Setup

Press Setup in the Page Select area to display the system configuration information.
Stagebox Ownership and Inputs Ownership settings are detailed under Ownership.
Name shows the device
name as set in Dante
Controller.
Clear Attention clears all active
attention LEDs on the currently
selected device.

Settings View

For installations using Dante Domain Manager (DDM), the Settings tab provides access to DDM
connection settings. Network I/O Controller can connect as a control client in the same way that
Dante Controller, SSL Live and System T consoles can. Consult the Dante Domain Manager User
Guide for further information regarding DDM.
DDM Server Connection
Status displays whether
there is an active
connection to DDM.
Info shows the status of the
device's redundant power
supplies, fans, and temperature.
Red indicates a fault.
Recalibrate All Owned Inputs
resets the trim applied to the
gain compensated inputs.
Operating Level allows selection
of the maximum analogue I/O
level in dBu (at 0dBFS) for the
device.
Reset IO Settings performs a device
reset of SSL parameters, clearing
ownership states and input settings.
DDM Server allows entry of the server name or
IP address.
User Name and Password credentials for DDM
are stored within Network I/O Controller. Once
entered, Network I/O Controller will
automatically attempt connection.
Selected Domain shows the active domain and
provides a list of all Dante domains the
selected user has access to.
AutoPad changes pad
mode from traditional
pad to AutoPad.
