- Page 1 Danfoss HFX Product Family Installation and Operation Manual For C-API SDK HFX Product Line AN430077865303en-000101...
- Page 2 Note: This manual was written with great care and precision. However, since the A limited warranty is given with these Danfoss products. Please see potential for error exists, we can provide no assurance of the absolute accuracy of its our website for details.
-
Page 3: Table Of Contents
Table of Contents Section Description Page No. INTRODUCTION TECHNICAL SPECIFICATIONS KEY FEATURES SAFETY CONSIDERATIONS APPLICATION HARDWARE DESCRIPTION SOFTWARE DESCRIPTION SERVICE TOOL - INSTALLATION AND GETTING STARTED DRIVER INSTALLATION INSTALL THE HFX SERVICE TOOL SOFTWARE LAUNCH THE HFX SERVICE TOOL GETTING STARTED FIRMWARE CREATING AN APPLICATION INSTALL APPLICATION... - Page 4 (THIS PAGE INTENTIONALLY LEFT BLANK) HFX Product Family Installation and Operation Manual for C-API April 2017...
-
Page 5: 1.0 Introduction
HFX Product Family 1.0 INTRODUCTION The Danfoss HFX product family is a series of advanced, CAN- based controllers for use with mobile and industrial Key Acronyms and Abbreviations equipment. Using C programming, these controllers enable functional control over electrically operated Firmware components within a variety of applications (e.g. -
Page 6: Technical Specifications
HFX Product Family TECHNICAL SPECIFICATIONS Danfoss HFX Controllers Dimensions 212.61mm L x 134.17mm W x 58.55mm H Weight 43.2 ounces (1225 grams) Storage Temperature Range -40 - +125 °C Operating Temperature Range -40 - +105°C (USB use is limited to 85°C) - Page 7 HFX Product Family Input Type Variable reluctance (Software con gurable) Maximum Input Frequency Ch 1 -2 (FREQ) (0 -5 V square or sine 0Hz...25kHz* Note: maximum aggregate is 200 kHz, minimum detectable pulse duration is 20 µsec wave) Note: phase and duty cycle are not supported by these inputs Switch -on Level Selectable as 2.2 V or self adaptive (input device changes voltage with frequency) Switch -o Level...
-
Page 8: Key Features
HARDWARE DESCRIPTION KEY FEATURES Robust, compact, fully sealed & potted cast • The Danfoss HFX product line consists of four controller aluminum construction models (HFX12m, HFX20m, HFX32m, and HFX48m), each Completely protected outputs possessing a unique number of I/O. The HFX12m/ HFX20m •... - Page 9 HFX Product Family The table below represents an I/O overview of the various HFX controller models. HFX48m HFX32m HFX20m HFX12m Controller Model (24 I/O) (16 I/O) (10 I/O) (6 I/O) Total Outputs Total 2 A channels Number of channels supporting function PWMi High Side output Total 4 A channels...
- Page 10 HFX Product Family The HFX48m incorporates 24 total Each channel is capable of: outputs, comprised of: High Side output • 8 x 4 A channels • Open loop PWM • 16 x 2 A channels • Closed loop PWM with current control •...
