SB i16 and SB 8.8 User Guide
Appendix C – Performance Specifications

Mic/Line Inputs

Parameter
Gain Range
Maximum Input Level
Frequency Response
Equivalent Input Noise
Usable Dynamic Range
Input Impedance
CMRR
Crosstalk
THD+N
Phantom Power (Mic
Input)
Pad (Mic Input)
Operating Levels
Sample Rates
Resolution
Group Delay
Measurement Parameters
Sample Rate:
Operating Level:
Mic input termination:
Mic Mode Gain:
Reference frequency:
Value
+5 to 79 dB 0 dBFS, MDAC continuous gain
+28 dBu Pad inserted
± 0.25 dB Mic mode, 20 Hz – 20 kHz (@48 kHz)
-0.5 dBu signal level
< -123 dB Mic mode, 70 dB gain, A-weighted filter,
22 kHz bandwidth.
> 114 dB Mic mode, 0 dBFS, A-weighted filter,
22 kHz bandwidth.
1.5 kΩ / 14 kΩ Mic / Line. Selectable per channel
> 55 dB Mic mode, 50 Hz – 20 kHz, 0 dBu
(typically > 65 dB)
> 80 dB Mic mode, 1 kHz, 0 dBu
(typically > 90 dB)
< -85 dB 20 Hz – 20 kHz
(typically < -95 dB)
< 0.005 % Mic mode, 20 Hz – 20 kHz, -6 dBu, 22 kHz
bandwidth
< 0.0015 % Mic mode, 1 kHz, -6 dBu, 22 kHz bandwidth
+48 V ±4 V
10 mA
20 dB
+24, +22, +20,
+18, +15 dBu
48 or 96 kHz
24 bit
39 samples
48 kHz
+24 dBu = 0 dBFS
150 Ω
24 dB (unless stated otherwise)
1 kHz (unless stated otherwise)
Notes
Selectable per channel
Selectable per channel
Analogue to Dante module
25
