Showven SPARKULAR JET User Manual page 6

3. RFID area
Composite Ti with RFID card, swiping cards used to identify parameters and types of granules.
The RFID card is disposable, one card can only use one time.
Interface
Δ
1. Main Interface:
First Line: DMX: DMX address
Second Line: T: inner core temp.
The working principle of the machine is when the firing is triggered, it takes some time (jet
delay) for the system to transfer and stimulate the consumables. When it reached the firing
trigger delay time, the valve will open automatically and firing.
2. Error information
Error information
E0 System IC
E1 Pump Protect
E2 Temp. Sensor
E3 P Temp. Over
E4 Time Remain
E5 K Temp. Over
E6 Heat Fail
P: pressure value
Delay: firing trigger delay
1. Emergency stop was executed when firing was triggered, and firing
stops. E0 disappear automatically 1min later
2. Too frequent firing in a short period of time, E0 disappear 100s later
It happens when continuous pressurization fail, probably the pump
broken
Temperature sensor is not connected or damage
Chassis over-temperature
Activated time for machine is not enough, need to swiping RFID card
Heating chamber over-temperature
Heating fail, if recover automatically, please pay attention to the power
supply
Explanation