-
Page 11: Software Description
HFX Product Family SOFTWARE DESCRIPTION INSTALL THE HFX SERVICE TOOL SOFTWARE Software for the HFX family of controllers is provided Run the HFX Service Tool installation le setup.exe in in the form of the HFX C-API SDK. This is distributed \Service_Tools \Eaton_HFX_ST_Installer \ . -
Page 12: Getting Started
HFX Product Family INSTALL APPLICATION GETTING STARTED Option 1: Install application (HFX service tool) FIRMWARE Launch the HFX Service Tool if it is not already open. Install the Firmware On the main page of the service tool select HFX units are shipped blank, with no rmware loaded. Prior to File>Reprogram Application. -
Page 13: Functionality And Basic Operation
HFX Product Family 10.0 FUNCTIONALITY AND BASIC OPERATION be put into an idle state where less current is required thus extending battery life. It is also useful with applications where, At initial startup, the controller enters the bootloader. A Operating Enter Sleep bootloader is simply a small program that loads the rest of Mode... -
Page 14: Watchdog Operation
HFX Product Family 10.4 WATCHDOG OPERATION Watchdogs are present to provide an indication that something has gone wrong. Systems that are programmable can hang for a number of di erent reasons. One of the most common is the execution of an in nite loop due to a programming logic error. -
Page 15: Led Operation
HFX Product Family 10.7 LED OPERATION HFX32m & HFX48m Dimensional Data LED A (left-most) - Green power LED 4X .256 O ==> Not powered up • 6.50 Solid on ==> Powered up and Application • not running Fast ash (100ms on, 100ms o ) ==> •... -
Page 16: Recommended Wiring Practices
HFX Product Family Note: Please review individual overcurrent shutdown values HFX12m & HF20m Dimensional Data in the con guration and use the correct wire gauge conductor to accommodate maximum load current 4X .256 con gured 6.50 Make sure that voltage drops are kept within reasonable •... -
Page 17: Electrical Connection Information
HFX Product Family 12.0 ELECTRICAL CONNECTION INFORMATION Wiring Pin Out Note: All 4 of the HFX units share a common pin - out. The HFX12 does not utilize the following pins: 8, 15, 17, 25, 27, 31, 32, and 40. Note: Although all 4 of the HFX units share a common pin-out, both the HFX12 and the HFX20 do not have connector B. - Page 18 HFX Product Family The above connector is used for programming and is common to all 4 models of the HFX controller. HFX Product Family Installation and Operation Manual for C-API April 2017...
-
Page 19: Block Diagram
HFX Product Family 13.0 BLOCK DIAGRAM HFX Product Family Installation and Operation Manual for Matlab® Support Package January 2017... - Page 20 HFX Product Family HFX Product Family Installation and Operation Manual for C-API April 2017...
- Page 21 HFX Product Family HFX Product Family Installation and Operation Manual for Matlab® Support Package January 2017...
- Page 22 HFX Product Family HFX Product Family Installation and Operation Manual for C-API April 2017...
-
Page 23: Testing And Validation
HFX Product Family 14.0 TESTING AND VALIDATION Requirement Speci cations Electrical/EMI/EMC EU (2004/104/) EU automotive EMC directive CISPR 25 Conducted emissions (EU broadband & narowband limits) CISPR 25 Radiated emissions (EU broadband & narowband limits) ISO 11452 -4 Immunity to narrowband conducted electormagnetic energy via bulk current injection ISO 11452 -2 Immunity to narrowband radiated electormagnetic energy via absorption lined chamber SAE J1113 -2:2004... -
Page 24: Service Tool
HFX Product Family 15.0 SERVICE TOOL 15.1 HFX SERVICE TOOL The HFX service tool allows the user to download rmware or application programs and provides an aid for troubleshooting. There are ve pages that display and/or allow con guration of various I/O types. Please see section 9 for details covering rmware and application installation. - Page 25 HFX Product Family The above page is the Analog In page. This page enables the user to view input values associated with the analog channels and con gure each channel for a speci c type of input. It also o ers the ability to individually select lters for each channel. X Product Family Installation and Operation Manual for Matlab®...
- Page 26 HFX Product Family The above page is the Freq In page. This page enables the user to view input values associated with the frequency channels and con gure each channel for a speci c type of input to temporarily deviate from the application de ned con guration. HFX Product Family Installation and Operation Manual for C-API April 2017...
- Page 27 HFX Product Family The above page is the Output page. This page enables the user to view controller temperature, individual channel feedback current/voltage, dither, duty cycle, frequency and current control gain speci c to each output channel. Each channel can also be con gured as current control, or PWM to temporarily deviate from the application con guration.
- Page 28 HFX Product Family The above page is the fault page and it displays warnings, system status, and any faults that are active. To see the full list of faults consult the capi_hfx_manual.pdf . HFX Product Family Installation and Operation Manual for C-API April 2017...
-
Page 29: Fxst Service Tool
HFX Product Family 15.2 FXST SERVICE TOOL The purpose of this tool is to allow access to the application level build information calibrations, probes and overrides and allow reprograming of the target application and view faults and certain con gurations. For uploading a new application see section 9. - Page 31 Phone: +45 7488 2222 Phone: +86 21 2080 6201 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products agreed.
