Line Outputs

Parameter
Maximum Output Level
Output Impedance
Frequency Response
Usable Dynamic Range
Crosstalk
THD+N
Output Symmetry
Operating Levels
Sample Rates
Resolution
Group Delay
Measurement Parameters
Sample Rate:
Operating Level:
Reference frequency:
Value Notes
+24 dBu 600 Ω / 10 kΩ load
< 50 Ω
± 0.2 dB -0.5 dBFS, 20 Hz – 15 kHz
- 0.5 dB At 20 kHz
> 113 dB 0 dBFS, A-weighted filter, 22 kHz bandwidth
Typically >117 dB.
< -90 dB 20 Hz – 20 kHz, 0 dBFS
typically < -100 dB
< 0.004 % 20 Hz – 20 kHz, -10 dBFS, 22 kHz bandwidth
< 0.004 % 1 kHz, 0 dBFS to -20 dBFS, 22 kHz bandwidth
> 40 dB 20 Hz – 20 kHz
Typically > 50 dB
+24, +22, +20,
+18, +15 dBu
48 or 96 kHz
24 bit
31 samples Dante module to analogue
48 kHz
+24 dBu = 0 dBFS
1 kHz (unless stated otherwise)
