Modbus RTU Client to KNX TP Gateway
NOTE
ETS creates a tab for each device.
– Number of signals: Defines the number of Modbus signals to integrate. Once a signal is defined, ETS
automatically creates one or two KNX objects, depending on the selected function. When selecting both
write and read functions, ETS creates two objects (one status object and one command object); but if you
only select the function write or the function read, ETS creates one single object (a command object for the
write function or a status object for the read function).
IMPORTANT
If you try to integrate more than 100 devices or signals, this message will popup:
The bottom side of the window shows the Modbus device table, where you can:
• See each device and its name.
• Change the server address.
• Change the number of signals.
NOTE
You can change this from the Device Tab, also.
• Activate or deactivate each device.
IMPORTANT
The signals of deactivated devices won't be transferred to the gateway.
Page 16 of 20
General Configuration Tab
