3 EVM Photo
Figure 3-1
highlights the AEF solution and the connection interface using header J1 to the EMI filter in the
application circuit. S1, S2, S3 and S4 connect to the sense capacitors, and INJ connects to the inject capacitor.
GND is tied to Earth or chassis ground of the system.
SLVUCM2 – JANUARY 2023
Submit Document Feedback
Figure 3-1. TPSF12C3QEVM Photo
CAUTION
Caution Hot surface.
Contact may cause burns.
Do not touch.
TPSF12C3QEVM Active EMI Filter Evaluation Module for Three-Phase AC
