Gateway Capacity

3.4. Gateway Capacity
Element
Modbus interface
Maximum number of Modbus
server devices supported
Type of Modbus server devices
supported
Modbus addresses range
Maximum number of Modbus
signals
Maximum number of
communication objects
Maximum number of KNX
group addresses
Maximum number of possible
KNX associations
NOTE
When installing more than 32 devices, you will need a repeater. This is an inherent limitation of the
Modbus protocol.
USER MANUAL Version 1.0
100 version
100 (see note below)
Those supporting Modbus protocol
communication over RTU (EIA-485)
1 to 255
100
KNX interface
205 signal objects:
100 status objects
100 control objects
4 error status objects
1 optional object for heartbeat
700
700
