS IS THE SET UP CORRECT? NO/? - FOCUS...
  • Page 58 SET THE CUTTING PARAMETERS NO/? SET TO A PROVEN SPECIFICATION TO THE CLOSEST AVAILABLE EITHER USED IN THE PAST OR CUTTING CONDITION. TAKEN FROM MAZAK CUTTING DATA CHARTS? IF POOR EDGE PERSISTS IS THE SET UP CORRECT? NO/? - FOCUS...
  • Page 59 MILD STEEL CONTINUED TECHNIQUE: Cutting small holes/geometry's in plate ( 3/16" and over ). SYMPTOM: Self burning occurs during lead-in. SOLUTION: Program a dwell with beam off after pierce to allow the material to cool. example: G82P___Q___R___M___; ....... piercing parameters G88P___M56;...

  • Page 60: Cutting Stainless Steel

    SET THE CUTTING PARAMETERS NO/? SET TO A PROVEN SPECIFICATION TO THE CLOSEST AVAILABLE EITHER USED IN THE PAST OR CUTTING CONDITION. TAKEN FROM MAZAK CUTTING DATA CHARTS? IF BLOWOUT STILL OCCURS IS THE SET UP CORRECT? NO/? - FOCUS SET UP FOR THE CLOSEST AVAILABLE CUTTING CONDITION.
  • Page 61 STAINLESS STEEL AND ALUMINUM TECHNIQUE: Special lead-in techniques. SYMPTOM: Cut is lost as soon as it is begun after piercing. SOLUTION: Perform the lead-in at a reduced feedrate. NOTE: CUTTER COMPENSATION MAY BE CANCELLED WHEN USING THIS METHOD. example:G90G00X__Y__; M98P____; ......
  • Page 62 SET THE CUTTING PARAMETERS SET TO A PROVEN SPECIFICATION TO THE CLOSEST AVAILABLE EITHER USED IN THE PAST OR CUTTING CONDITION. TAKEN FROM MAZAK CUTTING DATA CHARTS? IF DROSS STILL OCCURS IS THE SET UP CORRECT? NO/? SET UP FOR THE CLOSEST - FOCUS AVAILABLE CUTTING CONDITION.

  • Page 63: Effect Of Focus Point On Cutting Mild Steel With Oxygen

    EFFECT OF FOCUS POINT ON CUTTING MILD STEEL WITH OXYGEN When the machine set-up procedure is performed the focus point of the lens is adjusted to a specified position either above or below the surface of the material. When cutting mild steel the focus point is raised higher as the thickness increases.

  • Page 64: Effect Of Focus Point When Cutting With Inert Gas

    EFFECT OF FOCUS POINT WHEN CUTTING WITH INERT GAS When cutting various materials with inert assist gasses such as nitrogen and argon, the focus set-up differs greatly from that of oxygen cutting. To reduce or eliminate dross the focus point must be moved deeper into the material.

  • Page 65: Methods To Prevent Burning Of Corners

    POINT WHERE YOU NEED IT. RAMPING IS CANCELED WITH A G83. BOTH CONDITIONS MUST CUT WITH THE SAME ASSIST GAS PRESSURE. (SEE THE MAZAK PROGRAMMING MANUAL FOR EXAMPLES) 4> DWELL / A SUBPROGRAM IS CALLED UP AT EACH CORNER WHICH...

  • Page 66: Steel Plate Cutting Techniques

    STEEL PLATE CUTTING TECHNIQUES WHEN CUTTING STEEL PLATE THERE ARE SEVERAL PROGRAMMING TECHNIQUES WHICH HELP MINIMIZE THE EFFECTS OF EXCESS HEAT CAUSED BY PIERCING AND CUTTING THE MATERIAL. THESE TECHNIQUES INCLUDE THE FOLLOWING: HEAT BARRIER SEGMENTS THIS TECHNIQUE INVOLVES CUTTING A STRAIGHT LINE BETWEEN ROWS OF PARTS IN ORDER TO STOP HEAT TRANSFER BETWEEN ROWS.
  • Page 67 PART LAYOUT EXAMPLE THIS LAYOUT EXAMPLE SHOWS THE FOLLOWING TECHNIQUES: 1> HEAT BARRIER SEGMENTS. 2> STAGGERING INTERNAL GEOMETRY’S. 3> CHAIN CUTTING. Depending on the size of the part and spacing of the internal cut outs, sometimes all internal geometry can be cut for each part before cutting the perimeter.

  • Page 68: Program Restart Function

    PROGRAM RESTART FUNCTION During operation, if “RESET” is pressed, the program will restart at the beginning unless this procedure is followed. This procedure will allow operation to continue from the point it was at when an alarm occurred without repeating what has already been cut.
  • Page 69 MACHINE GRAPHICS (L PLUS CONTROL) 1> Position the axes close to home position, but not so close that the part to be simulated would not fit on the table. The L Plus control has a feature which looks ahead in the program to see if there are any movements that would cause an overtravel.

  • Page 70: Cutting Plastic Coated Metals

    CUTTING PLASTIC COATED METALS When cutting plastic coated metals with a contact style profiler, sometimes the plastic coating will “balloon” due to the pressure of the assist gas. This may cause the stylus foot to ride on the plastic causing the focus point to be lost and subsequently the cut is lost or becomes poor.
  • Page 71 PRE-BURNING ENTIRE PART (FOR LARGE HOLES AND PARTS) When cutting thick materials which require assist gas pressures in excess of 6.0 kg/cm , there may be ballooning at any point during cutting. For these materials it is possible to pre-burn the entire part before cutting, in order to create a channel through which the assist gas can escape without causing the coating to separate.

