- Page 1 HC Bridge SRC User Guide REVISION: 1.1...
-
Page 2: Document Revision History
As research and development is a continual process, Solid State Logic reserves the right to change the features and specifications described herein without notice or obligation. Solid State Logic cannot be held responsible for any loss or damage arising directly or indirectly from any error or omission in this manual. - Page 3 HC Bridge SRC User Guide Contents Table of Contents HC Card Reset Introduction Appendix A – Physical Specifications Overview Appendix B - GPIO Connector Pin Outs Key Features GP Inputs HC Bridge SRC Front Panel GP Outputs HC Bridge SRC Rear Panel Status LEDs and User Buttons Appendix C –...
- Page 4 SFP cages on the rear are looped between the two Dante HC cards to provide a standalone 256 channel Dante SRC device. The HC Bridge SRC also contains 12 pairs of GPIO for use with connected System T consoles. Key Features ●...
- Page 5 HC Bridge SRC User Guide Contents Status LEDs and User Buttons LK1 S and LK2 S indicate the NET1 S and NET2 S indicate the current sync status SRC 1 and SRC 2 current sync status of the of the respective HC card:...
-
Page 6: Hardware Connections
HC Bridge SRC User Guide Contents Hardware Connections Mains Power Connections The HC Bridge SRC includes redundant PSUs with IEC connectors, either supply can individually power the unit. Ideally these should be connected to separate power circuits to provide redundancy of incoming AC power. -
Page 7: Usage Cases
A System T console running at 48 kHz would only be able to route audio to and from the devices at 48 kHz. With an HC Bridge SRC containing an HC card set to 96 kHz it would become possible to route 256 channels to and from the Dante devices running at 96 kHz. -
Page 8: Appendix A - Physical Specifications
HC Bridge SRC User Guide Contents Appendices Appendix A – Physical Specifications HC Bridge SRC Height 1RU, 44.5mm (1.75”) Width 483mm (19”) Depth 340mm (13.4”) Weight 4.5kg Power <100W Page 8 of 13... -
Page 9: Appendix B - Gpio Connector Pin Outs
HC Bridge SRC User Guide Contents Appendix B - GPIO Connector Pin Outs GP Inputs Inputs are triggered by applying an AC or DC voltage of between 4V and 24V. The current drawn is approximately 10mA. Minimum input pulse duration 50mS. - Page 10 HC Bridge SRC User Guide Contents GP Outputs All output switch closures are via DIL relay. DO NOT use these outputs to directly switch capacitive or reactive loads; ALWAYS use a separate external relay with suitable contact rating. DIL Relay Ratings: •...
-
Page 11: Appendix C - Safety Notices
HC Bridge SRC User Guide Contents Appendix C – Safety Notices General Safety Please read and keep this document. Adhere to all warnings and follow instructions. This electrical equipment should not be used near water. Cleaning should only be with dry cloths or products compatible with electrical devices –... - Page 12 HC Bridge SRC User Guide Contents Power Safety The unit is not supplied with a mains lead allowing you to use IEC distribution of mains cables of your choice. Any mains cable used must fulfil the following: Refer to the ratings label on the rear of the unit and always use suitable mains cords.
- Page 13 RoHS Notice Solid State Logic has conformed and this product has conformed to European Union’s Directive 2011/65/EU on Restrictions of Hazardous Substances (RoHS) as well as the following sections of California law which refer to RoHS, namely sections 25214.10, 25214.10.2, and 58012, Health and...
