1 Product Overview

The RG-AP210-L AP operates in 802.11b/g/n with an access rate up to 300Mbps. It supports security, radio frequency
(RF) control, mobile access, Quality of Service (QoS) and seamless roaming. Teaming up with Ruijie AC Wireless
Controller Series, the AP can accomplish with ease wireless data forwarding, high performance security and access
control. The built-in antenna design enhances decoration effect and signal coverage. As for installation, both wall
mounting and ceiling mounting are possible. In addition, the AP adopts either local power supply or PoE power supply.
Therefore, AP210-L can be applied in a variety of scenarios, including offices, hotels and retail businesses.

1.1 Technical Specifications

Table 1-1 Technical Specifications of RG-AP210-L
Hardware Specifications
Radio
RF
RF Standard
Transmission
Protocol
Spatial Streams
Access Rates
Maximum Transmit
Power
Flash
Dimensions
(W x D x H)
Weight
Ports and Button
Reset
LED Indicators
Power Supply
Antenna
Power Consumption
IP Rating
Temperature
Humidity
MTBF
EMC Standard
2.4GHz (in operational band 2.412GHz to 2.472GH)
EN 300328
802.11b/g/n
2 streams, 2 x 2 MIMO
Up to 300Mbps
≤20dBm (Adjustable)
32MB
175mm x 175mm x 38mm (6.9in x 6.9in x 1.5in)
0.35kg
One 10/100BASE-T Ethernet port (PoE-capable)
One DC port
One Reset button
Supported
Supported
IEEE 802.af/at PoE
Local power supply
Built-in omnidirectional, antenna gain: 3dBi
＜7.5W
IP41
Operating: -10℃ to 45℃ (14℉ to 113℉)
Storage: -40℃ to 60℃ (-40℉ to 140℉)
Operating: 5% to 95% (non-condensing)
Storage: 5% to 95% (non-condensing)
>250,000H
GB9254
·
