Test Data and Performance Curves
V 500 V/DIV
LINE
V 10 V/DIV
SENSE1
I 2 A/DIV
SENSE1
I 10 A/DIV
INJ
Figure 5-4. IEC 61000-4-5 Surge, 5-kV Repetitive Strike at 10-Second Intervals – Positive (a), Negative (b)
10 TPSF12C3QEVM Active EMI Filter Evaluation Module for Three-Phase AC
Power Systems
10 s/DIV
(a)
Copyright © 2023 Texas Instruments Incorporated
V 500 V/DIV
LINE
V 10 V/DIV
SENSE1
I 2 A/DIV
SENSE1
I 10 A/DIV
INJ
(b)
