EVALUATION BOARD HARDWARE

POWER SUPPLIES

The EVAL-AD5600PMDZ requires an external source for the
analog and digital supply. See Table 2 for more details.
Both AGND and DGND inputs are provided on the EVAL-
AD5600PMDZ. The AGND and DGND planes are connected
at one location close to the AD5600. To avoid ground loop
problems, it is recommended that AGND and DGND not be
connected elsewhere in the system.
All supplies are decoupled to ground with 10 µF tantalum and
0.1 µF ceramic capacitors.
Table 2. Power Supply Connectors
Connector No.
P2-1
P6-1
P2-2, P6-2
P3-1
P3-2
Table 3. Test Point Descriptions
Test Point
GND
VCC
DVDD
VLOGIC
VDD
CS_N
DIN
SCLK
LDAC_N
VOUT
These test points are not populated on the evaluation board, but the user can use the copper pads to solder the test points.
1
Table 4. Link Options Setup for
Link Position
P7 A (default)
B
P8 A (default)
B
P9 A (default)
B
User Guide
Label External Voltage Supplies Description
AVDD Positive analog supply. Connect 5.0 V to this terminal.
AVSS Negative analog supply. Connect −5.0 V to this terminal.
AGND Analog ground.
DVDD Digital supply. Connect 5.0 V to this terminal.
DGND Digital ground.
1
Description
Board ground.
PMOD digital supply.
External digital supply.
IOVDD digital supply.
VDD analog supply.
Chip select.
Serial data input signal.
Serial clock input signal.
LDAC input signal.
Buffered DAC output voltage.
SDP Control
Description
VLOGIC test point is connected to DVDD.
VLOGIC test point is connected to the VCC test point on PMOD.
LDAC is connected to PMOD.
LDAC is connected to ground.
VREF is connected to
VREF is connected to J1. Connect an external reference voltage to J1.

TEST POINTS

The EVAL-AD5600PMDZ has various test points for debugging
and monitoring purposes. These test points are described in
Table 3.

VOLTAGE REFERENCES

The EVAL-AD5600PMDZ has an on-board voltage reference
with a value of 2.5 V. Note that the
an external supply through the AVDD connector (see Table 2).

LINK OPTIONS

A number of link options are incorporated on the EVAL-
AD5600PMDZ and must be set for the required operating
conditions before using the board. The functions of these link
options are described in Table 4.
ADR225 output.
Rev. 0 | Page 5 of 8
UG-1584
ADR225 requires the use of
