APPLICA TION NOTE

Firelite MS-9200UDLS

Must be installed in
conduit and located
in the same room
within 20 feet.
TB2 TB1
JP7
+ - + 24V + 24V
REMOTE PWR NON-RST RST
SUPPLY SYNC POWER POWER
JP4
Connection Instructions:
1. Connect the 24VDC on the CellComSLCF to the TB2 header on the
host panel.
2. Connect the phone line from TIP and RING on the CellComSLCF to PH15
on host panel.
3. Normal Central Station programming.
J11
J10
J1
TB11
JP5
J9
Digital Monitoring Products
6
MODEL CellCom
J8
B R
TB3 TB4 TB7
1B+ 3B+ 3B- 1B- 2B+ 4B+ 4B- 2B- NO
JP6
J14
KEYPAD
IF
LCD DISPLAY
J4
KWYBOARD COMM.
BATTERY
- + J8
J3
S1
S2
J9
S3
+12 G Z1 Z2 Z3 G Z4+ Z4- O1 O2 T R
TB5 TB6
NC C NO NC C NO NC C
JP2
MIN DIN
CellComSLCF Cellular Communicator Dialer Capture Application Note
RESET
S1
LOAD
S2
Must be installed in
conduit and located
in the same room
within 20 feet.
TB8 TB9
Xmt Rcv Dtr Gnd + - B+ A+ B-
A B A B Slc Slc Slc
In+ In- OUT+ Out-
J5
J7
SW1
Firelite
MS-9200UDLS
PH15
PRI. PHONE LINE SEC. PHONE LINE
TB10
A- A B
Slc SHIELD
J6
JP3
J12
PH16
