Summary of Contents for HMS Networks Intesis KNX
- Page 1 M-Bus Meters USER MANUAL Issue date: 06/2018 r1.1 ENGLISH...
- Page 2 KNX – M-Bus Intesis User Manual r1.1 EN Important User Information Disclaimer The information in this document is for informational purposes only. Please inform HMS Industrial Networks of any inaccuracies or omissions found in this document. HMS Industrial Networks disclaims any responsibility or liability for any errors that may appear in this document.
- Page 3 KNX – M-Bus Intesis User Manual r1.1 EN Gateway for the integration of M-Bus devices into KNX home automation systems. ORDER CODE LEGACY ORDER CODE INKNXMEB0100000 IBKNXMEB0100000 INKNXMEB0200000 IBKNXMEB0200000 INKNXMEB0600000 IBKNXMEB0600000 INKNXMEB1200000 IBKNXMEB1200000 © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice 3 / 17...
-
Page 4: Table Of Contents
Connection to M-Bus ........................10 Connection to the configuration tool ....................10 4 Set-up process and troubleshooting ...................... 11 Pre-requisites ..........................11 Intesis MAPS. Configuration & monitoring tool for Intesis KNX series .......... 11 4.2.1 Introduction ..........................11 4.2.2 Connection ..........................11 4.2.3... -
Page 5: Description
This document describes the integration of M-Bus meters with KNX home automation systems using the gateway Intesis KNX - M-Bus. The aim of this integration is to make accessible M-Bus devices signals and resources from a KNX network, as if it was a part of the own KNX system and vice-versa. -
Page 6: Functionality
KNX – M-Bus Intesis User Manual r1.1 EN Functionality Intesis polls, either continuously or only when ordered from the KNX, the M-Bus devices to obtain updated readings for the points configured in it (the points corresponding to measures and states of the meters in the integration points list explained later in this document). -
Page 7: Gateway's Capacity
KNX – M-Bus Intesis User Manual r1.1 EN Gateway’s capacity Intesis capacity is listed below: Element Notes version version version version Type of KNX devices KNX TP-1 Communication with KNX TP-1 networks. Maximum number of points that can be Number of KNX 1500 3000 defined in the virtual KNX device inside the... -
Page 8: Knx System
2 KNX System In this section, a common description for all Intesis KNX series gateways is given, from the point of view of KNX system which is called from now on internal system. Connection with the MBUS system is also called from now on external system. -
Page 9: Connections
KNX – M-Bus Intesis User Manual r1.1 EN 3 Connections Find below information regarding the Intesis connections available. Power Supply Must use NEC Class 2 or Limited Power Source (LPS) and SELV rated power supply. Respect polarity applied of terminals (+) and (-). Be sure the voltage applied is within the range admitted (check table below). -
Page 10: Powering The Device
KNX – M-Bus Intesis User Manual r1.1 EN Powering the device A power supply working with any of the voltage range allowed is needed (check section 5). Once connected the RUN led (Figure above) will turn on. WARNING! In order to avoid earth loops that can damage the gateway and/or any other equipment connected to it, we strongly recommend the use of DC power supplies, floating or with the negative terminal connected to earth. -
Page 11: Set-Up Process And Troubleshooting
® Intesis MAPS is a Windows compatible software developed specifically to monitor and configure Intesis KNX series. The installation procedure and main functions are explained in the Intesis MAPS User Manual for KNX. This document can be downloaded from the link indicated in the installation sheet supplied with the Intesis device or in the product website at www.intesis.com... -
Page 12: Configuration Tab
KNX – M-Bus Intesis User Manual r1.1 EN 4.2.3 Configuration tab Select the Configuration tab to configure the connection parameters. Three subsets of information are shown in this window: General (Gateway general parameters), KNX Server (KNX interface configuration) and M-Bus (M-Bus configuration parameters). -
Page 13: Sending The Configuration To Intesis
KNX – M-Bus Intesis User Manual r1.1 EN 4.2.5 Sending the configuration to Intesis When the configuration is finished, follow the next steps. 1.- Save the project (Menu option Project->Save) on your hard disk (more information in Intesis MAPS User Manual). - Page 14 KNX – M-Bus Intesis User Manual r1.1 EN Figure 4.5 Diagnostic More information about the Diagnostic section can be found in the Configuraion Tool manual. © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice 14 / 17...
-
Page 15: Set-Up Procedure
KNX – M-Bus Intesis User Manual r1.1 EN Set-up procedure 1. Install Intesis MAPS on your laptop, use the setup program supplied for this and follow the instructions given by the Installation wizard. 2. Install Intesis in the desired installation site. Installation can be on DIN rail or on a stable not vibrating surface (DIN rail mounted inside a metallic industrial cabinet connected to ground is recommended). -
Page 16: Electrical & Mechanical Features
KNX – M-Bus Intesis User Manual r1.1 EN 5 Electrical & Mechanical Features Plastic, type PC (UL 94 V-0) Size: Coin 20mm x 3.2mm Net dimensions (d h): 90x88x56 mm Enclosure Battery Capacity: 3V / 225mAh Recommended space for installation (d h): 130x100x100mm Type: Manganese Dioxide Lithium Color: Light Grey. -
Page 17: Dimensions
KNX – M-Bus Intesis User Manual r1.1 EN 6 Dimensions 56 mm (h) 88 mm (w) 90 mm (d) Recommended available space for its installation into a cabinet (wall or DIN rail mounting), with space enough for external connections 100 mm (h) 130 mm (d) 100 mm (w) ©...
