Introduction
WARNING:
AVERTISSEMENT : Le FOXBOX T HD-SDI émet une lumière invisible en continu
•
•
•
About this Guide
This guide describes how to install, operate, and configure the following Extron
FOXBOX T HD-SDI fiber optic transmitters.
•
•
NOTE: The two products are physically and functionally identical, with the exception of
the effective range of transmission. The term "transmitter" refers to either product.
About the FOXBOX T HD-SDI Transmitter
The FOXBOX T HD-SDI transmits 3G HD-SDI, HD-SDI, and SDI video and embedded digital
audio via a single fiber optic cable (see
fiber optic receiver receives the image and outputs the video and audio. The transmitter can
also send, on the same fiber optic cable:
•
•
With a second fiber optic cable, the transmitter can receive RS-232 responses from the
connected receiver.
NOTE: The RS-232 communications are a passive pass-through only. The transmitter
The FOXBOX T HD-SDI outputs continuous invisible light (Class 1 rated),
which may be harmful to the eyes; use with caution.
•
Do not look into the rear panel fiber optic cable connectors or into the fiber optic
cables themselves.
•
Plug the attached dust cap into the optical transceiver when the fiber optic cable is
unplugged.
(conforme à la classe 1) qui peut être dangereux pour les yeux, à utiliser avec
précaution.
•
Ne regardez pas dans les connecteurs de câble fibre optique sur le panneau arrière
ou dans les câbles fibre optique eux-mêmes.
•
Branchez la protection contre la poussière dans l'ensemble émetteur/récepteur
lorsque le câble fibre optique est débranché.
About this Guide
About the FOXBOX T HD-SDI Transmitter
Features
FOXBOX T HD-SDI SM — A singlemode, very long distance (up to 30 km [18.75
miles]) transmitter.
FOXBOX T HD-SDI MM — A multimode, long distance (2 km [6,561 feet]) transmitter.
Optional analog audio
RS-232 control signals
does not generate or respond to the RS-232 communication signals.
FOXBOX T HD-SDI Fiber Optic Transmitter • Introduction
figure
1, on the next page). A compatible Extron
1