  • Page 72: Supporting Thin Materials

    If the slats are severely worn, the material may be sitting below the soft overtravel limit. In this case the slats must be replaced. See the MAZAK operating manual for recommended slat drawings.

  • Page 73: Load / Unload Cell Operation/Programming Methods

    LOAD / UNLOAD CELL OPERATION/PROGRAMMING METHODS 1 > WHEN CREATING A NEST OF PARTS, ALWAYS HAVE THE PARTS POSITIONED LENGTH-WISE IN THE "X" AXIS. IF NOT, THE PARTS WILL FALL BETWEEN THE SUPPORT SLATS AND INTERFERE WITH THE LOADER. THIS WILL DAMAGE PARTS AS WELL AS MAKE PART RETRIEVAL MORE DIFFICULT AND TIME CONSUMING FOR THE OPERATORS.

  • Page 74: On Line" Programming Methods For Load/Unload Cell

    "ON LINE" PROGRAMMING METHODS FOR LOAD/UNLOAD CELL "L" FUNCTION METHOD: THIS METHOD TAKES ADVANTAGE OF THE ABILITY TO PERFORM A SUB-PROGRAM CALL A SPECIFIED NUMBER OF TIMES ( I.E. M98P____L #OF CALLS ). IT ALLOWS A MORE CONDENSED FORMAT WHICH USES LESS PROGRAM MEMORY. THE SAME "MAIN" AND "LOADER" PROGRAMS CAN BE USED FOR EACH JOB BY EDITING THE VARIABLES DESCRIBED BELOW FOR THE SPECIFIC PART.
  • Page 75 "REPEAT" METHOD: THIS METHOD REPEATS ALL OF THE LOAD/UNLOAD INSTRUCTIONS FOR EVERY SHEET CUT. IT INVOLVES A LONGER MAIN PROGRAM WHICH WILL TAKE UP MORE MEMORY, HOWEVER, IF AN ALARM IS GENERATED , THERE IS NO EDITING REQUIRED TO RESTART. ( SEE ALARM PROCEDURE ) "MAIN"...

  • Page 76: Restarting Loader After Alarm Procedure

    RESTARTING LOADER AFTER ALARM PROCEDURE If an alarm occurs which requires pressing reset, perform the following: 1> Press "command" and note which line was being executed. 2> Press "reset". 3> Correct the cause of the alarm. 4> Edit the "part" sub-program: change the last line (M99;) to ( M30;...

  • Page 77: Multiple Part Example

    MULTIPLE PART EXAMPLE There are several ways to repeat a part over an entire sheet. If this must be done manually without the nesting features of a CAD system and “MACRO” is not available, the following method is most commonly used. THE ZERO POINT FOR THIS EXAMPLE IS AT THE LOWER LEFT CORNER OF THE PART.

  • Page 78: Example Part Program

    EXAMPLE PART PROGRAM 1.434 0.711 2.582 .455 D 3.365 (2) .574 R 2.665 1.281 0.939 0.334 3.679 2.008 3.067 4.00 G91G28Z0.0; G90G92X0.Y0.; G00X0.711Y3.365; G00X0.Y-0.20; M98P9000; M98P9000; G42G01Y3.1375D1; G41G01Y0.0D1; G02J0.2275; Y4.0; G40G01Y3.1675; X4.0; M98P9001; Y0.0; G00X2.008Y2.665; X-0.04; M98P9000; G40X-0.10; G42G01X2.582D1; M98P9001; Y1.281;...
  • Page 79 NTX 5" LENS TOOL 0.2450 1.6150 0.145 0.3425 1.5175 1.7150 1.590 1.500 1.340 0.800 1.8600...
  • Page 80 NTX 7.5" LENS TOOL 0.2375 2.3625 4.00 3.125 2.60...
  • Page 81 TRAINING PART SAMPLE 1.137 1.859 2.191 4.00 2.999 2.300 1.049 D IA . 1.304 W ID TH .293 0.471 D IA . 0.605 0.776 0.364 0.967 1.570 3.076 4.00...
  • Page 82 NOZZLE TOOL (2) 0.125 (2) 0.250 (2) 0.25 1.12 0.25 0.12...

  • Page 83: Consumable And Spare Parts List For Stx Sc

    CONSUMABLE AND SPARE PARTS LIST FOR STX SC 1-31-97 PART DESCRIPTION PART NO. RECOMMENDED QUANTITY NOZZLE TIP 46603350520 NOZZLE BODY 46603350510 NOZZLE RETAINER 46683300030 STYLUS PIN 36682300280 STYLUS RING 46602350080 STYLUS ARM 36682300050 STYLUS ARM (W/LOADER) 36682300281 7.5" HIGH PRESSURE LENS Z50ZZ00520A INDIUM WIRE Z50MB000230...

  • Page 84: Procedure To Save Machine Parameters

    PROCEDURE TO SAVE MACHINE PARAMETERS FOR THE L1 & L2 CONTROL (L1PARAM.DOC) This procedure will save the hidden “NC” parameters which control machine operation. When the machine is originally shipped there is a hard copy of these parameters in the electrical control cabinet. It is a good idea to make a copy of this list.

  • Page 85: Stx And Stx Sc How To Sheet

    STX and STX SC How to Sheet To start a new program: 1. Press the D Menu 2. Press program 3. Press program again 4. Enter a number from 1-9999 5. Press Input If the alarm “program already exists” occurs, press reset, and clear and return to step 4. Be sure not to choose the same number.
