Extron electronics FOXBOX T HD-SDI User Manual page 5

Software Commands
Commands are written in the fonts shown here:
Computer responses and directory paths that do not have variables are written in the font
shown here:
Variables are written in slanted form as shown here:
Specifications Availability
Product specifications are available on the Extron website, www.extron.com.
^AR Merge Scene,,Op1 scene 1,1 ^B 51 ^W^C
[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]
E X! *X1^* X1** X2#* X2!
CE
NOTE: For commands and examples of computer or device responses mentioned
in this guide, the character "0" is used for the number zero and "O" is the capital
letter "o."
Reply from 208.132.180.48: bytes=32 times=2ms TTL=32
C:\Program Files\Extron
ping xxx.xxx.xxx.xxx —t
SOH R Data STX Command ETB ETX
}
